MWP90 series
90 Watt Medical Grade AC Adapter
MWP90 is NOT RECOMMENDED FOR NEW DEsiGNs
PlEasE usE MWC100 as a REPlaCEMENT
Replacement http://iccus.com/datasheets/mwc100.pdf
Features
Power factor correction
Wide range AC input
Fully regulated output
High efficiency
Medical grade approval
Also available in white
5 year warranty
Electrical Specifications
Input
Voltage................................ 90 - 264 VAC
Current................................ 2.0 Amp @ 90 VAC
Frequency........................... 47 - 63 Hz
Earth leakage current..........
Test Voltage
Normal
Single-fault
190 uA
330 uA
132 VAC 60 Hz 100 uA
264 VAC 50 Hz 190 uA
Environmental
Operating temperature.......... 0 C to 40 C
Storage temperature............. -55 C to 85 C
Weight = 1.40 lbs
EMI/EMC
Meets FCC class B, CISPR 11 class B
EMC per EN60601-1-2
EN61000-3-2 and EN61000-3-3
Safety
UR/cUR
CE Marked
UL2601-1
EN60601-1-2:2001
Output
Line regulation.................... TYP +/- 1%
Load regulation................... TYP +/- 5%
Set point.............................. +/- 3% at 60% load
Hold up time........................ 20 ms min at full load, 115 VAC
Transient response............. 500 ms for 50% to 100% load change
Over voltage protection....... Built-in
Over current protection....... Built-in
Short circuit protection........ Pulsing mode, auto recovery
Efficiency............................ 90% typical
Ripple/noise (V
p-p
)............... +/- 1% pk-pk (20 MHz bandwidth)
Polarity
DIN-8
1
V1
2
V1
3
Com
4
V1
5
Com
6
V1
7
8
Com Com
Model No.
Voltage Power Current
MWP9012-D8-NC-BK
12V
90W
7.5A
MWP9015-D8-NC-BK
15V
90W
6.0A
MWP9018-D8-NC-BK
MWP9024-D8-NC-BK
18V
24V
90W
90W
5.0A
3.75A
Input and Output Connections
Input connector (P1) = IEC 60320 inlet plug
Output connector (P2) = DIN-8 pin
circular connector
Output cable length = 6 ft
DIN-8
6
1
4 2 5
8
7
3
Rev 0905
Elpac Power Supplies 1562 Reynolds Ave. Irvine, CA 92614 USA TEL +1 949-476-6070 www.elpac.com info@elpac.com
