IMC-0603
Vishay Dale
High Frequency, Surface Mount, Laser Spiral
Coated Inductors
FEATURES
•
•
•
•
•
•
•
•
Very small in size
High self-resonant frequency values
High Q values relative to size at higher frequencies
RoHS
Coated coil provides protection and moisture
COMPLIANT
resistance
Compatible with vapor phase and infrared reflow soldering
Tape and reel packaging for automatic handling, 3000/reel, EIA-481
L and Q value not affected by mounting orientation
100 % lead (Pb)-free and RoHS compliant
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0 nH to 220 nH
Inductance Tolerance:
± 0.3 nH for 1.0 - 3.3 nH
± 5 % for 3.9 nH to 220 nH
Operating Temperature:
- 40 °C to + 100 °C Core
Material:
Ceramic
TEST EQUIPMENT
•
Inductance and Q measured on HP4291B
•
SRF measured on HP8753E
•
DCR measured on HP4338B
STANDARD ELECTRICAL SPECIFICATIONS
INDUCTANCE
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
TOLERANCE
± 0.3 nH, 0.2 nH
± 0.3 nH, 0.2 nH
± 0.3 nH, 0.2 nH
± 0.3 nH, 0.2 nH
± 0.3 nH, 0.2 nH
± 0.3 nH, 0.2 nH
± 0.3 nH, 0.2 nH
±5%
±5%
±5%
±5%
±5%
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
± 5 %, 2 %
TEST FREQ.
L
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Q
MINIMUM
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
26
26
26
20
20
TEST FREQ.
Q
(MHz)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
SELF-RESONANT
FREQ. MIN.
(MHz)
6000
6000
6000
6000
6000
6000
5500
5500
4800
4600
3550
3500
2800
2800
2500
2300
2000
2000
1800
1800
1800
1800
1500
1500
1300
1200
1100
1000
900
DCR
MAXIMUM
(Ohms)
0.06
0.06
0.07
0.08
0.09
0.10
0.12
0.15
0.17
0.18
0.20
0.28
0.32
0.35
0.41
0.45
0.50
0.55
0.60
0.80
0.95
1.20
1.30
1.50
1.80
3.00
4.50
6.5
7.5
RATED DC
CURRENT *
(mA)
500
500
500
500
500
500
500
450
450
430
430
400
400
400
350
350
300
300
300
300
250
250
250
250
200
130
100
80
70
*Value obtained when current flows and the temperature has risen 15 °C
DIMENSIONS
in inches [millimeters]
0.031 ± 0.008
[0.8 ± 0.20]
0.016 ± 0.008
[0.4 ± 0.2]
0.063 ± 0.008
[1.6 ± 0.20]
0.016 ± 0.004
[0.4 ± 0.1]
0.031 ± 0.006
[0.8 ± 0.15]
0.091
[2.3]
Recommended
Pad Layout
0.035
[ 0.8]
0.02
[0.8]
DESCRIPTION
IMC-0603
MODEL
10 nH
INDUCTANCE VALUE
±5%
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e4
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
M
C
0
6
0
3
E
R
1
0
N
J
www.vishay.com
94
For technical questions, contact: magnetics@vishay.com
Document Number: 34039
Revision: 10-Aug-06
