5962-8990812XX datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> 5962-8990812XX

5962-8990812XX: DescriptionSynchro or Resolver to Digital Converter, Hybrid, DIP-36; CategoryAnalog mixed-signal IC converter; File Size674KB，8 Pages; ManufacturerData Device Corporation

Download Datasheet Parametric Compare View All

5962-8990812XX Overview

Synchro or Resolver to Digital Converter, Hybrid, DIP-36

5962-8990812XX Parametric

Parameter Name	Attribute value
Maker	Data Device Corporation
Parts packaging code	DIP
package instruction	DIP-36
Contacts	36
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ALSO REQUIRES A +5V NOMINAL SUPPLY
Maximum analog input voltage	11.8 V
Maximum angular accuracy	4 arc min
Converter type	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER
JESD-30 code	R-XDIP-P36
length	48.13 mm
Maximum negative supply voltage	-15.75 V
Minimum negative supply voltage	-14.25 V
Nominal negative supply voltage	-15 V
Number of digits	16
Number of functions	1
Number of terminals	36
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	UNSPECIFIED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Qualified
Maximum seat height	5.33 mm
Signal/output frequency	400 Hz
Maximum supply voltage	15.75 V
Minimum supply voltage	14.25 V
Nominal supply voltage	15 V
surface mount	NO
technology	HYBRID
Temperature level	MILITARY
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	DUAL
width	15.24 mm
Base Number Matches	1

Preview

Download Datasheet

View All

5962-8990812XX Related Products

	5962-8990812XX	5962-8990811XX	5962-8949908XX	5962-8990813XX	5962-8949907XX
Description	Synchro or Resolver to Digital Converter, Hybrid, DIP-36	Synchro or Resolver to Digital Converter, Hybrid, DIP-36	Synchro or Resolver to Digital Converter, Hybrid, DIP-36	Synchro or Resolver to Digital Converter, Hybrid, DIP-36	Synchro or Resolver to Digital Converter, Hybrid, DIP-36
Parts packaging code	DIP	DIP	DIP	DIP	DIP
package instruction	DIP-36	DIP-36	DIP-36	DIP-36	DIP-36
Contacts	36	36	36	36	36
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum analog input voltage	11.8 V	11.8 V	11.8 V	11.8 V	11.8 V
Maximum angular accuracy	4 arc min	4 arc min	6 arc min	2 arc min	4 arc min
Converter type	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER
JESD-30 code	R-XDIP-P36	R-XDIP-P36	R-XDIP-P36	R-XDIP-P36	R-XDIP-P36
length	48.13 mm	48.13 mm	48.13 mm	48.13 mm	48.13 mm
Maximum negative supply voltage	-15.75 V	-15.75 V	-15.75 V	-15.75 V	-15.75 V
Minimum negative supply voltage	-14.25 V	-14.25 V	-14.25 V	-14.25 V	-14.25 V
Nominal negative supply voltage	-15 V	-15 V	-15 V	-15 V	-15 V
Number of digits	16	16	16	16	16
Number of functions	1	1	1	1	1
Number of terminals	36	36	36	36	36
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
encapsulated code	DIP	DIP	DIP	DIP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
Certification status	Qualified	Qualified	Qualified	Qualified	Qualified
Maximum seat height	5.33 mm	5.33 mm	5.33 mm	5.33 mm	5.33 mm
Signal/output frequency	400 Hz	400 Hz	400 Hz	400 Hz	400 Hz
Maximum supply voltage	15.75 V	15.75 V	15.75 V	15.75 V	15.75 V
Minimum supply voltage	14.25 V	14.25 V	14.25 V	14.25 V	14.25 V
Nominal supply voltage	15 V	15 V	15 V	15 V	15 V
surface mount	NO	NO	NO	NO	NO
technology	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID
Temperature level	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY
Terminal form	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL
width	15.24 mm	15.24 mm	15.24 mm	15.24 mm	15.24 mm
Base Number Matches	1	1	1	1	1
Maker	Data Device Corporation	Data Device Corporation	-	Data Device Corporation	Data Device Corporation
Other features	ALSO REQUIRES A +5V NOMINAL SUPPLY	ALSO REQUIRES A +5V NOMINAL SUPPLY	-	ALSO REQUIRES A +5V NOMINAL SUPPLY	-
