Table 2. Optical characteristics for LUXEON MZ at test current, T
j
=85°C .
PART NUMBER
LMZx-xWxx
TYPICAL TOTAL INCLUDED ANGLE
[1]
140°
TYPICAL VIEWING ANGLE
[2]
120°
Notes for Table 2:
1. Total angle at which 90% of total luminous flux is captured.
2. Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value.
Electrical and Thermal Characteristics
Table 3. Electrical and thermal characteristics for LUXEON MZ at test current, T
j
=85ºC .
PART NUMBER
LMZx-Sxxx
LMZx-Rxxx
LMZx-Qxxx
FORWARD VOLTAGE (V)
[1]
MINIMUM
10.50
5.25
2.63
TYPICAL
11.20
5.60
2.80
MAXIMUM
11.70
6.00
3.00
TYPICAL TEMPERATURE
COEFFICIENT OF FORWARD
VOLTAGE (mV/°C)
[2]
-7.00
-3.50
-1.75
TYPICAL THERMAL
RESISTANCE – JUNCTION TO
SOLDER PAD (°C/W)
1.25
1.25
1.25
Notes for Table 3:
1. Lumileds maintains a tolerance of ± 0.06V on forward voltage measurements.
2. Measured between 25°C and 85°C.
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON MZ .
PARAMETER
DC Forward Current
[1,2]
MAXIMUM PERFORMANCE
1200mA for LMZx-Sxxx
2400mA for LMZx-Rxxx
4800mA for LMZx-Qxxx
1375mA for LMZx-Sxxx
2750mA for LMZx-Rxxx
5500mA for LMZx-Qxxx
-40°C to 135°C
Class 3B
-40°C to 120°C
-40°C to 120°C
JEDEC 020c 260°C
3
LUXEON LEDs are not designed to be driven in reverse bias
Peak Pulsed Forward Current
[1,3]
LED Junction Temperature
[1]
(DC & Pulse)
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
Operating Case Temperature
[1]
Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
Notes for Table 4:
1. Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed 15% of the maximum allowable DC forward current
