CLD-DS60 Rev 8D
Product family data sheet
Cree
®
XLamp
®
MK-R LEDs
PRoDuCt DEsCRiPtion
Built on Cree’s revolutionary SC³ Technology
®
platform, the
XLamp
®
MK-R LeD brings new levels of price and performance
to directional LeD arrays, enabling lighting manufacturers to
create the next generation of high-lumen indoor and outdoor
LeD lighting systems. In single-LeD systems, the XLamp MK-R
LeD, with easyWhite
®
color binning, provides the LeD industry’s
tightest unit-to-unit color consistency. For systems using multiple
LeDs, the MK-R enables manufacturers to use fewer LeDs while
maintaining light output and color consistency, which translates
to lower system cost.
The XLamp MK-R LeD is optimized for directional lighting
applications and is a welcome addition to applications requiring
high lumen output, a compact optical source and a broad palette
of color temperature and CRI values.
FEAtuREs
•
Available in ANSI white bins as well as 4-step and 2-step
EasyWhite bins at 2700 K, 3000 K, 3500 K, 4000 K, 4500 K
and 5000 K CCT
• Two voltage options: 6 V & 12 V
• Low thermal resistance: 1.7 °C/W
• Maximum junction temperature: 150 °C
• Binned at 85 °C
• Viewing angle: 120°
•
Available in cool white, 70-, 80- and 90-CRI minimums
• Unlimited floor life at ≤ 30 ºC/85% RH
• Reflow solderable - JEDEC J-STD-020C
•
electrically neutral thermal path
• RoHS and REACh compliant
•
UL
®
recognized component (E349212)
WWW.CREE.Com/XLAmp
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
, EasyWhite
®
and SC
3
Technology
®
are registered trademarks and the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
mK-R LEDs
tAbLE oF ContEnts
Characteristics .......................................................................................................................................................................................................
3
Flux Characteristics, easyWhite
®
Order Codes and Bins - 6 V
............................................................................................................................ 4
Flux Characteristics, ANSI White Order Codes and Bins - 6 V.............................................................................................................................
6
Flux Characteristics, easyWhite
®
Order Codes and Bins -12 V
........................................................................................................................... 9
Flux Characteristics, ANSI White Order Codes and Bins - 12 V
........................................................................................................................
11
Relative Spectral Power Distribution ..................................................................................................................................................................
14
Relative Flux vs. Junction Temperature
..............................................................................................................................................................
14
electrical Characteristics .....................................................................................................................................................................................
15
Relative Flux vs. Current ......................................................................................................................................................................................
16
Relative Chromaticity vs. Current........................................................................................................................................................................
17
Relative Chromaticity vs. Temperature ...............................................................................................................................................................
18
Typical Spatial Distribution..................................................................................................................................................................................
18
Thermal Design ....................................................................................................................................................................................................
19
Performance Groups - Luminous Flux ................................................................................................................................................................ 20
Performance Groups - Chromaticity ...................................................................................................................................................................
21
Cree easyWhite
®
Bins Plotted on the 1931 CIE Color Space
............................................................................................................................ 24
Cree ANSI White Bins Plotted on the 1931 CIE Color Space............................................................................................................................. 25
Cree’s Standard Cool White Kits Plotted on ANSI Standard Chromaticity Regions......................................................................................... 26
Cree’s Standard Warm and Neutral White Kits Plotted on ANSI Standard Chromaticity Regions .................................................................. 26
Bin and Order Code Formats ............................................................................................................................................................................... 27
Reflow Soldering Characteristics
........................................................................................................................................................................ 28
Notes .................................................................................................................................................................................................................... 29
Mechanical Dimensions ......................................................................................................................................................................................
31
Tape and Reel .......................................................................................................................................................................................................
32
Packaging .............................................................................................................................................................................................................
33
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
, EasyWhite
®
and SC
3
Technology
®
are registered trademarks and
the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
2
XLamp
®
mK-R LEDs
ChARACtERistiCs
Characteristics
Thermal resistance, junction to solder point
Viewing angle - full width half maximum (FWHM)
Temperature coefficient of voltage (6 V, 1400 mA, 85 °C)
Temperature coefficient of voltage (12 V, 700 mA, 85 °C)
ESD withstand voltage (HBM per Mil-Std-883D)
DC forward current (6 V, 1400 mA, 85 °C)
DC forward current (12 V, 700 mA, 85 °C)
Reverse voltage
Forward voltage (6 V, 1400 mA, 85 °C)
Forward voltage (12 V, 700 mA, 85 °C)
LeD junction temperature
unit
°C/W
degrees
mV/°C
mV/°C
v
mA
mA
v
v
v
°C
5.85
11.7
Minimum
typical
1.7
120
-4
-8
8000
2500
1250
5
7
14
150
Maximum
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
, EasyWhite
®
and SC
3
Technology
®
are registered trademarks and
the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
mK-R LEDs
FLuX ChARACtERistiCs, EAsyWhitE
®
Order COdes and Bins - 6 V (i
F
= 1400 mA,
t
J
= 85 °C)
The following tables provide order codes for XLamp MK-R LeDs. For a complete description of the order code nomenclature, please
reference Bin and Order Code Formats (page 27).
Minimum Luminous Flux**
Color
CCt
Range
Group
H4
5000 K
H2
G4
H4
4500 K
H2
G4
H4
4000 K
H2
G4
80-CRI
easyWhite
3500 K
H4
H2
G4
G2
H2
3000 K
G4
G2
H2
2700 K
G4
G2
F4
Flux
(lm) @
85 °C
970
900
840
970
900
840
970
900
840
970
900
840
780
900
840
780
900
840
780
730
Flux
(lm) @
25 °C*
1091
1012
945
1091
1012
945
1091
1012
945
1091
1012
945
877
1012
945
877
1012
945
877
821
27H
30H
35H
40H
45H
50H
Chromaticity
Region
2-step
order Code
MKRAWT-00-0000-0B0HH450H
MKRAWT-00-0000-0B0HH250H
MKRAWT-00-0000-0B0HG450H
MKRAWT-00-0000-0B0HH445H
MKRAWT-00-0000-0B0HH245H
MKRAWT-00-0000-0B0HG445H
MKRAWT-00-0000-0B0HH440H
MKRAWT-00-0000-0B0HH240H
MKRAWT-00-0000-0B0HG440H
MKRAWT-00-0000-0B0HH435H
MKRAWT-00-0000-0B0HH235H
MKRAWT-00-0000-0B0HG435H
MKRAWT-00-0000-0B0HG235H
MKRAWT-00-0000-0B0HH230H
MKRAWT-00-0000-0B0HG430H
MKRAWT-00-0000-0B0HG230H
MKRAWT-00-0000-0B0HH227H
MKRAWT-00-0000-0B0HG427H
MKRAWT-00-0000-0B0HG227H
MKRAWT-00-0000-0B0HF427H
27F
30F
35F
40F
45F
50F
Chromaticity
Region
4-step
order Code
MKRAWT-00-0000-0B0HH450F
MKRAWT-00-0000-0B0HH250F
MKRAWT-00-0000-0B0HG450F
MKRAWT-00-0000-0B0HH445F
MKRAWT-00-0000-0B0HH245F
MKRAWT-00-0000-0B0HG445F
MKRAWT-00-0000-0B0HH440F
MKRAWT-00-0000-0B0HH240F
MKRAWT-00-0000-0B0HG440F
MKRAWT-00-0000-0B0HH435F
MKRAWT-00-0000-0B0HH235F
MKRAWT-00-0000-0B0HG435F
MKRAWT-00-0000-0B0HG235F
MKRAWT-00-0000-0B0HH230F
MKRAWT-00-0000-0B0HG430F
MKRAWT-00-0000-0B0HG230F
MKRAWT-00-0000-0B0HH227F
MKRAWT-00-0000-0B0HG427F
MKRAWT-00-0000-0B0HG227F
MKRAWT-00-0000-0B0HF427F
Notes:
• Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on CRI
measurements. See the Measurements section (page 29).
•
Minimum CRI for 80-CRI White is 80.
*
Flux values @ 25 °C are calculated and for reference only.
**
Cree XLamp MK-R LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher
than the minimum specified by the order code without advance notice. Shipments will always adhere to the chromaticity restrictions
specified by the order code.
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
, EasyWhite
®
and SC
3
Technology
®
are registered trademarks and
the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
mK-R LEDs
FLuX ChARACtERistiCs, EAsyWhitE
®
Order COdes and Bins - 6 V (i
F
= 1400 mA,
t
J
= 85 °C) - COntinued
Minimum Luminous Flux**
Color
CCt
Range
Group
F4
3000 K
F2
e4
e2
F2
2700 K
e4
e2
D4
Flux
(lm) @
85 °C
730
680
635
590
680
635
590
550
Flux
(lm) @
25 °C*
821
765
714
664
765
714
664
619
27H
30H
Chromaticity
Region
2-step
order Code
MKRAWT-00-0000-0B0UF430H
MKRAWT-00-0000-0B0UF230H
MKRAWT-00-0000-0B0UE430H
MKRAWT-00-0000-0B0UE230H
MKRAWT-00-0000-0B0UF227H
MKRAWT-00-0000-0B0UE427H
MKRAWT-00-0000-0B0UE227H
MKRAWT-00-0000-0B0UD427H
27F
30F
Chromaticity
Region
4-step
order Code
MKRAWT-00-0000-0B0UF430F
MKRAWT-00-0000-0B0UF230F
MKRAWT-00-0000-0B0UE430F
MKRAWT-00-0000-0B0UE230F
MKRAWT-00-0000-0B0UF227F
MKRAWT-00-0000-0B0Ue427F
MKRAWT-00-0000-0B0Ue227F
MKRAWT-00-0000-0B0UD427F
90-CRI
easyWhite
Notes:
• Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on CRI
measurements. See the Measurements section (page 29).
•
Minimum CRI for 90-CRI White is 90.
*
Flux values @ 25 °C are calculated and for reference only.
**
Cree XLamp MK-R LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher
than the minimum specified by the order code without advance notice. Shipments will always adhere to the chromaticity restrictions
specified by the order code.
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
, EasyWhite
®
and SC
3
Technology
®
are registered trademarks and
the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
