GW-CSSRM2PM-N1N3-XX53-1 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> GW-CSSRM2PM-N1N3-XX53-1

GW-CSSRM2PM-N1N3-XX53-1: DescriptionHigh Power LEDs - White White 5000K OSLON Square; CategoryLED optoelectronic/LED; File Size2MB，26 Pages; ManufacturerOsram Opto Semiconductor; Websitehttps://www.osram.com/index-2.jsp

Download Datasheet Parametric Compare View All

GW-CSSRM2PM-N1N3-XX53-1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GW-CSSRM2PM-N1N3-XX53-1	-	-	View	Buy Now

GW-CSSRM2PM-N1N3-XX53-1 Overview

High Power LEDs - White White 5000K OSLON Square

GW-CSSRM2PM-N1N3-XX53-1 Parametric

Parameter Name	Attribute value
Product Category	High Power LEDs - White
Manufacturer	Osram Opto Semiconductor
RoHS	Details
Package / Case	SMD-2
Illumination Color	White (Cool White)
Wavelength/Color Temperature	5000 K
Luminous Intensity	91 cd
Luminous Flux/Radiant Flux	280 lm
Color Rendering Index - CRI	70
Viewing Angle	120 deg
If - Forward Current	700 mA
Vf - Forward Voltage	2.8 V
Mounting Style	SMD/SMT
Length	3 mm
Width	3 mm
Height	2.17 mm
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Packaging	Reel
Packaging	MouseReel
Packaging	Cut Tape
Color Temperature	5000 K
Features	-
LED Size	3 mm x 3 mm x 2.17 mm
Factory Pack Quantity	600

Preview

Download Datasheet

View All

2016-01-15

OSLON

Square

Datasheet

Version 1.2

GW CSSRM2.PM

Third generation of OSLON Square with improved

radiation pattern and enhanced performance. Most

compact high-power LED with well known superior

robustness, high reliability, long lifetime and low

thermal resistance.

Die dritte Generation OSLON Square mit verbesserter

Abstrahlcharakteristik und nochmals verbesserter

Leistung. Die kompakte High-Power LEDs bietet

erprobte Zuverlässigkeit und lange Lebensdauer bei

niedrigstem Wärmewiderstand.

Features:

•

Package:

SMT ceramic package with silicone resin

and silicone lens

•

Viewing angle at 50 % I

120°

•

Color:

3000 K - 6500 K (white)

•

CRI:

min. 70 ( typ. 72 )

•

Luminous Flux:

typ. 300 lm @ 5000 K, 85 °C

•

Luminous efficacy:

typ. 153 lm/W @ 5000 K,

85 °C

•

Corrosion Robustness:

Superior Corrosion

Robustness

•

Lumen Maintenance:

Test results according to

IESNA LM-80 available

Applications

•

Industrial lighting

•

Outdoor lighting

•

Street and tunnel lighting

Besondere Merkmale:

•

Gehäusetyp:

SMT-Keramikgehäuse mit

Silikonverguss und -linse

•

Abstrahlwinkel bei 50 % I

120°

•

Farbe:

3000 K - 6500 K (weiß)

•

CRI:

min. 70 ( typ. 72 )

•

Lichtstrom:

typ. 300 lm @ 5000 K, 85 °C

•

Lichtausbeute:

typ. 153 lm/W @ 5000 K, 85 °C

•

Korrosionsstabilität:

Höchste

Korrosionsbeständigkeit

Lichtstromerhaltung:

Testergebnisse nach

IESNA LM-80 verfügbar

Anwendungen

•

Industriebeleuchtung

•

Außenbeleuchtung

•

Straßen und Tunnel

2016-01-15

Version 1.2

GW CSSRM2.PM

Type:

Typ:

Color

Temperature

Farbtemperatur

Luminous Flux

page 28

Ordering Code

Bestellnummer

Lichtstrom

Seite 28

= 700 mA, T

85 °C

[K]

[lm]

GW CSSRM2.PM-N3N5-A232-1

GW CSSRM2.PM-N3N5-XX52-1

GW CSSRM2.PM-N1N3-A131-1

GW CSSRM2.PM-N1N3-XX51-1

GW CSSRM2.PM-N2N4-A131-1

GW CSSRM2.PM-N2N4-XX51-1

Note:

5700

6500

300 ... 330

280 ... 310

290 ... 320

Q65112A0217

Q65112A0228

Q65112A0234

Q65112A0233

Q65112A0236

Q65112A0235

The above Type Numbers represent the order groups which include only a few brightness groups (see page 8). Only one group will

be shipped on each packing unit (there will be no mixing of two groups on each packing unit). E. g. GW CSSRM2.PM-M9N1-XX57-1

means that only one group M9, MF, N1 will be shippable for any packing unit.

In a similar manner for colors where color chromaticity coordinate groups are measured and binned, single groups will be shipped on

any one packing unit. GW CSSRM2.PM-M9N1-XX57-1 means that the device will be shipped within the specified limits.

In a similar manner for colors where forward voltage groups are measured and binned, single forward voltage groups will be shipped

on any packing unit. E. g. GW CSSRM2.PM-M9N1-XX57-1 means that only one forward voltage group K2,L1,L2,M1,M2 will be

shippable.

Anm.:

Die oben genannten Typbezeichnungen umfassen die bestellbaren Selektionen. Diese bestehen aus wenigen Helligkeitsgruppen

(siehe Seite 8). Es wird nur eine einzige Helligkeitsgruppe pro Verpackungseinheit geliefert. Z. B. GW CSSRM2.PM-M9N1-XX57-1

bedeutet, dass in einer Verpackungseinheit nur eine der Helligkeitsgruppen M9, MF, N1 enhalten ist.

Gleiches gilt für die Farben, bei denen Farbortgruppen gemessen und gruppiert werden. Pro Verpackungseinheit wird nur eine

Farbortgruppe geliefert. Z.B. GW CSSRM2.PM-M9N1-XX57-1 bedeutet, dass in einer Verpackungseinheit nur eine der

Farbortgruppen enthalten ist. GW CSSRM2.PM-M9N1-XX57-1 bedeutet, dass das Bauteil innerhalb der spezifizierten Grenzen

geliefert wird.

Gleiches gilt für die LEDs, bei denen die Durchlassspannungsgruppen gemessen und gruppiert werden. Pro Verpackungseinheit

wird nur eine Durchlassspannungsgruppe geliefert. Z. B. GW CSSRM2.PM-M9N1-XX57-1 bedeutet, dass nach

Durchlassspannungsgruppen gruppiert wird. In einer Verpackungseinheit ist nur eine der Durchlassspannungsgruppen

K2,L1,L2,M1,M2 enthalten (siehe Seite 8).

2016-01-15
