DIALIGHT
PART NUMBER
597-3021-402F; -407F
597-3202-402F; -407F
597-3312-402F; -407F
597-3325-402F; -407F
597-3612-402F; -407F
LED
COLOR
RED
ORANGE
GREEN
InGaN GREEN
BLUE
REV
ECN NO
REVISIONS
DRN CKD APP
DATE
RoHS COMPLIANT 597-3XXX-40XF
Part Numbers with the "F" suffix ending are RoHS Compliant.
For example: 597-3021-402F
Reel and bag packaging are marked with "RoHS Compliant"
label or equivalent markings. These parts can be used with
RoHS reflow profile. Parts can be wave soldered, dip soldered
or hand soldered using typical lead-free soldering process
with max 260°C temp. for 5 sec.
LENS
PEAK
VIEWING
WAVELENGTH ANGLE
(nm)
(DEG)
TYP
635
609
565
522
465
TYP
60
60
60
50
50
.118
[3]
.079
[2,01]
.071
[1,8]
.036
[0,9]
2
1
.059
[1,5]
LED CHIP
CATHODE MARK
A
B
NEW RELEASE
TWC
ADDED P/Ns: 597-3021-402F,-407F;
597-3202-402F,-407F;
597-3312-402F,-407F;
AJF KLJ
& 597-3612-402F,-407F;
REVISED NOTES.
NO 3-14-11
OPERATING CHARACTERISTICS AT 25 $ AMBIENT
C
LUMINOUS INTENSITY FORWARD VOLTAGE
REVERSE
@I
F
= 20 mA
@I
F
= 20 mA
CURRENT
(10 mA FOR InGaN GREEN & BLUE)
(10 mA FOR InGaN GREEN & BLUE)
( A)
(mcd)
(V)
MIN
RED
ORANGE
GREEN
InGaN GREEN
BLUE
150
150
27
150
47
MAX
330
330
56
680
220
TYP
1.9
1.9
2.1
3.3
3.3
MAX
2.4
2.4
2.5
3.8
3.8
MAX
100
100
100
100
100
DOMINANT
WAVELENGTH
(nm)
MIN
620
600
558
TYP
626
605
561
525
470
MAX
632
609
564
DEVICE SURFACE TEMPERATURE
LED
COLOR
C
$
260
230
180
PRE-HEATING
OPERATION HEATING
~
150
0
ABSOLUTE MAXIMUM RATINGS AT 25 C AMBIENT
$
POWER DISSIPATION
FORWARD CURRENT
PULSE FORWARD CURRENT (DUTY
DERATE LINEARLY FROM 75 C
$
REVERSE VOLTAGE
STORAGE TEMPERATURE
OPERATING TEMPERATURE
< 1/20, PULSE WIDTH < 1ms)
(FROM 60 C OR HIGHER FOR InGAN GREEN & BLUE)
$
RED
78
30
100
1.0
5
LED COLOR
UNITS
InGaN
ORANGE GREEN
BLUE
GREEN
78
81
84
80
mW
30
100
1.0
5
30
100
1.0
5
-40 TO +100
20
48
0.96
5
20
48
0.96
5
mA
mA
mA/ $
C
V
$
C
$
C
120s
40s MAX
RECOMMNEDED RoHS SOLDER PROFILE
-40 TO +120
-40 TO +110
.024
[0,6]
PCB
NOTES:
1. DIE: InGaN FOR P/Ns 597-3325-40XF & 597-3612-40XF
AllnGaP FOR ALL OTHER P/Ns.
2. EPOXY COLOR: WATER CLEAR.
3. DIALIGHT PART NUMBERS: 597-3XXX-40XF.
4. ...-402F SUFFIX FOR 20 PCS ON A SAMPLE STRIP.
5. ...-407F SUFFIX FOR 7" [180mm] DIA. REEL, .315" [8mm] WIDE TAPE,
PACKAGED 2,500 PCS PER REEL, CATHODE TOWARDS SPROCKET.
6. MOISTURE SENSITIVITY LEVEL: 4.
7. THESE COMPONENTS CONTAINS ELECTROSTATIC DISCHARGE SENSITIVE
DEVICES (ESDS). MAINTAIN ALL PRECAUTIONARY MEASURES DURING
ASSEMBLY, HANDLING AND STORAGE IN ACCORDANCE WITH IPC-A-610.
ATTENTION:
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES
PIN 2
PIN 1
CATHODE
.063
[1,6]
LED SCHEMATIC
.051
[1,3]
2
1
.008 TYP.
[0,2]
1
.157±.004 TYP.
[4,00±0.1]
.079 TYP.
[2,00]
.059+.004
-.000
[1,5+0.1]
-0
.069 #
.004
[1,75 #
0,1]
.138
[3,50]
.173 #
.002
[4,39 #
0,05 ]
THIS DRAWING AND THE CONTENTS HEREIN ARE CONFIDENTIAL AND
THE SOLE PROPERTY OF DIALIGHT. REPRODUCTION OF THIS DRAWING
OR CONSTRUCTION OF ANY PARTS WITHIN THIS DRAWING ARE
FORBIDDEN WITHOUT THE WRITTEN CONSENT OF DIALIGHT.
SCALE: 20.000
.315 #
.008
[8,00 #
0,2]
DRAWING NUMBER
REV
.063 #
.002
[1,6 #
0,05 ]
ALL DIM'S IN: INCHES (MM)
TOLERANCES:
UNLESS OTHERWISE SPECIFIED
C-17266
TITLE
MATERIAL
SMT LED, 1206 PKG. W/ LENS
RoHS COMPLIANT
B
FRACTIONS: #
1/64
DECIMALS (.XX): #
.01
DECIMALS (.XXX): #
.008
.067±.008 TYP.
[1,7±0.2]
.157±.004
[4,00±0.1]
TYP.
CATHODE
FEED DIRECTION
TAPING SPECIFICATIONS
.063 #
.002
[1,6 #
0,05 ]
RECOMMENDED SOLDER PAD LAYOUT
ANGLES:
# $
1
-
1501 ROUTE 34 SOUTH
FARMINGDALE, NJ 07727
SCALE
15.000
FINISH:
2
-
FSCM
83330
SHEET
1
OF
1
FAMILY TABLE:
