IllumInatIon
luXeon uV u line
Highest power density, superior efficiency, powered
by leading Chip Scale Package (CSP) technology
At a micro package size compared to other ultraviolet and violet LEDs,
LUXEON UV U Line LEDs are SMT devices that can be assembled in
tight arrays with spacing of only 200 microns, which enables high power
density (W/cm²) systems for superior efficiency and design freedom.
These products are undomed for precise optical control and include a
portfolio of 1mm² and 2mm² die sizes covering ultraviolet and violet light.
The superior power density, excellent robustness of CSP technology and
real world efficacy enable leading performance and efficient solution
development in a wide variety of UV specialty lighting applications.
Features and BeneFIts
Offering ultraviolet in 380-400nm and violet (400–420nm) for a range of options
Small 2.2 to 3.6mm² SMT footprint enables highest W/cm
2
power density,
design freedom
1A per mm
2
die size maximum drive current allows more power per LED
Up to 50%+ efficiency reduces heat output
AlN package R
th
as low as 1.8 K/W for better thermal management
PrImary aPPlIcatIons
Specialty Lighting
– Analytical Instrumentation
– Curing
– Medical
– Security
– UV Photoreaction
COMPLIANT
RoHS
DS178 LUXEON UV U Line Product Datasheet ©2017 Lumileds Holding B.V. All rights reserved.
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical and Thermal Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Spectral Power Distribution Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Forward Current Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Wavelength Shift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Radiation Pattern Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Product Bin and Labeling Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Decoding Product Bin Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Radiometric Power Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Peak Wavelength Bins. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Reflow Soldering Guidelines
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Pocket Tape Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Reel Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
DS178 LUXEON UV U Line Product Datasheet 20170711 ©2017 Lumileds Holding B.V. All rights reserved.
i
General Product Information
Product Test Conditions
LUXEON UV U Line LEDs are tested and binned with a DC drive current of 500mA for LUXEON UV U1 and 1000mA for LUXEON
UV U2 at a junction temperature, T
j
, of 25ºC.
Part Number Nomenclature
Part numbers for LUXEON UV U1 follow the convention below:
L H U V –
B B B B
– A
C C C
Where:
B B B B
–
designates peak wavelength (0385=385nm ±5nm, 0395=395nm ±5nm,
0405=405nm ±5nm, 0415=415nm ±5nm)
C C C
–
designates minimum radiometric power bin (025=250mW, 030=300mW, 035=350mW,
040=400mW, 045=450mW, 050=500mW, 055=550mW, 060=600mW, 065=650mW,
070=700mW, 075=750mW, 080=800mW)
Therefore, the following part number is used for a LUXEON UV U1 with a peak wavelength of 395nm and a minimum radiometric
power bin of 400mW:
L H U V –
0 3 9 5
– A
0 4 0
Part numbers for LUXEON UV U2 follow the convention below:
L 1 F 3 – U
A A A B
0 0 0
C C C C
0
Where:
A A A
B
–
–
designates peak wavelength 380=380nm, 390=390nm, 400=400nm and 410=410nm)
designates product name and die size (2=LUXEON UV U2 with 2mm
2
die size)
designates minimum radiometric power bin (0400=400mW, 0600=600mW, 0800=800mW,
1000=1000mW, 1200=1200mW, 1400=1400mW)
Therefore, the following part number is used for a LUXEON UV U2 with a peak wavelength of 390nm and a minimum radiometric
power bin of 1000mW:
L 1 F 3 – U
3 9 0 2
0 0 0
1 0 0 0
0
C C C C
–
DS178 LUXEON UV U Line Product Datasheet 20170711 ©2017 Lumileds Holding B.V. All rights reserved.
2
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the long-
term performance of this product.
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON UV U Line
is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment, namely the
RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the following restricted
materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated
diphenyl ethers (PBDE).
DS178 LUXEON UV U Line Product Datasheet 20170711 ©2017 Lumileds Holding B.V. All rights reserved.
3
Performance Characteristics
Product Selection Guide
Table 1a . Product performance of LUXEON UV U1 at 500mA and 1000mA, T
j
=25ºC .
PeaK
WaVelength
[1]
tyPIcal radIometrIc PoWer
[2]
(mW)
500ma
575
415 ±5nm
625
675
725
575
405 ±5nm
625
675
725
525
395 ±5nm
575
625
675
275
325
375
385 ±5nm
425
475
525
575
Notes for Table 1a:
1. Lumileds maintains a tolerance of ±2nm for peak wavelength measurements.
2. Lumileds maintains a tolerance of ±10% for radiometric power measurements.
1000ma
1093
1188
1283
1378
1093
1188
1283
1378
998
1093
1188
1283
523
618
713
808
903
998
1093
Part numBer
LHUV-0415-A055
LHUV-0415-A060
LHUV-0415-A065
LHUV-0415-A070
LHUV-0405-A055
LHUV-0405-A060
LHUV-0405-A065
LHUV-0405-A070
LHUV-0395-A050
LHUV-0395-A055
LHUV-0395-A060
LHUV-0395-A065
LHUV-0385-A025
LHUV-0385-A030
LHUV-0385-A035
LHUV-0385-A040
LHUV-0385-A045
LHUV-0385-A050
LHUV-0385-A055
Table 1b . Product performance of LUXEON UV U2 at 1000mA and 2000mA, T
j
=25°C .
PeaK
WaVelength
[1]
410–420nm
tyPIcal radIometrIc PoWer
[2]
(mW)
1000ma
1300
1450
1100
400–410nm
1300
1450
390–400nm
1100
1300
700
380–390nm
900
1050
Notes for Table 1b:
1. Lumileds maintains a tolerance of ±2nm for peak wavelength measurements.
2. Lumileds maintains a tolerance of ±10% for radiometric power measurements
2000ma
2340
2610
1980
2340
2610
1980
2340
1260
1620
1890
Part numBer
L1F3-U410200012000
L1F3-U410200014000
L1F3-U400200010000
L1F3-U400200012000
L1F3-U400200014000
L1F3-U390200010000
L1F3-U390200012000
L1F3-U380200006000
L1F3-U380200008000
L1F3-U380200010000
DS178 LUXEON UV U Line Product Datasheet 20170711 ©2017 Lumileds Holding B.V. All rights reserved.
4
