Pacific Silicon Sensor Series 7 Data Sheet
Part Description PC20-7-SM
Order # 01-063
ACTIVE AREA: 20mm
2
(5.05mm DIA)
8.80
1.50
MAX
0.90
1.27
TYP
6
7
8 9 10
10.60
5.66 SQ
5.30
1
5
5 4
0.62
3
2 1
1.50
TYP
0.50
5.08
FRONTSIDE VIEW
BACKSIDE VIEW
R
o
H
FEATURES
•
•
•
•
∅
5.05 mm active area
Low capacitance
Long term stability
High NIR sensitivity
DESCRIPTION
20.0 mm Low Capacitance PIN Photodiode. Surface
mount packaged with clear epoxy encapsulant.
2
APPLICATIONS
•
•
•
•
Laser detection
Instrumentation
Optical remote control
Pulsed light sensor
S
C
PLI
A
NT
OM
ABSOLUTE MAXIMUM RATING
SYMBOL PARAMETER
MIN
T
STG
T
OP
V
R(OP)
I
(PEAK)
Storage Temp
Operating Temp
Reverse Operating
Voltage
Peak DC Current
-20
-20
-
-
SPECTRAL RESPONSE
MAX
+80
+60
50
10
UNITS
°C
°C
V
mA
RESPONSIVITY (A/W)
0.70
0.60
0.50
0.40
0.30
0.20
0.10
0.00
300
SCHEMATIC
LEAD 1
LEADS 3 & 5
LEADS 2,4,6,7,8,9,& 10
NOT CONNECTED
400
500
600
700
800
900
1000
1100
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS @ 22° C
SYMBOL
CHARACTERISTIC
TEST CONDITIONS
I
D
C
Dark Current
Capacitance
Responsivity
NEP
V
BR
t
r
Noise Equivalent Power
Breakdown Voltage
Rise Time
V
R
= 12 V
V
R
= 12 V
V
R
= 0 V;
λ
= 950 nm
V
R
= 0 V;
λ
= 1064 nm
V
R
= 12 V;
λ
= 850 nm; R
L
= 50
Ω
I
R
= 10 µA
V
R
= 12 V;
λ
= 850 nm; R
L
= 50
Ω
MIN
---
---
---
---
---
30
---
TYP
0.5
20
0.65
0.20
2.0 X 10
---
50
-14
MAX
---
---
---
---
---
---
---
UNITS
nA
pF
A/W
W/Hz
V
ns
1/2
Disclaimer: Due to our policy of continued development, specifications are subject to change without notice.
Package is not suitable for reflow soldering.
USA:
Pacific Silicon Sensor, Inc.
5700 Corsa Avenue, #105
Westlake Village, CA 91362 USA
Phone (818) 706-3400
Fax (818) 889-7053
Email:
sales@pacific-sensor.com
www.pacific-sensor.com
7/19/2010
