Product Specification
10Gb/s, 40km Single Mode, Multi-Rate SFP+ Transceiver
FTLX1672M3BCL
PRODUCT FEATURES
Hot-pluggable SFP+ footprint
Supports 8.5 and 9.95 to 11.3 Gb/s
40km link length (800ps/nm)
-5/70°C case temperature range
Internal transmitter/receiver CDR
low power consumption
Cooled 1550nm EML laser
Limiting electrical interface receiver
Duplex LC connector
Built-in digital diagnostic functions
RoHS-6 compliant (lead-free)
APPLICATIONS
SONET OC-192 IR-2/-3
SDH STM-64.2b/3b
OTN G959.1 P1S1-2D2b
OTN G.709 OTU1e/2/2e FEC bit rates
10GBASE-ER/EW
8.5/10G Fibre Channel
Finisar’s FTLX1672M3BCL transceivers are Enhanced Small Form Factor Pluggable
SFP+ transceivers designed for use in 10-Gigabit multi-rate links up to 40km of G.652
single mode fiber. They are compliant with SFF-8431
1
, SFF-8432
2
, SONET OC-192 IR-
2R/3R, SDH STM-64.2b/3b, OTN P1S1-2D2b, 10GBASE-ER/EW and support 8.5G and
10G Fibre Channel. The transceivers use internal clock and data recovery (CDR) IC’s for
the transmitter and the receiver. This guarantees compliance with the SONET/SDH jitter
requirements and it can be used to set the electrical interface to be XFI-compliant.
Digital diagnostics functions are available via a 2-wire serial interface, as specified in
SFF-8472
3
. The optical transceiver is compliant per the RoHS Directive
2011/65/EU
4
. See Finisar Application Note AN-2038 for more details
5
.
PRODUCT SELECTION
FTLX1672M3BCL
Finisar Corporation –September 2015
Rev. C1
Page 1
FTLX1672M3BCL Product Specification
I.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Pin Descriptions
Symbol
V
EET
T
FAULT
T
DIS
SDA
SCL
MOD_ABS
RS0
RX_LOS
RS1
V
EER
V
EER
RD-
RD+
V
EER
V
CCR
V
CCT
V
EET
TD+
TD-
V
EET
Name/Description
Transmitter Ground
Transmitter Fault
Transmitter Disable. Laser output disabled on high or open.
2-wire Serial Interface Data Line
2-wire Serial Interface Clock Line
Module Absent. Grounded within the module
Rate Select 0.
Loss of Signal indication. Logic 0 indicates normal operation.
Rate Select 1.
Receiver Ground
Receiver Ground
Receiver Inverted DATA out. AC Coupled.
Receiver Non-inverted DATA out. AC Coupled.
Receiver Ground
Receiver Power Supply
Transmitter Power Supply
Transmitter Ground
Transmitter Non-Inverted DATA in. AC Coupled.
Transmitter Inverted DATA in. AC Coupled.
Transmitter Ground
Ref.
1
2
3
2
2
2
4
5
4
1
1
1
6
6
1
1
Notes:
1. Circuit ground is internally isolated from chassis ground.
2. T
is an open collector/drain output, which should be pulled up with a 4.7k – 10k Ohms resistor on
FAULT
3.
4.
5.
6.
the host board if intended for use. Pull up voltage should be between 2.0V to Vcc + 0.3V. A high
output indicates a transmitter fault caused by either the TX bias current or the TX output power
exceeding the preset alarm thresholds. A low output indicates normal operation. In the low state, the
output is pulled to <0.8V.
Laser output disabled on T
DIS
>2.0V or open, enabled on T
DIS
<0.8V.
Internally pulled down per SFF-8431 Rev 4.1. See Sec. X of this datasheet for the logic table to use for
the internal CDRs locking modes.
LOS is open collector output. Should be pulled up with 4.7k – 10k on host board to a voltage
between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
Internally connected
VeeT
1
VeeT
TD-
2
TX_Fault
TD+
3
TX_Disable
VeeT
4
SDA
VccT
16
17
18
19
20
Towards
Bezel
5
SCL
VccR
15
6
MOD_ABS
VeeR
14
Towards
ASIC
7
RS0
RD+
13
8
RX_LOS
RD-
12
9
RS1
VeeR
11
VeeR
10
Figure 1. Diagram of Host Board Connector Block Pin Numbers and Names.
Finisar Corporation - September 2015
Rev. C1
Page 2
FTLX1672M3BCL Product Specification
II. Absolute Maximum Ratings
Exceeding the limits below may damage the transceiver module permanently.
Parameter
Maximum Supply Voltage
Storage Temperature
Relative Humidity
Receiver Optical Damage Threshold
Notes:
1. Non-condensing
Symbol
Vcc
T
S
RH
Rx
Damage
Min
-0.5
-40
0
5
Typ
Max
4.0
85
85
Unit
V
C
%
dBm
Ref.
1
III.
Electrical Characteristics (T
OP
= -5 to 70
C)
Parameter
Symbol
Vcc
R
in
V
in,pp
V
D
V
EN
R
out
V
out,pp
T
r
, T
f
V
LOS A
V
LOS D
V
CCT
/V
CCR
P
diss-C
Min
3.14
80
120
V
cc
-0.8
0
Typ
3.30
100
Max
3.46
120
850
V
cc
0.8
Unit
V
mV
V
V
mV
ps
V
V
mVpp
W
W
Ref.
Supply Voltage
Transmitter (Tx)
Input differential impedance
Differential data input swing
Transmit Disable Voltage
Transmit Enable Voltage
Receiver (Rx)
Output differential impedance
Differential data output swing
Output rise time and fall time
LOS asserted
LOS de-asserted
Power Supply Noise Tolerance
Power Consumption
Tx and Rx CDRs ON
Tx and Rx CDRs OFF and Ethernet spec.
1
80
100
120
300
850
28
V
cc
-0.8
V
cc
0
0.8
Per SFF-8431 Rev 4.1
1.6
1.4
1.7
1.5
1
2
3
3
4
5
5
Notes:
1. Internally AC coupled. Data pins connect directly to the CDR.
2.
20 – 80%. Measured with Module Compliance Test Board and OMA test pattern. Use of four 1’s and four 0’s
sequence in the PRBS 9 is an acceptable alternative. SFF-8431 Rev 4.1.
3. LOS is an open collector output. Should be pulled up with 4.7k – 10k on the host board. Normal operation is
logic 0; loss of signal is logic 1.
4. See Section 2.8.3 of SFF-8431 Rev 4.1.
5. Typical power consumption values refer to 70C, 3.3V and beginning of life.
Finisar Corporation - September 2015
Rev. C1
Page 3
FTLX1672M3BCL Product Specification
IV.
Optical Characteristics (T
OP
= -5 to 70
C,
V
CC
= 3.14 to 3.46 Volts)
Ref.
Parameter
Symbol
Min
Typ
Max
Unit
Transmitter (Tx)
Output Power
P
AVE
-1
+2
dBm
Optical Wavelength
1530
1565
nm
Side-Mode Suppression Ratio
SMSR
30
dB
Optical Extinction Ratio
ER
8.2
dB
Average Launch power when Tx is OFF
P
OFF
-30
dBm
Jitter Generation 20kHz-80MHz, peak-peak
Tx
jpk2pk1
0.3
UI
Jitter Generation 4MHz-80MHz, peak-peak
Tx
jpk2pj2
0.1
UI
Relative Intensity Noise
RIN
-128
dB/Hz
Receiver (Rx)
Optical Center Wavelength
1260
1600
nm
C
Receiver Reflectance
R
rx
-27
dB
-16
dBm
8.5, 9.95-10.7 Gb/s
R
SENS1
Sensitivity
11.1-11.3 Gb/s
R
SENS2
-15
dBm
Overload
R
OVL
-1
dBm
Path Penalty (800ps/nm)
PP
2
dB
LOS De-Assert
LOS
D
-21
dBm
LOS Assert
LOS
A
-29
dBm
LOS Hysteresis
LOS
H
0.5
dB
Notes:
1. SONET/SDH jitter performance is guaranteed with the internal CDRs enabled and locked
2. PRBS 2
31
– 1at BER<10
-12
3. Measured with worst ER=8.2 dB
1
1
2,3
2,3
2,3
V.
General Specifications
Parameter
Symbol
BR
L
MAX
Min
8.5
Typ
Max
11.3168
40
Units
Gb/s
km
Ref.
1
2
Bit Rate
Max. Supported Link Length
Notes:
1. Tested with a 2
31
– 1 PRBS pattern at the BER defined in Table IV.
2. Over G.652 single mode fiber.
Timing Parameters
Parameter
Time to initialize
Symbol
t_start_up
Min
Typ
Max
10
Units
s
Ref.
Finisar Corporation - September 2015
Rev. C1
Page 4
FTLX1672M3BCL Product Specification
VI.
Environmental Specifications
Finisar FTLX1672M3BCL transceivers have the following temperature
specifications:
Parameter
Case Operating Temperature
Storage Temperature
Symbol
T
op
T
sto
Min
-5
-40
Typ
Max
70
85
Units
°C
°C
Ref.
VII. Regulatory Compliance
Finisar transceivers are Class 1 Laser Products and comply with US FDA regulations.
These products are certified by TÜV and CSA to meet the Class 1 eye safety
requirements of EN (IEC) 60825 and the electrical safety requirements of
EN (IEC) 60950. Copies of certificates are available at Finisar Corporation upon request.
Finisar Corporation - September 2015
Rev. C1
Page 5
