LUXEON 3535 Mid-Power LEDs
Illumination Portfolio
Introduction
LUXEON
®
3535 delivers optimized performance in combination with quality of light needed
for distributed light source applications. In addition to delivering specified correlated color
temperature and color rendering combinations, these emitters deliver the efficacy and reliability
required by the indoor illumination markets. This document contains the performance data
needed to design and engineer applications based on these LUXEON 3535 emitters.
Features and Benefits
• High efficacy for sustainable design
• Compact 3535 package
• Minimum 70 and 80 CRI for both indoor and outdoor applications
• ANSI compliant 1/6th color binning
• Supports ENERGY STAR
®
lumen maintenance certification
requirements
Key Applications
• Lamps
• Indoor Area Lighting
• Downlight
• Outdoor
• Architecture
• High bay & Low bay
LUXEON 3535 Datasheet DS202 ©2013 Philips Lumileds Lighting Company.
Table of Contents
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Average Lumen Maintenance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
JEDEC Moisture Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Reflow Soldering Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Relative Spectral Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Luminous Efficacy Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Forward Current Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Typical Radiation Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Emitter Pocket Tape Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Emitter Reel Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Product Binning and Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Color Bin Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
LUXEON 3535 Datasheet DS202 20130228 ©2013 Philips Lumileds Lighting Company.
i
General Information
Product Nomenclature
LUXEON Mid-Power Illumination emitters are tested and binned at 100 mA, with current pulse duration of 20 ms. All
characteristic charts where the thermal pad is kept at constant temperature (25ºC typically) are measured with current pulse
duration of 20 ms.
The part number designations for the MXM8 series is explained as follows:
M X M A - B C D E - I J K L
Where:
A
B
C
—
—
—
designates minimum CRI performance (value 7 = 70 minimum and 8 = 80 minimum)
designates radiation pattern (value P = Lambertian)
designates color (value W = White)
designates nominal ANSI CCT (for example, 30 = 3000K and 40 = 4000K)
D, E —
I, J, K & L — designates additional part numbers
Therefore products in this series with minimum CRI value of 80, CCT of 4000K will have the part numbering scheme:
M X M 8 - P W 4 0
Average Lumen Maintenance Characteristics
Lumen maintenance for solid-state lighting devices (LEDs) is typically defined in terms of the percentage of initial light output
remaining after a specified period of time.
Environmental Compliance
Philips Lumileds is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON
Mid-Power LEDs are compliant to the European Union directives on the restriction of hazardous substances in electronic
equipment, namely REACH and the RoHS directive. Philips Lumileds will not intentionally add the following restricted materials
to these LEDs: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl
ethers (PBDE).
LUXEON 3535 Datasheet DS202 20130228 ©2013 Philips Lumileds Lighting Company.
2
Product Selection
Product Selection for Mid-Power LEDs
Solder Pad Temperature = 25°C, Test Current = 100 mA
Table 1.
Nominal
CCT
2700K
3000K
3500K
4000K
5000K
5700K
6500K
Part
Number
MXM8-PW27-0000
MXM8-PW30-0000
MXM8-PW35-0000
MXM8-PW40-0000
MXM8-PW50-0000
MXM8-PW57-0000
MXM8-PW65-0000
Minimum
CRI
80
80
80
80
80
80
80
Typical
CRI
82
82
82
82
82
82
82
Typical
R9
10
10
10
10
10
10
10
Minimum Luminous
Flux (lm)
ɸ
V
28
30
30
32
32
32
32
Typical Luminous
Flux (lm)
ɸ
V
32
33
34
36
36
36
36
Product Selection for Mid-Power LEDs
Solder Pad Temperature = 25°C, Test Current = 100 mA
Table 2.
Nominal
CCT
4000K
5000K
5700K
6500K
Note for Tables 1 & 2:
1. Philips Lumileds maintains a tolerance of ± 7.5% on luminous flux and ± 2 on CRI measurements.
Part Number
MXM7-PW40-0000
MXM7-PW50-0000
MXM7-PW57-0000
MXM7-PW65-0000
Color Rendering Index
Minimum
70
70
70
70
Typical
72
73
73
74
Minimum Luminous
Flux (lm)
ɸ
V
32
32
32
32
Typical Luminous
Flux (lm)
ɸ
V
39
39
39
39
LUXEON 3535 Datasheet DS202 20130228 ©2013 Philips Lumileds Lighting Company.
3
Optical Characteristics
Optical Characteristics of Mid-Power LEDs
Solder Pad Temperature = 25°C, Test Current = 100 mA
Table 3.
Nominal
CCT
2700K
3000K
3500K
4000K
5000K
5700K
6500K
Notes for Table 3:
1. Total angle at which 90% of total luminous flux is captured.
2. Viewing angle is the off axis angle from lamp centerline where the luminous intensity is ½ of the peak value.
Color Temperature CCT
Minimum
2550K
2850K
3200K
3750K
4700K
5300K
6000K
Typical
2700K
3000K
3500K
4000K
5000K
5700K
6500K
Maximum
2850K
3200K
3750K
4250K
5300K
6000K
7000K
Typical Total
Included Angle
[1]
(degrees)
u
0 .90V
150
150
150
150
150
150
150
Typical
Viewing Angle
[2]
(degrees) 2u
½
115
115
115
115
115
115
115
LUXEON 3535 Datasheet DS202 20130228 ©2013 Philips Lumileds Lighting Company.
4
