XBGHVW-H0-0000-00000HBE7 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> XBGHVW-H0-0000-00000HBE7

XBGHVW-H0-0000-00000HBE7: DescriptionHigh Power LEDs - White White, 114lm; CategoryLED optoelectronic/LED; File Size1MB，10 Pages; ManufacturerCree; Websitehttp://www.cree.com/

Download Datasheet Parametric Compare View All

XBGHVW-H0-0000-00000HBE7 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	XBGHVW-H0-0000-00000HBE7	-	-	View	Buy Now

XBGHVW-H0-0000-00000HBE7 Overview

High Power LEDs - White White, 114lm

XBGHVW-H0-0000-00000HBE7 Parametric

Parameter Name	Attribute value
Product Category	High Power LEDs - White
Manufacturer	Cree
RoHS	Details
Package / Case	SMD-2
Illumination Color	White (Warm White)
Wavelength/Color Temperature	3000 K
Luminous Intensity	-
Luminous Flux/Radiant Flux	93.9 lm
Color Rendering Index - CRI	80
Viewing Angle	140 deg
Lens Color/Style	Tinted, Clear
If - Forward Current	44 mA
Vf - Forward Voltage	22.5 V
Power Rating	5 W
Mounting Style	SMD/SMT
Length	2.45 mm
Width	2.45 mm
Height	2.45 mm
Maximum Operating Temperature	-
Minimum Operating Temperature	-
Packaging	Reel
Packaging	MouseReel
Packaging	Cut Tape
Color Temperature	3000 K
Features	-
LED Size	2.45 mm x 2.45 mm x 1.8 mm
Lens Dimensions	2.4 mm x 2.4 mm
Lens Shape	Square
Factory Pack Quantity	1000
Type	XLamp XB-G HighVoltage White LEDs
Vr - Reverse Voltage	5 V

Preview

Download Datasheet

View All

CLD-DS72 Rev 2C

Product family data sheet

Cree

XLamp

XB-G High-Voltage White LEDs

PRODUCT DESCRIPTION

Built on Cree’s SC³ Technology

Platform,

the XLamp

XB-G High-voltage White

(HvW) LeD is optimized to lower cost for

high-lumen, omnidirectional replacement

lamps. The XB-G HvW LeD delivers high

efficacy in the small XB footprint and

enables smaller and more efficient driver

circuits than standard-voltage LeDs.

In addition, the XB-G LeD has a wider

light distribution that can improve the

omnidirectionality of eNeRGY STAR

replacement lamps.

FEATURES

•

Binned @ 85 °C & 44 mA

Available in 80-minimum CRI

200 mA maximum drive current

22.5 V typical forward voltage

@ 85 °C, 44 mA

Wide viewing angle: 140°

Reflow solderable - JEDEC

J-STD-020C compatible

Unlimited floor life at

≤ 30 °C/85% RH

electrically neutral thermal path

RoHS-compliant

recognized component

(E349212)

TABLE OF CONTENTS

Characteristics ....................................... 2

Flux Characteristics

............................... 2

Relative Spectral Power Distribution ....

electrical Characteristics .......................

Relative Flux vs. Current

........................

Typical Spatial Distribution....................

Thermal Design ...................................... 5

Reflow Soldering Characteristics

.......... 6

Notes ...................................................... 7

Mechanical Dimensions ........................ 8

Tape and Reel .........................................

Packaging ............................................. 10

WWW.CREE.Com/XLAmP

, the Cree logo,

XLamp

, EasyWhite

and SC³ Technology

are registered trademarks of Cree, Inc. UL

and the UR logo are registered trademarks of UL LLC. ENERGY

STAR

is a registered trademark of the U.S. Environmental Protection Agency.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

XBGHVW-H0-0000-00000HBE7 Related Products

	XBGHVW-H0-0000-00000HBE7	XBGHVW-H0-0000-00000HBF8	XBGHVW-H0-0000-00000HCF8	XBGHVW-H0-0000-00000HDF8
Description	High Power LEDs - White White, 114lm	High Power LEDs - White White, 114lm	High Power LEDs - White White, 100lm	High Power LEDs - White White, 107lm
Product Category	High Power LEDs - White	High Power LEDs - White	-	High Power LEDs - White
Manufacturer	Cree	Cree	-	Cree
RoHS	Details	Details	-	Details
Package / Case	SMD-2	SMD-2	-	SMD-2
Illumination Color	White (Warm White)	White (Warm White)	-	White (Warm White)
Wavelength/Color Temperature	3000 K	2850 K	-	2850 K
Luminous Flux/Radiant Flux	93.9 lm	93.9 lm	-	107 lm
Color Rendering Index - CRI	80	80	-	80
Viewing Angle	140 deg	140 deg	-	140 deg
Lens Color/Style	Tinted, Clear	Tinted, Clear	-	Tinted, Clear
If - Forward Current	44 mA	44 mA	-	44 mA
Vf - Forward Voltage	22.5 V	22.5 V	-	22.5 V
Power Rating	5 W	5 W	-	5 W
Mounting Style	SMD/SMT	SMD/SMT	-	SMD/SMT
Length	2.45 mm	2.45 mm	-	2.45 mm
Width	2.45 mm	2.45 mm	-	2.45 mm
Height	2.45 mm	2.45 mm	-	2.45 mm
Packaging	Cut Tape	Reel	-	Cut Tape
Color Temperature	3000 K	2850 K	-	2850 K
LED Size	2.45 mm x 2.45 mm x 1.8 mm	2.45 mm x 2.45 mm x 1.8 mm	-	2.45 mm x 2.45 mm x 1.8 mm
Lens Dimensions	2.4 mm x 2.4 mm	2.4 mm x 2.4 mm	-	2.4 mm x 2.4 mm
Lens Shape	Square	Square	-	Square
Factory Pack Quantity	1000	1000	-	1000
Type	XLamp XB-G HighVoltage White LEDs	XLamp XB-G HighVoltage White LEDs	-	XLamp XB-G HighVoltage White LEDs
Vr - Reverse Voltage	5 V	5 V	-	5 V
