PRODUCT DATASHEET
Crystal series
last update 1/12/2016
DETAILS
Product Number
Family
Type
Color
Diameter
Height
Style
Optic Material
Holder Material
Fastening
Status
ROHS Compliant
Date Updated
production ready
Yes
1/12/2016
F12916_CRYSTAL-RS
Crystal
Lens
clear
46,8 mm
27,4 mm
round
PMMA
OPTICAL PROPERTIES
Viewing
LED
XP-E
XP-G
LUXEON A
NVSxx19B/NVSxx19C
LH351Z
LH351B
Angle
3.3 deg
4.9 deg
5.1 deg
5.3 deg
4.4 deg
5.3 deg
Light
Beam
Real spot
Real spot
Real spot
Real spot
Real spot
Real spot
Effi-
ciency
93 %
89 %
89 %
89 %
90 %
90 %
cd/lm
106.000
68.290
58.900
42.500
77.000
57.030
Connector
-
-
-
-
-
-
December 5th 2017 14:53 Copyright Ledil Oy - Subject to change without prior notice - Page 1/1
Ledil Oy
Salorankatu 10
24240 SALO, Finland
http://www.ledil.com
email: ledil@ledil.com
FAX: +358-2-733 8001
Relative intensity of CN13552_CRYSTAL-RS_(Luxeon_A)
100%
75%
50%
25%
0%
61
56
51
46
41
36
31
26
0-180
21
16
11
6
1
Relative intensity of CN13552_CRYSTAL-RS_(NVSxx19B)
100%
75%
50%
25%
0%
30
25
20
15
10
5
0
1
-5
-10
-15
-20
-25
-30
Relative intensity of C12916_CRYSTAL-RS_(LH351Z)
100%
75%
50%
25%
0%
30
25
20
15
10
5
0
-5
1: 0-180
-10
-15
-20
-25
-30
Relative intensity of C12916_CRYSTAL-RS_(LH351B)
100%
75%
50%
25%
0%
30
25
20
15
10
5
0
-5
-10
-15
-20
-25
-30
