ELSW-J71C3-0CPGS-D6500 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> ELSW-J71C3-0CPGS-D6500

ELSW-J71C3-0CPGS-D6500: DescriptionHigh Power LEDs - White Cool White 6500K; CategoryLED optoelectronic/LED photoelectric; File Size1MB，35 Pages; ManufacturerEVERLIGHT; Websitehttp://www.everlight.com/; Environmental Compliance

Download Datasheet Parametric View All

ELSW-J71C3-0CPGS-D6500 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ELSW-J71C3-0CPGS-D6500	-	-	View	Buy Now

ELSW-J71C3-0CPGS-D6500 Overview

High Power LEDs - White Cool White 6500K

ELSW-J71C3-0CPGS-D6500 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	EVERLIGHT
package instruction	ROHS COMPLIANT, SMD, 2 PIN
Reach Compliance Code	compliant
color	COOL WHITE
Configuration	SINGLE WITH BUILT-IN ZENER DIODE
Maximum forward current	0.75 A
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	2.03 mm
method of packing	TAPE AND REEL 7\"
shape	ROUND
size	2.37 mm
surface mount	YES
perspective	100 deg

Preview

Download Datasheet

View All

Shwo

3W Series

爍

Introduction

The Shwo series is a surface-mount high-power device

featuring high brightness combined with a compact size

that is suitable for all kinds of lighting applications such as

general illumination, flash, spot, signal, industrial and

commercial lighting. The thermal pad of this device is

“Shwo [Shuo] is the English translation for the Chinese word meaning Twinkle and is

often used as a description of stars or other bright, celestial objects as seen from

Earth. This word is a relevant description for this bright, compact Everlight LED

package.”

electrically isolated providing convenience in thermal and electrical design. The Shwo series

is one of the most promising devices in Everlight’s high power product offering and is ready

to face the challenges of today’s Solid-State Lighting requirements.

Features

Small package with high efficiency

ESD protection up to 8KV

Soldering method: SMT

Binning Parameters: Brightness, Forward

Voltage ,Wavelength and Chromaticity

Moisture Sensitivity Level: 1

RoHS compliant

Matches ANSI binning

Reliability testing conforms to IESNA LM80

Lumen maintenance test method

Applications

General Lighting

Decorative and Entertainment Lighting

Signal and Symbol Luminaries for

orientation marker lights (e.g. steps, exit

ways, etc.)

Exterior and Interior Automotive

Illumination

www.everlight.com

DATASHEET

SMD HP Shwo

3W Series

Table of Contents

Absolute Maximum Ratings ............................................................................................. 4

JEDEC Moisture Sensitivity ............................................................................................. 4

Luminous Flux Characteristics for the Shwo series.......................................................... 5

PN of the Shwo series: White LEDs ................................................................................. 6

PN of the Shwo series: Color LEDs ................................................................................. 7

Product Binning ................................................................................................................ 9

White Bin Structure ........................................................................................................ 10

Color Bins ...................................................................................................................... 16

Optical Characteristics ................................................................................................... 17

Mechanical Dimension ................................................................................................... 18

Pad Configuration .......................................................................................................... 19

Reflow Soldering Characteristics ................................................................................... 20

Wavelength Characteristics............................................................................................ 21

Typical Light Output Characteristic V.S. Thermal Pad Temperature ............................... 23

Typical Electrical Characteristics .................................................................................... 24

Typical Relative Luminous Flux V.S. Forward Current ................................................... 25

Relative Flux and Forward Voltage V.S. Junction Temperature ...................................... 29

Emitter Tape Packaging ................................................................................................. 32

Emitter Reel Packaging .................................................................................................. 33

Product Labeling ............................................................................................................ 33

Storage Conditions ......................................................................................................... 34

Revision History ............................................................................................................. 35

www.everlight.com

Recommended Resources

Positive and negative DC regulated power supply circuit

Directly started motor automatic mutual switching circuit a

BTL150W power amplifier circuit

TV tuner circuit

MAX866 typical working circuit diagram

2.5M frequency multiplier circuit
