MTGEZW-01-0000-0B00J050F datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> MTGEZW-01-0000-0B00J050F

MTGEZW-01-0000-0B00J050F: DescriptionLED Lighting Lenses Cree MT-G Lens 26.5 Degrees; CategoryLED optoelectronic/LED; File Size1MB，18 Pages; ManufacturerCree; Websitehttp://www.cree.com/

Download Datasheet Parametric View All

MTGEZW-01-0000-0B00J050F Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MTGEZW-01-0000-0B00J050F	-	-	View	Buy Now

MTGEZW-01-0000-0B00J050F Overview

LED Lighting Lenses Cree MT-G Lens 26.5 Degrees

MTGEZW-01-0000-0B00J050F Parametric

Parameter Name	Attribute value
Product Category	High Power LEDs - White
Manufacturer	Cree
RoHS	Details
Package / Case	SMD-2
Illumination Color	White (Cool White)
Wavelength/Color Temperature	5000 K
Luminous Intensity	-
Luminous Flux/Radiant Flux	600 lm
Color Rendering Index - CRI	75
Viewing Angle	120 deg
Lens Color/Style	Clear
If - Forward Current	1100 mA
Vf - Forward Voltage	6 V
Power Rating	25 W
Mounting Style	SMD/SMT
Length	8.9 mm
Width	8.9 mm
Height	4.85 mm
Maximum Operating Temperature	-
Minimum Operating Temperature	-
Packaging	Reel
Color Temperature	5000 K
Features	-
LED Size	8.9 mm x 8.9 mm x 4.85 mm
Lens Dimensions	8.2 mm
Lens Shape	Dome
Factory Pack Quantity	100
Type	XLamp MT-G EasyWhite LEDs
Vr - Reverse Voltage	5 V

Preview

Download Datasheet

View All

CLD-DS36 Rev 9G

Product family data sheet

Cree

XLamp

MT-G EasyWhite

LEDs

ProDuCT DEsCriPTion

The XLamp

MT-G easyWhite

LeD

maximizes lumen density, eliminates

chromaticity

binning

and

enables

luminaire and bulb manufacturers to

deliver consistent color and high‑efficacy

light output in a new, compact, multi-die

package. XLamp MT-G easyWhite LeDs

can reduce LeD-to-LeD color variation

to within a 2-step MacAdam ellipse,

94% smaller than the total area of the

corresponding ANSI C78.377 color region.

The XLamp MT-G easyWhite LeD is the

perfect choice for lighting applications

where high luminous flux output is

required from a single, small point source.

example

applications

include:

LeD

retrofit bulbs, commercial/retail display

spotlights, and other indoor general

illumination applications.

FEATurEs

•

Cree easyWhite color temperatures

from 2700 K to 5000 K CCT

Wide range of operating power - up

to 25 W

85 °C binning and characterization

Two voltage options: 6 V, 36 V

Low effective thermal resistance:

1.5 °C/W

High lumen density

Wide viewing angle: 120°

80‑minimum CRI at 2700 K and

3000 K CCT

85‑ and 90‑minimum CRI available in

2700 K and 3000 K CCT

electrically neutral thermal path

RoHS and ReACh compliant

UL recognized component

(e349212)

TAbLE oF ConTEnTs

Characteristics ....................................... 2

Flux Characteristics, easyWhite

Order

Codes and Bins ‑ 6 V

.............................. 3

Flux Characteristics, easyWhite

Order

Codes and Bins ‑ 36 V

............................

Relative Spectral Power Distribution .... 7

Relative Luminous Flux vs. Junction

Temperature ........................................... 7

electrical Characteristics ....................... 8

Relative Luminous Flux vs. Current....... 9

Typical Spatial Distribution.................. 10

Performance Groups – Brightness ..... 10

Performance Groups – Chromaticity.. 11

Cree easyWhite

Color Temperatures

Plotted on the 1931 CIe Curve ............ 12

Bin and Order Code Formats ............... 12

Reflow Soldering Characteristics

........ 13

Notes .................................................... 14

Mechanical Dimensions ...................... 16

Tape and Reel ....................................... 17

Packaging ............................................. 18

APPLiCATions

•

MR, PAR and other directional retrofit

bulbs

Commercial/residential directional

lighting

General illumination

WWW.CREE.Com/XLAmp

•

, XLamp

and

EasyWhite

are registered trademarks and the Cree logo is a trademark of Cree, Inc. UL

and the UR logo are registered trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300
