1.555
[39.50 ]
.980
[24.89 ]
-
REVISIONS
P
LTR
DESCRIPTION
DATE
DWN
APVD
C1
C2
C3
C4
REVISED PER ECO-14-010107
REVISED PER ECO-16-006331
REVISED PER ECO-16-009536
REVISED PER ECO-16-011652
03JUL2014
24MAR2016
24JUN2016
05AUG2016
JA
VNB
JA
JA
DM
DM
DM
DM
D
FLANGE SEAL
1013-006-1206
D
PIN SPACER
.175
[4.45 ]
1.388
[35.26 ]
.876
[22.25 ]
.062 .002
[1.56 0.05 ]
.610
[15.49 ]
C
2.331
[59.21 ]
C
1.597
[40.56 ]
.691
[17.54 ]
1.941
[49.30 ]
.525
[13.34 ] .875
[22.23 ]
1.381
[35.08 ]
1.701
[43.21 ]
PIN 1
PIN 1
HOUSING
.122
[3.10 ]
BLIND HOLE
#6-19 SCREW
2X
.160
[4.06 ]
.450
[11.43 ]
3X
n.110 THRU
[2.79 ]
#4-20 SCREW
.122
[3.10 ]
1.519
[38.58 ]
.250
[6.35 ]
.153
[3.89 ]
.210
[5.33 ]
B
7. SEE SHEET 2 FOR OTHER KEY ARRANGEMENTS.
6. MOUNTING SCREW TORQUE VALUES ARE AS FOLLOWS:
#6-19 SCREWS: 11-15 IN-LB [1.24-1.70 N-m].
#4-20 SCREWS: 6-10 IN-LB [.68-1.13 N-m].
VALUES VALID FOR PLASTITE 48 SCREWS ONLY.
B
TE INTERNAL PN
DT13-12PA
DT13-12PB
DT13-12PC
DWN
CHK
DEUTSCH PN
DT13-12PA
DT13-12PB
DT13-12PC
DT13-12PD
TE Connectivity
5. RECOMMENDED MOUNTING SCREWS (NOT INCLUDED): CAMCAR PLASTITE 48, SINGLE HELIX.
4. THIS RECEPTACLE MATES WITH DT06-12SX PLUG (X = A,B,C,D KEYS, XXXX = ALL
3. CONTACT PLATING - MATING SIDE: NICKEL; PCB SIDE: TIN
2
MATERIALS:
HOUSING/PIN SPACER: PA46 GF30 (SEE SHEET 2 FOR COLORS)
FLANGE SEAL: VMQ (RED-ORANGE)
PIN CONTACTS: COPPER ALLOY
DIMENSION TOLERANCE: # .025 [.64]
PANEL CUTOUT: # .010 [.25]
PIN LOCATIONS: # .005 [.13]
MOUNTING HOLE LOCATIONS: # .010 [.13]
THIS DRAWING IS A CONTROLLED DOCUMENT.
MODIFICATIONS).
P.BURKE
06JUN2001
NAME
DT13-12PD
DIMENSIONS:
INCHES[mm]
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
A
1
0
1
2
3
4
MATERIAL
ANGLES
PLC
PLC
PLC
PLC
PLC
03JUL2014
KEVIN MCKEE
APVD
03JUL2014
DAVID MEYER
PRODUCT SPEC
APPLICATION SPEC
1
-
0°30'0"
-
NOTES:
1470-19 (3/11)
-
FINISH
WEIGHT
-
2
41g # 10%
CUSTOMER DRAWING
A3
4AFU8
SIZE
CAGE CODE
RECEPTACLE HEADER
12 PIN 90 DEG
DT SERIES
DRAWING NO
A
RESTRICTED TO
DT13-12PX
SCALE
3:2
SHEET
1
OF
2
REV
-
C4
