LPX120 Enclosure
(2X)M3 INSERT
Rev. 7.9.09_160
LPX120 Enclosure
1 of 2
0.980
Installation Notes
LPX120 • Cover Enclosure Kit
[ 24,9 ]
0.802
[ 20,4
LPX120 will fit the LPS12X power supplies.
]
OUTPUT TERMINALS
INPUT TERMINALS
2.945
[ 74,8 ]
1.457
[ 37,0 ]
INSULATOR
4.685
[ 119,0
]
Materials
1.693
[ 43,0 ]
(2X)
(2X)
(2X)
A
• 1 Base
• 1 Cover
2.677
[ 68,0 ]
(2X)
• 4 M3x6mm Pan head
0.591 ]
GROUND STUD
[ 15,0
screws with spring washer
ÿ0.35(ÿ8.8)
ÿ0.14(ÿ3.6)
3.727
[ 94,7 ]
• 4 M3x6mm countersunk
Installation Instructions and Notes
2.283
screws
[ 58,0 ]
0.25(6.4)
1. Place the insulator over the chassis as shown.
• 1 M4 nut
(2X) KEYWAY DETAIL
2. Place the power supply over the insulator as shown.
• 1 M4 star washer
3. Align the 4x power supply to the chassis standoff.
• 1 M4 spring washer
A
4. Secure 4 pan head screws with washer provided with in kit as shown.
• 1 Plastic insulator sheet
2.205
1.724
[ 43,8 ]
[ 56,0 ]
A
(4X)STANDOFF
A
(4X)M3 INSERT
MARKED"A"
SEE KEYWAY DETAILS
Place the cover over the power supply as shown.
Align the 4x cover to the U-bracket countersink holes.
Secure 4 countersink screws provided with in kit as shown.
Overall dimensions: 5.95 (151.13) x 3.4 (86.36) x 1.6 (40.64).
Base plate has two sets of customer mountings:
a. Bottom mounting (4X) M3 inserts. Max. screw penetration 0.0787 (2mm)
b. Side mounting (4X) M3 inserts. Max. screw penetration 0.236 (6mm)
NOTES
10. Ensure insulator is correctly fitted in base under PCB to maintain safety creepage
and clearances.
1. All dimensions are in inches(mm)
MATERIALS
2. Overall dimensions
11. Ensure base
1 Base
is firmly connected to supply earth via the earth stud marked
4.685(119.0) x 2.945(74.8) x 1.693(43.0)
3. Base plate has three sets of customer mountings:
1 Cover
12. When using
4 M3X6mm Pan head screws with spring washer
that relevant safety standards (e.g. EN60950) are complied
this enclosure, ensure
a. Bottom mounting(4X)M3 inserts. Max. screw penetration 0.0787(2mm)
b. Bottom mounting(2X)4mm clear holes plus 2 keyways.(see keyway
4 M3X6mm
creepage
with, in respect to
Countersunk screws
and clearance distances, and distances
screw penetration 0.236(6mm) detail)
c. Side mountings(4X)M3 inserts. Max.
through insulation.
1 M4 nut
4. Ensure insulator is correctly fitted in base under PCBto maintain safety
1 M4
13. All dimensions
star washer
inches (mm)
are in
creepage and clearances.
1 M4 spring washer
1 Plastic insulator sheet
6. When using this enclosure, ensure that relevant safety standards
(e.g.,EN60950)are complied with, in respect to creepage and clearance
distances, and distances through insulation.
5.
6.
7.
8.
9.
Embedded Power for
Business-Critical Continuity
Mechanical Drawing
