Plug-In Outlet
®
Center Units
Plug-In Outlet Center
®
Units
Wiremold
®
Plug-In Outlet Center Units bring power
safely and conveniently to wherever you need it. These
units are ideal for use in a wide variety of settings,
including relay racks and cabinets, laboratories,
workshops, classrooms and offices.
Plug-In Outlet Center Units include rack mount,
Cabinet-MATE, compact, 90 degree, deluxe control,
industrial, and international units. Most units are
available in both 15 and 20 Amp configurations.
Wiremold also offers extensive custom capabilities
for Plug-In Outlet Center Units. Contact the factory for
more information.
J08B0B (Front & Back)
UL207BC
J06BOB20X-AM (Front)
P6
FEATURES & BENEFITS
■
User-ready outlets.
Plug-In Outlet Center units provide
power distribution in a portable, plug-in unit.
■
Rugged construction.
Durable 2" x 1 3/4" [44mm x 51mm]
or 3 1/2" x 2" [89mm x 44mm] aluminum housing. Some
Plug-In Outlet Center units are available with an impact-
resistant plastic housing.
■
Space saving.
Rack mount units fit standard 19" [482mm]
relay racks. Compact 1U design takes up minimum space.
23" [584mm] units available, consult factory.
■
Low profile.
CabinetMATE units offer a narrow 1 1/2"
x 1 3/16" [38mm x 20mm] aluminum housing.
■
Aesthetically pleasing.
Rack mount units have a black
matte finish and a black cord. CabinetMATE, compact
and industrial units have a gray finish and a black cord.
Deluxe control and 20A units have a putty white finish
and a black cord. Most units with a putty white finish
have a putty white cord. Special Use units have a
white finish and a white cord.
■
Flexible mounting.
Each unit features one of four
different mounting types. Each mounting method has
been designed to optimize the performance of the
product. Complete mounting hardware and installation
instructions are included with every unit.
■
Cord properly rated to load requirements.
15A units
have a 14/3 SJT cord and a NEMA 5-15P plug. 20A
units have a 12/3 SJT cord and a NEMA 5-20P or
NEMA L5-20P plug.
■
Lighted switch.
Most units have lighted on/off
switch(es) to control power to the unit.
■
Resettable circuit breaker.
Provides overload protection.
■
Two-Year product warranty.
■
UL and cUL Listed or Recognized.
Units are UL and cUL
Listed to UL1363 standards. Rack mount units are UL and
cUL Recognized to UL1363 standards.
ED795 R10 – Updated February 2013 – For latest specs visit www.legrand.us/wiremold
15A Rack Mount Plug-In Outlet Centers Ordering Information
Catalog No./Item
J08B0B
J08B2B
Description/Specifications
Rack Mount Plug-In Outlet
Center –
Eight rear outlets, lighted
switch. Receptacles rotated 90° and
4 outlets spaced to accommodate
transformers. 6' [1.8m] (J08B0B) or
15' [4.6m] (J08B2B) cord. Receptacle
center-to-center 1 1/2" [38mm] and
2" [51mm].
q c
Catalog No./Item
J60B0B
J60B2B
Description/Specifications
Rack Mount Plug-In Outlet
Center –
Six front outlets, lighted
switch. 6' [1.8m] (J60B0B) or 15'
[4.6m] (J60B2B) cord. Receptacle
center-to-center1 1/2" [38mm].
J60B0B-90
J60B2B-90
J06B0B
J06B2B
Rack Mount Plug-In Outlet
Center –
Six rear outlets, lighted
switch. 6' [1.8m] (J06B0B) or 15'
[4.6m] (J08B2B) cord. Receptacle
center-to-center1 1/2" [38mm].
J24B0B
J24B2B
Rack Mount Plug-In Outlet
Center –
Six front outlets, lighted
switch. Receptacles rotated 90°.
6' [1.8m] (J60B0B-90) or 15' [4.6m]
(J60B2B-90) cord. Receptacle
center-to-center 1 1/2" [38mm].
J06B0BX
J06B2BX
Rack Mount Plug-In Outlet
Center –
Six rear outlets. 6' [1.8m]
(J06B0BX)or 15' [4.6m] (J06B2B)
cord. Receptacle center-to-center
1 1/2" [38mm].
Rack Mount Plug-In Outlet
Center –
Two front, four rear outlets.
Lighted switch. 6' [1.8m] (J24B0B) or
15' [4.6m] (J24B2 B)cord. Receptacle
center-to-center 1 1/2" [38mm].
20A Rack Mount Plug-In Outlet Centers Ordering Information
Catalog No./Item
J06B0B20
J06B2B20
Description/Specifications
Rack Mount Plug-In Outlet
Center –
Six 20A rear outlets,
on/off switch. 6' [1.8m] (J06B0B20)
or 15' [4.6m] (J06B2B20) cord.
Receptacle center-to-center
1 1/2" [38mm].
Catalog No./Item
J60B0B20
J60B2B20
Description/Specifications
Rack Mount Plug-In Outlet
Center –
Six 20A front outlets,
on/off switch. 6' [1.8m] (J60B0B20)
or 15' [4.6m] (J60B2B20) cord.
Receptacle center-to-center
1 1/2" [38mm].
J06B0B20X
J06B2B20X
Rack Mount Plug-In Outlet
Center –
Six 20A rear outlets.
6' [1.8m] (J08B0B20X) or 15' [4.6m]
(J06B0B20X) cord. Receptacle
center-to-center 1 1/2" [38mm].
J60B0B20X
J60B2B20X
Rack Mount Plug-In Outlet
Center –
Six 20A front outlets.
6' [1.8m] (J60B0B20X) or 15' [4.6m]
(J60B2B20X) cord. Receptacle
center-to-center 1 1/2" [38mm].
J06B0B20X-AM
Rack Mount Plug-In Outlet
Center with Digital Ammeter –
Digital LCD readout of current
draw. Six 20A rear outlets. 6'
[1.8m] cord. Receptacle center-
to-center 1 1/2"[38mm].
J60B0B (Front & Back)
J24B0B (Front & Back)
2
J06B0B20X (Front & Back)
15A CabinetMATE Plug-In Outlet Centers Ordering Information
Catalog No./Item
3609ULBC
3609ULBD
Description/Specifications
CabinetMATE Plug-In Outlet
Center –
Nine outlets. 6' [1.8m]
(3609ULBC) or 15' [4.6m]
(3609ULBD) cord. Length 36"
[914mm]. Receptacle center-to-
center 3" [76mm].
j
4810ULBC
4810ULBD
CabinetMATE Plug-In Outlet
Center –
Ten outlets. 6' [1.8m]
(4810ULBC) or 15' [4.6m]
(4810ULBD)cord. Length 48"
[1.2m]. Receptacle center-to-
center 4" [102mm].
j
7011ULBC
7011ULBD
CabinetMATE Plug-In Outlet
Center –
Eleven outlets. 6' [1.8m]
(7011ULBC) or 15' [4.6m]
(7011ULBD) cord. Length 70"
[1.8m]. Receptacle center-to-
center 6" [152mm].
j
7712ULBC
7712ULBD
CabinetMATE Plug-In Outlet
Center –
Twelve outlets. 6' [1.8m]
(7712ULBC) or 15' [4.6m]
(7712ULBD) cord. Length 77" [2m].
Receptacle center-to-center
6" [152mm].
j
4810ULBC/
4810ULBD
3609ULBC/
3609ULBD
7011ULBC/
7011ULBD
7712ULBC/
7712ULBD
3
20A CabinetMATE Plug-In Outlet Centers Ordering Information
Catalog No./Item
2008ULBC20R
2008ULBD20R
2008ULBC20R-TL*
2008ULBD20R-TL*
Description/Specifications
CabinetMATE Plug-In Outlet
Center –
Eight 20A outlets with
t-slots. 6' [1.8m] (2008ULBC20R,
2008ULBC20R-TL) or 15' [4.6m]
(2008ULBD20R, 2008ULBD20R-TL)
cord. Length 20" [508mm].
Receptacle center-to-center 1 1/4"
[32mm]. Units available with straight
blade or NEMA L5-20P locking plug.
j
4810ULBC20R
4810ULBD20R
4810ULBC20R-TL*
4810ULBD20R-TL*
CabinetMATE Plug-In Outlet
Center –
Ten 20A outlets with
t-slots. 6' [1.8m] (4810ULBC20R,
4810ULBC20R-TL) or 15' [4.6m]
(4810ULBD20R, 4810ULBD20R-TL)
cord.Length 48" [1.2m]. Receptacle
center-to-center 4" [102mm].
Units available with straight blade
or NEMA L5-20P locking plug.
j
2008ULBC20R/
2008ULBD20R
7011ULBC20R
7011ULBD20R
7011ULBC20R-TL*
7011ULBD20R-TL*
CabinetMATE Plug-In Outlet
Center –
Eleven 20A outlets with
t-slots. 6' [1.8m] (7011ULBC20R,
7011ULBC20R-TL) or 15' [4.6m]
(7011ULBD20R, 7011ULBD20R-TL)
cord. Length 70" [1.6m]. Receptacle
center-to-center 6" [152mm].
Units available with straight blade
or NEMA L5-20P locking plug.
j
4810ULBC20R/
4810ULBD20R
7712ULBC20R
7712ULBD20R
7712ULBC20R-TL*
7712ULBD20R-TL*
CabinetMATE Plug-In Outlet
Center –
Twelve 20A outlets with.
t-slots. 6' [1.8m] (7712ULBC20R,
7712ULBC20R-TL) or 15' [4.6m]
(7712ULBD20R, 7712ULBD20R-TL)
cord. Length 77" [2m]. Receptacle
center-to-center 6" [152mm].
Units available with straight blade
or NEMA L5-20P locking plug.
j
7011ULBC20R/
7011ULBD20R
* Use “TL” suffix with Catalog Number for locking plug.
7712ULBC20R/
7712ULBD20R
20A NEMA L5-20P Locking Plug
4
Compact Plug-In Outlet Centers Ordering Information
Catalog No./Item
UL100BC
UL100BD
Description/Specifications
Compact Plug-In Outlet Center –
Five outlets, 6' [1.8m] (UL100BC) or
15' [4.6m] (UL100BD)cord. Length
9 1/4" [235mm]. Receptacle center-
to-center 1 1/4" [32mm].
Catalog No./Item
UL207BC
UL207BD
Description/Specifications
Compact Plug-In Outlet Center –
Six outlets, lighted switch. 6' [1.8m]
(UL207BC) or 15' [4.6m] (UL207BD)
cord. Length 12 1/4" [311mm].
Receptacle center-to-center
1 1/4" [32mm].
Compact Plug-In Outlet Center –
Eight outlets, lighted switch. 6'
[1.8m] (UL218BC) or 15' [4.6m]
(UL218BD)cord. Length 15"
[381mm]. Receptacle center-to-
center 1 1/4" [32mm].
j
UL101BC
UL101BD
Compact Plug-In Outlet Center –
Four outlets, 6' [1.8m] (UL101BC) or
15' [4.6m] (UL101BD) cord. Length
9 1/4" [235mm].Receptacle center-
to-center1 1/4" [32mm].
j
UL218BC
UL218BD
j
UL104BC
UL104BD
Compact Plug-In Outlet Center –
Four outlets, lighted switch. 6' [1.8m]
(UL104BC) or 15' [4.6m] (104BD)
cord. Length 9 1/4" [235mm].
Receptacle center-to-
center 1 1/4" [32mm].
Compact Plug-In Outlet Center –
Seven outlets, lighted switch.
6' [1.8m] (UL204BC) or 15' [4.6m]
(UL204BD) cord. Length 13"
[330mm]. Receptacle center-to-
center 1 1/4" [32mm].
j
UL210BC
UL210BD
j
UL204BC
UL204BD
Compact Plug-In Outlet Center –
Ten outlets, lighted switch.Putty
white finish. 6' [1.8m] (UL210BC) or 15'
[4.6m] (UL210BD) cord. Length 13"
[330mm]. Width 3 1/2" [89mm].
Receptacle center-to-center
1 15/16" [49mm].
j
UL1090BC
UL1090BD
j
UL205BC
UL205BD
Compact Plug-In Outlet Center –
Eight outlets, 6' [1.8m] (UL205BC) or
15' [4.6m] (UL205BD)cord. Length
13" [330mm].Receptacle center-to-
center 1 1/4" [32mm].
Compact Plug-In Outlet Center –
Four outlets. Receptacles rotated 90°
and spaced to accommodate trans-
formers. 6' [1.8m] (UL1090BC) or 15'
[4.6m] (UL1090BD) cord. Length 16"
[406mm]. Receptacle center-to-center
3" [76mm].
Compact Plug-In Outlet Center –
Six outlets, lighted switch.Putty
white finish, 6' [1.8m] (R610) or 15'
[4.6m] (R612) cord. Length 12 1/4"
[311mm]. Receptacle center-to-
center 1 1/4" [32mm].
j
j
R610/R612
UL206BC
UL206BD
Compact Plug-In Outlet Center –
Six outlets. 6' [1.8m] (UL206BC) or
15' [4.6m] (UL206BD)cord. Length
12 1/4" [311mm].Receptacle center-
to-center 1 1/4" [32mm].
j
j
P6/P6-15
Compact Plug-In Outlet Center –
Six outlets, lighted switch.Putty
white finish, plastic housing. 6' [1.8m]
or 15' [4.6m] cord. Length 12"
[305mm]. Receptacle center-to-
center 1 1/4" [32mm].
u c
5
