LAST TIME BUY: AUGUST 31, 2014. CLICK HERE FOR OBSOLESCENCE NOTICE OF FEBRUARY 2014.
www.murata-ps.com
DSM/DWR Models
Dual Output, 3.3V and 5V, 15Watt DC/DC Converters
FEATURES
Regulated
5
V
and
3.3V
outputs
5V
Watts total output
po
wer
15
tot
al
t
power
o
@ 2.65Amps/3.3V @ 3 Amps
ca
pability
5V
2.65A
mps/3.3V
A
capability
a
x
2"
SMT
or
through
-hole
packa
ge
1"
T
through-hole package
h
a
Available
input
voltage
ranges:
10-18V, 18-36V or 36-75V
18-
36V
36-7
5V
-
7
No-load stable operation
UL/EN60950-1 safety approvals
mark available (75V-input models)
Continuous short-circuit protection
isolated, 1500Vdc guaranteed
Fully
to +100°C operating temperature
–40
under and overvoltage shutdown
Input
Output OVP, thermal shutdown
NOT RECOMMENDED
FOR NEW DESIGNS
PRODUCT OVERVIEW
Typical units
For surface mount or through-hole applications requiring 15 Watts of power from 5V and 3.3V, DATEL
offers a new power sharing DC/DC converter capable of meeting your output current requirements. The
DSM/DWR series is available with three different input voltage ranges: 36-75V input (D48), 18-36V input
(D24) or 10-18V input (D12). These converters are fully isolated and capable of delivering any combina-
tion of 5V and 3.3V output current up to a combined total of 15 Watts of output power.
Housed in 1" x 2" metal packages coated with electrically non-conductive finish, DSM/DWR convert-
ers are regulated by a 3.3V control loop that provides load regulation of ±0.5% for 3.3V output and
±1.5% for 5V output.
All models include input filtering, input overvoltage and undervoltage shutdown circuitry, output short-
circuit and current-limiting protection, and thermal shutdown. All models provide trim capability and an
on/off control function. Fully synchronous output rectification provides high efficiency (86%) and a stable
output under no-load conditions.
DSM/DWR power sharing modules offer low output ripple and noise performance, 1500 Vdc isolation
voltage, and are fully specified for –40 to +100°C operation. These devices meet IEC950, UL1950 and
EN60950-1 safety standards. "D48" models are CE marked (meets LVD requirements).
SIMPLIFIED SCHEMATIC
+INPUT
(1)
+5V OUTPUT
(5)
SWITCH
CONTROL
+3.3V OUTPUT
(8)
–INPUT
(2)
ON/OFF
CONTROL
(3)
PWM
CONTROLLER
OUTPUT
RETURN
(7)
OPTO
ISOLATION
UV & OV
COMPARATORS
THERMAL
SHUTDOWN
REFERENCE &
ERROR AMP
TRIM
(9)
Figure 1. Simplified Schematic
Typical topology is shown.
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com/support
MDC_DSM/DWR Models.C01
Page 1 of 9
DSM/DWR Models
Dual Output, 3.3V and 5V, 15Watt DC/DC Converters
Performance Specifications and Ordering Guide
➀
V
OUT
(Volts)
5
3.3
5
3.3
5
3.3
Model
OBSOLETE
OBSOLETE
I
OUT
➁
(Amps)
2.65
3
2.65
3
2.65
3
Output
R/N (mVp-p)
➂
Typ.
40
60
40
60
40
60
Input
Regulation (Max.)
Line
±1%
±0.5%
±1%
±0.5%
±1%
±0.5%
Max.
75
100
75
100
75
100
Load
➃
±1.5%
±0.5%
±1.5%
±0.5%
±1.5%
±0.5%
V
IN
Nom.
(Volts)
12
24
48
Range
(Volts)
10-18
18-36
36-75
I
IN
➄
(mA)
60/1450
35/730
20/370
Efficiency
Min.
83%
83%
83%
Typ.
86%
85%
85%
Package
(Case,
Pinout)
C18A, P36
C34, P36
C18A, P36
C34, P36
C18A, P36
C34, P36
*
*
*
*
DSM-5/2.65-3.3/3-D12-C
DWR-5/2.65-3.3/3-D12-C
DSM-5/2.65-3.3/3-D24-C
DWR-5/2.65-3.3/3-D24-C
DSM-5/2.65-3.3/3-D48-C
DWR-5/2.65-3.3/3-D48-C
OBSOLETE
OBSOLETE
➀
Typical at T
A
= +25°C under nominal line voltage and balanced "full-load" conditions (5V @ 1.5A/3.3V @ 2.25A).
➁
Any combination of 5V/3.3V rated I
OUT
current, not to exceed 15 Watts of output power. (See derating graphs.)
➂
Ripple/Noise (R/N) measured over a 20MHz bandwidth. All models are specified with 0.47µF ceramic
in parallel with 100µF tantalum output capacitors.
➃
Tested from 250mA to 100% full load (other output at 250mA load).
➄
Nominal line voltage, no load/balanced full-power condition.
HERE FOR OBSOLESCENCE NOTICE OF FEBRUARY 2014.
*
LAST TIME BUY: AUGUST 31, 2014. CLICKpart numbers will be available: DSM-5/2.65-3.3/3-D24-C;
As of September 2014, ONLY the following
DSM-5/2.65-3.3/3-D24L1-C; DWR-5/2.65-3.3/3-D24-C.
PART NUMBER STRUCTURE
DSM
-
5
/
2.65
-
3.3
/
3
-
D48 LX
-
C
Dual Output:
DSM: Surface-Mount Series
➁
(Selective soldering only)
DWR: Through-Hole Series
V
1
Nominal Output Voltage:
5 Volts
I
1
Maximum Output Current:
2.65 Amps
V
2
Nominal Output Voltage:
3.3 Volts
RoHS-6 compliant
See Optional Functions
Input Voltage Range:
D12
= 10-18 Volts (12V nominal)
D24
= 18-36 Volts (24V nominal)
D48
= 36-75 Volts (48V nominal)
I
2
Maximum Output Current:
3 Amps
Optional Functions
DSM/DWR 15 Watt DC/DC's are designed with an On/Off Control
function, with positive polarity in the pin 3 position.
DWR➀
Blank
= On/Off Control function (positive polarity) on pin 3 only
models
}
L1
= Pin length: 0.110 inches (2.79mm) ±0.010
L2
= Pin length: 0.145 inches (3.68mm) ±0.010
➀
Special quantity order is required; samples available with
standard pin length only.
➁
SMT (M) versions not available in sample quantities.
➂
Some model number combinations may not be available. See
website or contact your local Murata sales representative.
MECHANICAL SPECIFICATIONS
I/O Connections
Pin
1
2
3
4
5
6
7
8
9
Function P36
+Input
–Input
On/Off Control
Case
+5V Output
NC
Output Return
+3.3V Output
Trim
0.100
(2.54)
4
3
0.500
(12.70) 0.300
(7.62)
2
1
TOP VIEW
9
0.110
(2.79)
2.00 ±0.03
(50.80)
Case C18A
DSM Models
8
7
6
5
0.800
(20.32)
1.00
±0.03
4 EQ. SP. @
(25.40)
0.200 (5.08)
0.45
(11.43)
Case C34
DWR Models
METAL CASE
INSULATED PAD
0.040 ±0.001 DIA.
(1.016 ±0.025)
1.800
(45.72)
1
0.300
(7.62)
0.015
(0.38)
2
3
4
0.200
(5.08)
5
6
7
8
9
BOTTOM VIEW
0.800 (20.32)
1.00
±0.03
4 EQ. SP. @
(25.40)
0.200 (10.16)
0.20 MIN
(5.08)
0.10
(2.54)
2.00
±0.03
(50.80)
0.110
(2.79)
0.060
(1.52)
0.10
(2.54)
Dimensions are in inches (mm) shown for ref. only.
Third Angle Projection
0.52
(13.21)
INSULATED BASE
METAL CASE
0.015
(0.38)
0.055
(1.40)
0.10
(2.54)
Tolerances (unless otherwise specified):
.XX ± 0.02 (0.5)
.XXX ± 0.010 (0.25)
Angles ± 2˚
Components are shown for reference only.
www.murata-ps.com/support
MDC_DSM/DWR Models.C01
Page 2 of 9
DSM/DWR Models
Dual Output, 3.3V and 5V, 15Watt DC/DC Converters
Performance/Functional Specifications
Typical @ T
A
= +25°C under nominal line voltage, balanced "full-load" conditions, unless noted.
➀
Input
Input Voltage Range:
D12 Models
D24 Models
D48 Models
Overvoltage Shutdown:
D12 Models
D24 Models
D48 Models
Start-Up Threshold:
D12 Models
D24 Models
D48 Models
Undervoltage Shutdown:
D12 Models
D24 Models
D48 Models
Input Current:
Normal Operating Conditions
Standby Mode:
Off, OV, UV, Thermal Shutdown
Input Reflected Ripple Current
➇
Internal Input Filter:
Capacitive
D12 Models
D24 Models
D48 Models
Reverse-Polarity Protection:
D12 Models
D24 Models
D48 Models
On/Off Control:
(Pin 3):
➂ ➄
10-18 Volts (12V nominal)
18-36 Volts (24V nominal)
36-75 Volts (48V nominal)
18.5-21 Volts (19V typical)
37-40 Volts (38.5V typical)
77-81 Volts (79.5V typical)
9.4-10 Volts (9.6V typical)
16.5-18 Volts (17V typical)
34-36 Volts (35V typical)
7.0-8.5 Volts (8V typical)
15.5-17.5 Volts (16.5V typical)
32.5-35.5 Volts (33.5V typical)
See Ordering Guide
10mA
10mAp-p
10µF
3.3µF
1.5µF
1 minute duration, 3A maximum
1 minute duration, 2A maximum
1 minute duration, 1A maximum
On = open or to +15V,
I
IN
@ 13V = 800µA
Off = 0 to 0.8V, I
IN
@ 0V = 2mA
Short Circuit Current:
5V Output
3.3V Output
Maximum Capacitive Loading
Temperature Coefficient
Output (continued)
5.5 Amps average, continuous current
3 Amps average, continuous current
330µF per output
±0.02% per °C
Dynamic Characteristics
Dynamic Load Response:
➁
5V (50-100% step to 98% V
OUT
)
3.3V (50-100% step to 98.5% V
OUT
)
Start-Up Time:
V
IN
to V
OUT
On/Off to V
OUT
Switching Frequency
MTBF:
➅
D12 Models
D24 Models
D48 Models
Operating Temperature:
(Ambient):
➁
Without Derating:
With Derating
Case Temperature:
Maximum Operational
For Thermal Shutdown
Storage Temperature
Dimensions
Internal Case Connection
Case Material
200µsec maximum (3.3V @ 0.25A)
200µsec maximum (5V @ 0.25A)
10msec
10msec
260kHz (±25kHz)
Environmental
TBD hours
2.1 million hours
2.4 million hours
–40 to +60°C
To +100°C (See Derating Curves)
+100°C
101°C minimum, 115°C maximum
–40 to +120°C
Physical
See Mechanical Specifications
Case connection via pin 4
Corrosion resistant steel with
non-conductive, epoxy-based, black
enamel finish and plastic baseplate
Gold-plate copper alloy pins or tin-plate
copper alloy SMT contacts
1.6 ounces (46 grams)
Output
V
OUT
Accuracy:
5V Output
3.3V Output
Minimum Load For Stability
Ripple/Noise
(20MHz BW)
➃
Line/Load Regulation
Efficiency
Cross Regulation:
5V Output
(5V@1.5A, 3.3V@0.25-2.25A)
3.3V Output
(3.3V@2.25A, 5V@0.25-1.5A)
Trim Range
➁
Isolation Voltage:
Input-to-Output
Input-to-Case
Output-to-Case
Isolation Capacitance
Isolation Resistance
Current Limit Inception:
5V @ 95% V
OUT
(3.3V @ 0.25A)
3.3V @ 97% V
OUT
(5V @ 0.25A)
Pin Material
±2.5% maximum
±1.5% maximum
No load
See Ordering Guide
See Ordering Guide
See Ordering Guide / Efficiency Curves
Weight
Minimum Loading Per Specification
➆
250mA
Primary to Secondary Insulation Level
Operational
±2%
±0.5%
±5%
1500Vdc minimum
1000Vdc minimum
1000Vdc minimum
560pF
100MΩ
3.3-4 Amps
4.7-5.7 Amps
➀
Balanced "full-load" is 5V @ 1.5A/3.3V @ 2.25A. All models are specified with external
0.47µF ceramic and 100µF tantalum output capacitors.
➁
See Technical Notes/Graphs for details.
➂
Applying a voltage to On/Off Control (pin 3) when no input power is applied to the
converter can cause permanent damage.
➃
Output noise may be further reduced with the installation of additional external output
capacitors. See Technical Notes.
➄
On/Off control is designed to be driven with open collector or by appropriate voltage
levels. Voltages must be referenced to the –Input (Pin 2).
➅
Demonstrated MTBF available on request.
➆
For conditions with less than minimum loading, outputs remain stable. However, regulation
performance will degrade.
➇
Input Ripple Current is tested/specified over a 5-20MHz bandwidth with an external 22µF
input capacitor and a simulated source impedance of 220µF and 12µH. See I/O Filtering,
Input Ripple Current and Output Noise for details.
www.murata-ps.com/support
MDC_DSM/DWR Models.C01
Page 3 of 9
DSM/DWR Models
Dual Output, 3.3V and 5V, 15Watt DC/DC Converters
Absolute Maximum Ratings
Input Voltage:
Continuous:
D12 Models
D24 Models
D48 Models
Transient (100msec): D12 Models
D24 Models
D48 Models
21 Volts
40 Volts
81 Volts
25 Volts
50 Volts
100 Volts
Input Current must be limited. 1 minute
duration. Fusing recommended.
3 Amps
2 Amps
1 Amps
Current limited. Devices can withstand
an indefinite output short circuit.
+15V
–40 to +120°C
+300°C
D48 models). Once operating, devices will not turn off until the input voltage
drops below the Undervoltage Shutdown limit (34V for D48 models). Subse-
quent re-start will not occur until the input is brought back up to the Start-Up
Threshold. This built in hysteresis prevents any unstable on/off situations from
occurring at a single input voltage.
Input voltages exceeding the input overvoltage shutdown specification listed
in the Performance/Functional Specifications will cause the device to shut-
down. A built-in hysteresis of 0.6 to 1.6 Volts for all models will not allow the
converter to restart until the input voltage is sufficiently reduced.
Start-Up Time
The V
IN
to V
OUT
start-up time is the interval of time where the input voltage
crosses the turn-on threshold point, and the fully loaded output voltage enters
and remains within its specified accuracy band. Actual measured times will
vary with input source impedance, external input/output capacitance, and
the slew rate of the input voltages. The XWR 15 Watt Series implements a
soft start circuit that limits the duty cycle of the PWM controller at power up,
thereby limiting the Input Inrush current.
The On/Off Control to V
OUT
start-up time assumes the converter has its
nominal input voltage applied but is turned off via the On/Off Control pin. The
specification defines the interval between the time at which the converter is
turned on and the fully loaded output voltage enters and remains within its
specified accuracy band. Similar to the V
IN
to V
OUT
start-up, the On/Off Control
to V
OUT
start-up time is also governed by the internal soft start circuitry and
external load capacitance.
On/Off Control
The On/Off Control (pin 3) may be used for remote on/off operation. As shown
in Figure 1, the control pin is referenced to the –Input (pin 2) and will be inter-
nally pulled to a high state. The XWR Series is designed so that it is enabled
when the control pin is left open (pulled high) and disabled when the control
pin is pulled low (less than +0.8V relative to –Input).
Dynamic control of the on/off function is best accomplished with a mechani-
cal relay or an open-collector/open-drain circuit (optically isolated if appropri-
ate). The drive circuit should be able to sink approximately 1 mA for logic low.
The on/off control function is designed such that the converter can be
disabled while the input power is ramping up, and then “released” once the
input has stabilized.
Input Reverse-Polarity Protection:
➁
D12 Models
D24 Models
D48 Models
Output Current
➁
On/Off Control (Pin 3) Max. Voltages:
Referenced to –Input (pin 2)
Storage Temperature
Lead Temperature
(Soldering, 10 sec.)
These are stress ratings. Exposure of devices to greater than any of these conditions may
adversely affect long-term reliability. Proper operation under conditions other than those
listed in the Performance/Functional Specifications Table is not implied, nor recommended.
TECHNICAL NOTES
Isolation / Case Connection
The XWR Series’ 5V and 3.3V outputs (pins 5 & 8) with its common return (pin
7) are isolated from the +V
IN
and –V
IN
inputs (pins 1 & 2) via a transformer
and an opto-coupled transistor.
The DC/DC converter’s case is internally connected to pin 4. This allows
circuit specific grounding of the case on either the input or the output side, or
leaving the case disconnected, i.e. “floating.”
Input Fusing
Certain applications and/or safety agencies may require the installation of
fuses at the inputs of power conversion components. Fuses should also be
used if the possibility of a sustained, non-current-limited, input-voltage polar-
ity reversal exists. For XWR 15 Watt Series Converters, it is recommended to
install slow blow fuses with values no greater than the following, in the +Input
line.
V
IN
Range
D12 Models
D24 Models
D48 Models
Fuse Value
3 Amps
2 Amps
1 Amps
+Vcc
13V CIRCUIT
3
ON/OFF
CONTROL
5V CIRCUIT
Input Reverse-Polarity Protection
Upon applying a reverse-polarity voltage to the DC/DC converter, an internal
diode will be forward biased, drawing excessive current from the power
source. Therefore, it is required that the input current be limited by either an
appropriately rated input fuse or a current limited power source.
Input Overvoltage/Undervoltage Shutdown and Start-Up Threshold
Under normal start-up conditions, devices will not begin to regulate until the
ramping-up input voltage exceeds the Start-Up Threshold Voltage (35V for
2
–INPUT
Figure 2. Internal On/Off Control circuitry
www.murata-ps.com/support
MDC_DSM/DWR Models.C01
Page 4 of 9
DSM/DWR Models
Dual Output, 3.3V and 5V, 15Watt DC/DC Converters
5V & 3.3V Regulation
The XWR Series converters are designed such that both the 5V and 3.3V out-
puts share a common regulation feedback control loop. Though the feedback
loop is influenced by both outputs, the 3.3 Volt output is dominant. As a result,
the 3.3 Volt regulation (0.5%) is superior to the 5 Volt regulation (1.5%).
The converters are specified for load regulation of minimum (250mA) to 100%
loading. All models are stable under no-load conditions, but operation below
minimum load mandates an increase in the regulation tolerance of ±0.5% for
3.3 Volt output and an increase of ±1% for the 5 Volt output. A slight increase
in switching noise may also be observed for operation below minimum load-
ing. Operation with a full load on 3.3 Volt output and light to no load on 5 Volt
output is the most demanding for +5V regulation.
Filtering and Noise Reduction
The XWR Series Converters achieve their rated ripple and noise specifica-
tions with the use of 0.47µF ceramic in parallel with 100µF tantalum output
capacitors. In critical applications, input/output noise may be further reduced
by installing additional external I/O capacitors. Input capacitors should be
selected for bulk capacitance, low ESR and high rms-ripple-current ratings.
Output capacitors should be selected for low ESR and appropriate frequency
response. All caps should have appropriate voltage ratings and be located as
close to the converter as possible.
Thermal Shutdown
These XWR converters are equipped with Thermal Shutdown Circuitry. If
the internal temperature of the DC/DC converter rises above the designed
operating temperature, a precision temperature sensor will power down the
unit. When the internal temperature decreases below the threshold of the
temperature sensor, the units will self start.
Current Limiting
When power demands from either output fall within 120% to 190% of the
rated output current, the DC/DC converter will go into a current limiting mode.
In this condition, both output voltages will decrease proportionately with
increases in output current, thereby maintaining a somewhat constant power
dissipation.
This is commonly referred to as power limiting. Current limit inception is
defined as the point where the full-power output voltage falls below the
specified tolerance. If the load current being drawn from the converter is
significant enough, the unit will go into a short circuit condition. See “Short
Circuit Condition.”
Short Circuit Condition
3
Trimming Output Voltages
The DSM/DWR converters have a trim capability (pin 9) that allow users
to adjust the output voltages ±5%. A trim adjustment will cause an equal
percentage of change in both outputs. Adjustments to the output voltages can
be accomplished via a trim pot, Figure 3, or a single fixed resistor as shown
in Figures 4 and 5. A single fixed resistor can increase or decrease the output
voltage depending on its connection. Fixed resistors should have absolute TCR's
less than 100ppm/°C to minimize sensitivity to changes in temperature.
A single resistor connected from the Trim pin (pin 9) to the +3.3V Output (pin 8),
see Figure 4, will decrease the output voltages. A resistor connected from the
Trim pin (pin 9) to Output Return (pin 7) will increase the output voltages.
Trim adjustments greater than 5% can have an adverse effect on the con-
verter's performance and is not recommended.
1
+INPUT
2
–INPUT
3
4
CASE
TRIM
9
ON/OFF
CONTROL
+3.3V OUTPUT
+5V OUTPUT
5
+5V LOAD
OUTPUT
RETURN
7
20kΩ
5-22
Turns
+3.3V LOAD
8
Figure 3. Trim Connections Using A Trimpot
5
+5V LOAD
–INPUT
3
4
CASE
TRIM
9
R TRIM
DOWN
ON/OFF
CONTROL
+3.3V OUTPUT
OUTPUT
RETURN
7
+3.3V LOAD
8
1
+INPUT
2
+5V OUTPUT
R
T
DOWN
(kΩ) =
2.49(V
O
– 1.234)
3.3 – V
O
–14
Figure 4. Decrease Output Voltage Trim Connections
Using A Fixed Resistor
1
+INPUT
2
–INPUT
ON/OFF
CONTROL
+5V OUTPUT
5
+5V LOAD
OUTPUT
RETURN
7
+3.3V LOAD
When a converter is in current limit mode the output voltages will drop as
the output current demand increases. If the output voltage drops too low, the
magnetically coupled voltage used to develop primary side voltages will also
drop, thereby shutting down the PWM controller.
Following a time-out period of 5 to 15 milliseconds, the PWM will restart,
causing the output voltages to begin ramping to their appropriate values. If
the short-circuit condition persists, another shutdown cycle will be initi-
ated. This on/off cycling is referred to as “hiccup” mode. The hiccup cycling
reduces the average output current, thereby preventing internal temperatures
from rising to excessive levels. The modules are capable of enduring an
indefinite short circuit output condition.
4
CASE
+3.3V OUTPUT
TRIM
8
9
R TRIM
UP
R
T
UP
(kΩ) =
3.073
V
O
– 3.3
–14
Figure 5. Increase Output Voltage Trim Connections
Using A Fixed Resistor
Accuracy of adjustment is subject to tolerances or resistor values and factory-
adjusted output accuracy. V
O
= desired output voltage.
www.murata-ps.com/support
MDC_DSM/DWR Models.C01
Page 5 of 9
PCB Design
京公网安备 11010802033920号
EEWORLD
