ALUMINUM ELECTROLYTIC CAPACITORS
UPV
Miniature Sized, Low Impedance,
High Reliability
Miniature sized low impedance series withstanding 5000 hours load life at +105°C.
Compliant to the RoHS directive (2011/65/EU).
UPJ
Long Life
UPV
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
Performance Characteristics
–55 to +105°C
6.3 to 50V
1.5 to 390µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage at 20°C, leakage current is not more than 0.03CV or 4 (µA), whichever is greater.
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
tan
δ
(MAX.)
6.3
0.22
10
0.19
6.3
5
16
0.16
10
5
25
0.14
16
4
35
0.12
25
3
50
0.10
35
3
50
2
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio ZT / Z20 (MAX.)
Z– 55°C / Z+20°C
Endurance
The specifications listed at right shall be met when
the capacitors are restored to 20°C after the rated
voltage is applied for 5000 hours at 105°C.
After storing the capacitors under no load at
105˚C for 1000 hours and then performing voltage
treatment based on JIS C 5101-4 clause 4.1 at
20°C, they shall meet the specified values for the
endurance characteristics listed at right.
Printed with white color letter on dark brown sleeve.
Capacitance change
tan
δ
Leakage current
Capacitance change
tan
δ
Leakage current
Within ± 30% of the initial capacitance value
300% or less than the initial specified value
Less than or equal to the initial specified value
Within ± 20% of the initial capacitance value
150% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
Radial Lead Type
Type numbering system (Example : 25V 47µF)
1
2
3
4
5
6
7
8
9 10
11
Sleeve (P.E.T.)
U P V 1 E 4 7 0 MGD
φd
Configuration
φD
+0.5 MAX.
Capacitance tolerance (±20%)
P
±0.5
Rated capacitance (47µF)
Rated voltage (25V)
Series name
(φ6.3up )
Pressure
relief vent
Type
L
+1.5 MAX.
15
MIN
4
MIN
(mm)
Configuration
φ
D
5
6.3 ,8
Pb-free leadwire
Pb-free PET sleeve
φD
P
φd
5
2.0
0.5
6.3
2.5
0.5
8
3.5
0.6
FD
GD
•
Please refer to page 20 about the end seal configuration.
• Frequency coefficient of
rated ripple current
(10kHz to 200kHz=1)
390
220
150
100
68
47
Cap.( F)
33
22
15
10
1.5
0
120Hz
300Hz
1kHz
0.5
0.6
0.7
0.8
0.9
1.0
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
Frequency coefficient
Dimension table in next page.
238
ALUMINUM ELECTROLYTIC CAPACITORS
UPV
Dimensions
V(Code)
6.3 (0J)
10 (1A)
16 (1C)
25 (1E)
Item
Co
Cap.(µF)
de
Case size Impedance Rated ripple
Case size Impedance Rated ripple
Case size Impedance Rated ripple
Case size Impedance Rated ripple
(Ω) MAX.
(Ω) MAX.
(Ω) MAX.
(Ω) MAX.
(mArms)
(mArms)
(mArms)
(mArms)
φ
D
×
L
φ
D
×
L
φ
D
×
L
φ
D
×
L
(mm)
(mm)
(mm)
(mm)
20°C/100kHz 105°C/100kHz
20°C/100kHz 105°C/100kHz
20°C/100kHz 105°C/100kHz
20°C/100kHz 105°C/100kHz
33
39
47
56
68
82
100
120
150
180
220
270
330
390
330
390
470
560
680
820
101
121
151
181
221
271
331
391
5
×
11
5
×
11
6.3
×
11...
6.3
×
11...
6.3
×
11...
...8
×
11.5
...8
×
11.5
...8
×
11.5
1.50
1.10
0.83
0.66
0.51
0.41
0.34
0.29
150
175
225
250
285
370
405
445
5
×
11
5
×
11
6.3
×
11...
6.3
×
11...
6.3
×
11...
6.3
×
11...
...8
×
11.5
...8
×
11.5
...8
×
11.5
1.40
1.10
0.94
0.75
0.60
0.49
0.41
0.34
0.27
155
175
210
235
265
290
370
405
460
5
×
11
5
×
11
6.3
×
11...
6.3
×
11...
6.3
×
11...
6.3
×
11...
...8
×
11.5
...8
×
11.5
...8
×
11.5
1.40
1.10
0.85
0.71
0.60
0.49
0.39
0.34
0.27
155
175
220
240
265
290
375
405
460
5
×
11
5
×
11
6.3
×
11...
6.3
×
11...
6.3
×
11...
6.3
×
11...
...8
×
11.5
...8
×
11.5
...8
×
11.5
1.40
1.10
0.94
0.75
0.61
0.51
0.41
0.34
0.27
155
175
210
235
260
285
370
405
460
V(Code)
35 (1V)
50 (1H)
Item
Co
Cap.(µF)
de
Case size Impedance Rated ripple
Case size Impedance Rated ripple
(Ω) MAX.
(Ω) MAX.
(mArms)
(mArms)
φ
D
×
L
φ
D
×
L
(mm)
(mm)
20°C/100kHz 105°C/100kHz
20°C/100kHz 105°C/100kHz
1.5
2.2
3.3
4.7
6.8
10.....
12.....
15.....
18.....
22.....
27.....
33.....
39.....
47.....
56.....
68.....
82.....
100.......
1R5
2R2
3R3
4R7
6R8
100
120
150
180
220
270
330
390
470
560
680
820
101
5
×
11
5
×
11
6.3
×
11...
6.3
×
11...
6.3
×
11...
6.3
×
11...
...8
×
11.5
...8
×
11.5
...8
×
11.5
1.30
1.00
0.83
0.70
0.58
0.48
0.41
0.32
0.27
160
180
225
245
270
295
370
415
460
5
×
11
5
×
11
5
×
11
5
×
11
5
×
11
5
×
11
5
×
11
5
×
11
5
×
11
6.3
×
11...
6.3
×
11...
6.3
×
11...
6.3
×
11...
...8
×
11.5
...8
×
11.5
...8
×
11.5
11.0....
7.00
4.60
3.10
2.50
2.00
1.70
1.30
1.10
0.91
0.74
0.60
0.50
0.42
0.35
0.28
..45
..54
..66
..81
..91
115
125
145
155
195
215
240
260
330
360
410
239
