Low Skew, 1-to-4 LVCMOS/LVTTL
Fanout Buffer
8304AMLN - PDN CQ-16-01 - LAST TIME BUY EXPIRES MAY 6, 2017
8304
DATA SHEET
G
ENERAL
D
ESCRIPTION
The 8304 is a low skew, 1-to-4 Fanout Buffer. The 8304 is
characterized at full 3.3V for input (V
DD
), and mixed 3.3V and 2.5V
for output operating supply modes (V
DDO
). Guaranteed output and
part-to-part skew characteristics make the 8304 ideal for those
clock distribution applications demanding well defined performance
and repeatability.
F
EATURES
•
Four LVCMOS / LVTTL outputs
•
LVCMOS / LVTTL clock input
•
CLK can accept the following input levels: LVCMOS, LVTTL
•
Maximum output frequency: 200MHz
•
Additive phase jitter, RMS: 0.173ps (typical) @ 3.3V
•
Output skew: 45ps (maximum) @ 3.3V
•
Part-to-part skew: 500ps (maximum)
•
Small 8 lead SOIC package saves board space
•
3.3V input, outputs may be either 3.3V or 2.5V supply modes
•
0°C to 70°C ambient operating temperature
•
Available in lead-free (RoHS 6) compliant package
B
LOCK
D
IAGRAM
Q0
Q1
CLK
Pulldown
Q2
P
IN
A
SSIGNMENT
V
DDO
V
DD
CLK
GND
1
2
3
4
8
7
6
5
Q3
Q2
Q1
Q0
8304
8-Lead SOIC
3.9mm x 4.9mm, x 1.375mm package body
M Package
Top View
Q3
8304 REVISION H 11/19/15
1
©2015 Integrated Device Technology, Inc.
8304 DATA SHEET
T
ABLE
1. P
IN
D
ESCRIPTIONS
Number
1
2
3
4
5
6
7
8
Name
V
DDO
V
DD
CLK
GND
Q0
Q1
Q2
Q3
Power
Power
Input
Power
Output
Output
Output
Output
Type
Description
Output supply pin.
Positive supply pin.
Pulldown LVCMOS / LVTTL clock input.
Power supply ground.
Single clock output. LVCMOS / LVTTL interface levels.
Single clock output. LVCMOS / LVTTL interface levels.
Single clock output. LVCMOS / LVTTL interface levels.
Single clock output. LVCMOS / LVTTL interface levels.
NOTE:
Pulldown
refers to internal input resistors. See Table 2, Pin Characteristics, for typical values.
T
ABLE
2. P
IN
C
HARACTERISTICS
Symbol
C
IN
C
PD
R
PULLDOWN
R
OUT
Parameter
Input Capacitance
Power Dissipation Capacitance
(per output)
Input Pulldown Resistor
Output Impedance
5
V
DD
, V
DDO
= 3.465V
51
7
12
Test Conditions
Minimum
Typical
4
15
Maximum
Units
pF
pF
kΩ
Ω
LOW SKEW, 1-TO-4 LVCMOS/LVTTL
FANOUT BUFFER
2
REVISION H 11/19/15
8304 DATA SHEET
A
BSOLUTE
M
AXIMUM
R
ATINGS
Supply Voltage, V
DD
Inputs, V
I
Outputs, V
O
Package Thermal Impedance,
θ
JA
Storage Temperature, T
STG
4.6V
-0.5V to V
DD
+ 0.5 V
-0.5V to V
DDO
+ 0.5V
112.7°C/W (0 lfpm)
-65°C to 150°C
N OT E : S t r e s s e s b eyo n d t h o s e l i s t e d u n d e r A b s o l u t e
Maximum Ratings may cause permanent damage to the
device. These ratings are stress specifications only. Functional
operation of product at these conditions or any conditions beyond
those listed in the
DC Characteristics
or
AC Characteristics
is not
implied. Exposure to absolute maximum rating conditions for ex-
tended periods may affect product reliability.
T
ABLE
3A. P
OWER
S
UPPLY
DC C
HARACTERISTICS
,
V
DD
= V
DDO
= 3.3V±5%, T
A
= 0°C
TO
70°C
Symbol
V
DD
V
DDO
I
DD
I
DDO
Parameter
Power Supply Voltage
Output Power Supply Voltage
Power Supply Current
Output Supply Current
Test Conditions
Minimum
3.135
3.135
Typical
3.3
3.3
Maximum
3.465
3.465
15
8
Units
V
V
mA
mA
T
ABLE
3B. P
OWER
S
UPPLY
DC C
HARACTERISTICS
,
V
DD
= 3.3V±5%, V
DDO
= 2.5V±5%, T
A
= 0°C
TO
70°C
Symbol
V
DD
V
DDO
I
DD
I
DDO
Parameter
Positive Supply Voltage
Output Supply Voltage
Power Supply Current
Output Supply Current
Test Conditions
Minimum
3.135
2.375
Typical
3.3
2.5
Maximum
3.465
2.625
15
8
Units
V
V
mA
mA
T
ABLE
3C. LVCMOS / LVTTL DC C
HARACTERISTICS
,
V
DD
= V
DDO
= 3.3V±5%, T
A
= 0°C
TO
70°C
Symbol
V
IH
V
IL
I
IH
I
IL
V
OH
Parameter
Input High Voltage
Input Low Voltage
Input High Current
Input Low Current
Output High Voltage
V
DD
= V
IN
= 3.465V
V
DD
= 3.465V, V
IN
= 0V
Refer to NOTE 1
I
OH
= -16mA
I
OH
= -100uA
Refer to NOTE 1
V
OL
Output Low Voltage
I
OL
= 16mA
I
OL
= 100uA
Ω
Test Conditions
Minimum
2
-0.3
-5
2.6
2.9
3
Typical
Maximum
V
DD
+ 0.3
1.3
150
Units
V
V
µA
µA
V
V
V
0.5
0.25
0.15
V
V
V
NOTE 1: Outputs terminated with 50 to V
DDO
/2. See Parameter Measurement Section, “3.3V Output Load Test Circuit”.
REVISION H 11/19/15
3
LOW SKEW, 1-TO-4 LVCMOS/LVTTL
FANOUT BUFFER
8304 DATA SHEET
T
ABLE
3D. LVCMOS / LVTTL DC C
HARACTERISTICS
,
V
DD
= 3.3V±5%, V
DDO
= 2.5V±5%, T
A
= 0°C
TO
70°C
Symbol
V
IH
V
IL
I
IH
I
IL
V
OH
V
OL
Parameter
Input High Voltage
Input Low Voltage
Input High Current
Input Low Current
Output High Voltage; NOTE 1
Output Low Voltage; NOTE 1
Ω
Test Conditions
Minimum
2
-0.3
Typical
Maximum
V
DD
+ 0.3
1.3
150
Units
V
V
µA
µA
V
V
DD
= V
IN
= 3.465V
V
DD
= 3.465V, V
IN
= 0V
-5
2.1
0.5
V
NOTE 1: Outputs terminated with 50 to V
DDO
/2. See Parameter Measurement Section,
“3.3V/2.5V Output Load Test Circuit”.
T
ABLE
4A. AC C
HARACTERISTICS
,
V
DD
= V
DDO
= 3.3V±5%, T
A
= 0°C
TO
70°C
Symbol
f
MAX
tp
LH
tjit
tsk(o)
tsk(pp)
t
R
t
F
odc
Parameter
Maximum Output Frequency
Propagation Delay, Low-to-High;
NOTE 1
Buffer Additive Phase Jitter, RMS;
refer to Additive Phase Jitter Section
Output Skew; NOTE 2, 4
Part-to-Part Skew; NOTE 3, 4
Output Rise Time
Output Fall Time
Output Duty Cycle
30% to 70%
30% to 70%
f
≤
189.5MHz
250
250
40
ƒ
≤
166MHz
166MHz < f
≤
189.5MHz
125MHz, Integration Range:
12kHz – 20MHz
ƒ = 133MHz
2.0
2.0
0.173
45
500
500
500
60
Test Conditions
Minimum
Typical
Maximum
200
3.3
3.4
Units
MHz
ns
ns
ps
ps
ps
ps
ps
%
All parameters measured at f
MAX
unless noted otherwise.
NOTE 1: Measured from V
DD
/2 of the input to V
DDO
/2 of the output.
NOTE 2: Defined as skew between outputs at the same supply voltage and with equal load conditions.
Measured at V
DDO
/2.
NOTE 3: Defined as skew between outputs on different devices operating at the same supply voltages
and with equal load conditions. Using the same type of inputs on each device, the outputs are measured
at V
DDO
/2.
NOTE 4: This parameter is defined in accordance with JEDEC Standard 65.
T
ABLE
4B. AC C
HARACTERISTICS
,
V
DD
= 3.3V±5%, V
DDO
= 2.5V±5%, T
A
= 0°C
TO
70°C
Symbol
f
MAX
tp
LH
tsk(o)
tsk(pp)
t
R
t
F
odc
Parameter
Maximum Output Frequency
Propagation Delay, Low-to-High; NOTE 1
Output Skew; NOTE 2, 4
Part-to-Part Skew; NOTE 3, 4
Output Rise Time
Output Fall Time
Output Duty Cycle
30% to 70%
30% to 70%
f
≤
189.5MHz
250
250
40
ƒ
≤
166MHz
166MHz < f
≤
189.5MHz
ƒ = 133MHz
2.3
2.15
Test Conditions
Minimum
Typical
Maximum
189.5
3.7
3.55
60
500
500
500
60
Units
MHz
ns
ns
ps
ps
ps
ps
%
For NOTES, please see above Table 4A.
LOW SKEW, 1-TO-4 LVCMOS/LVTTL
FANOUT BUFFER
4
REVISION H 11/19/15
8304 DATA SHEET
A
DDITIVE
P
HASE
J
ITTER
The spectral purity in a band at a specific offset from the fundamental
compared to the power of the fundamental is called the
dBc Phase
Noise.
This value is normally expressed using a Phase noise plot
and is most often the specified plot in many applications. Phase
noise is defined as the ratio of the noise power present in a 1Hz
band at a specified offset from the fundamental frequency to the
power value of the fundamental. This ratio is expressed in decibels
(dBm) or a ratio of the power in the 1Hz band to the power in the
fundamental. When the required offset is specified, the phase noise
is called a
dBc
value, which simply means dBm at a specified offset
from the fundamental. By investigating jitter in the frequency domain,
we get a better understanding of its effects on the desired application
over the entire time record of the signal. It is mathematically possible
to calculate an expected bit error rate given a phase noise plot.
Additive Phase Jitter
@ 125MHz
(12kHz to 20MHz) = 0.173ps typical
SSB P
HASE
N
OISE
dBc/H
Z
O
FFSET
F
ROM
C
ARRIER
F
REQUENCY
(H
Z
)
As with most timing specifications, phase noise measurements has
issues. The primary issue relates to the limitations of the equipment.
Often the noise floor of the equipment is higher than the noise floor
of the device. This is illustrated above. The device meets the noise
floor of what is shown, but can actually be lower. The phase noise
is dependant on the input source and measurement equipment.
REVISION H 11/19/15
5
LOW SKEW, 1-TO-4 LVCMOS/LVTTL
FANOUT BUFFER
