1N5243B-T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> 1N5243B-T

1N5243B-T: DescriptionZener Diodes 500mW 13V; Categorysemiconductor Discrete semiconductor; File Size394KB，5 Pages; ManufacturerMCC; Websitehttp://www.mccsemi.com

Download Datasheet Parametric Compare View All

1N5243B-T Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N5243B-T	-	-	View	Buy Now

1N5243B-T Overview

Zener Diodes 500mW 13V

1N5243B-T Parametric

Parameter Name	Attribute value
Product Category	Zener Diodes
Manufacturer	MCC
RoHS	No
Vz - Zener Voltage	13 V
Mounting Style	Through Hole
Package / Case	DO-35-2
Pd - Power Dissipation	500 mW (1/2 W)
Voltage Tolerance	20 %
Voltage Temperature Coefficient	0.079 %/C
Zz - Zener Impedance	13 Ohms
Minimum Operating Temperature	- 55 C
Maximum Operating Temperature	+ 150 C
Configuration	Single
Test Current	9.5 mA
Packaging	Cut Tape
Packaging	Reel
Packaging	MouseReel
Height	2 mm
Ir - Reverse Current	500 nA
Length	4.2 mm
Factory Pack Quantity	10000
Width	2 mm
Unit Weight	0.004833 oz

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

1N5221

THRU

1N5276

500 mW

Zener Diode

2.4 to 150 Volts

DO-35

Features

•

Wide Voltage Range Available

Glass Package

High Temp Soldering: 260°C for 10 Seconds At Terminals

Marking : Cathode band and type number

Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates

Compliant. See ordering information)

Moisture Sensitivity: Level 1 per J-STD-020C

•

Maximum Ratings

•

Operating Temperature: -55°C to +150°C

Storage Temperature: -55°C to +150°C

500 mWatt DC Power Dissipation

Power Derating: 4.0mW/°C above 50°C

Forward Voltage @ 200mA: 1.1 Volts

Figure 1 - Typical Capacitance

100

Cathode

Mark

At zero volts

At –2 Volts V

100

Typical Capacitance (pf) –

versus

– Zener voltage (V

)

Figure 2 - Derating Curve

200

400

DIMENSIONS

200

DIM

INCHES

MIN

---

1.000

MAX

.166

.079

.020

---

MIN

---

25.40

MAX

4.2

2.00

.52

---

NOTE

100

150

Temperature

°C

Power Dissipation (mW) -

Versus

- Temperature

°C

Note:

1. Lead in Glass Exemption Applied, see EU Directive Annex 5.

Revision:

www.mccsemi.com

1 of 5

2008/03/01
