Part Number

Search

D1N60-4084

Description
Rectifiers VRM=600 IFSM=30
CategoryDiscrete semiconductor    diode
File Size285KB,2 Pages
ManufacturerSHINDENGEN
Websitehttps://www.shindengen.com
Download Datasheet Parametric View All

D1N60-4084 Online Shopping

Suppliers Part Number Price MOQ In stock
D1N60-4084 - - View Buy Now

D1N60-4084 Overview

Rectifiers VRM=600 IFSM=30

D1N60-4084 Parametric

Parameter NameAttribute value
package instructionO-LALF-W2
Reach Compliance Codeunknown
ECCN codeEAR99
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JESD-30 codeO-LALF-W2
Number of components1
Number of terminals2
Maximum operating temperature150 °C
Maximum output current1 A
Package body materialGLASS
Package shapeROUND
Package formLONG FORM
Certification statusNot Qualified
Maximum repetitive peak reverse voltage600 V
surface mountNO
Terminal formWIRE
Terminal locationAXIAL
Base Number Matches1
Rectifier Diode
アキシャルダイオード
Axial Diode
D1N
600V 1A
特長
• 耐湿性に優れ高信頼性
• 高耐圧
■外観図 OUTLINE
Package:AX057
Unit : mm
Weight : 0.19g typ.)
3
*2
φ0.57
φ2.6
Feature
• High-Reliability
• High Voltage
* 捺印面展開図
  Marking
+①
②−
極性表示
Polarity
*2 仕様コー
  S½ C½
½½ ½ ½
D1N 60
5060 :52mm
5070 :26mm
D1N 20
7060 :52mm
7070 :26mm
品名略号
Type No.
V6 67
ロッ
ト記号
(例)
Date code
外½図については新電元 Web サイト又は〈半導½½品一覧表〉をご参照下
さい。捺印表示については捺印仕様をご確認下さい。
■定格表 RATINGS
項  目
Item
保存温度
Storage Temperature
接合部温度
Operation Junction Temperature
せん頭逆電圧
Maximum Reverse Voltage
出力電流
Average Rectified Forward Current
せん頭サージ順電流
Peak Surge Forward Current
電流二乗時間積
Current Squared Time
記号
条 件
Symbol Conditions
T
stg
T
j
V
RM
I
O
I
FSM
I
2
t
品 名
Type No.
D1N20
D1N60
単½
Unit
−55∼150
150
200
50Hz 正弦波,抵抗負荷,プリント基板実装,Ta = 25℃
50Hz sine wave, Resistance load, On glass-epoxy substrate, Ta = 25℃
50Hz 正弦波,非繰り返し1サイクルせん頭値,Tj = 25℃
50Hz sine wave, Non-repetitive 1cycle peak value, Tj = 25℃
1ms≦t<10ms,Tj = 25℃
600
1
30
4.5
V
A
A
A
2
s
順電圧
Forward Voltage
逆電流
Reverse Current
熱抵抗
Thermal Resistance
V
F
I
R
θjl
θja
I
F =
1A,
パルス測定
Pulse measurement
V
R =
V
RM
,
パルス測定
Pulse measurement
MAX
MAX
MAX
MAX
1.05
10
10
113
V
μA
℃/W
接合部・リード間
Junction to Lead
接合部・周囲間,プリント基板実装
Junction to Ambient, On glass-epoxy substrate
210
(J534)
