896-46-009-90-300000 datasheet, PDF

Datasheet> All Categories > The connector> The connector> 896-46-009-90-300000

896-46-009-90-300000: CategoryThe connector The connector; File Size417KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com; Environmental Compliance

Download Datasheet Parametric View All

896-46-009-90-300000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	896-46-009-90-300000	-	-	View	Buy Now

896-46-009-90-300000 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mill-Max
package instruction	ROHS AND REACH COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Connector type	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	GOLD (30)
Contact completed and terminated	Gold (Au)
Contact material	COPPER ALLOY
JESD-609 code	e4
Base Number Matches	1

Preview

Download Datasheet

View All

SOCKETS

SERIES 896, 897 • UNIVERSAL SERIAL BUS 3.0 • SOCKETS

•

USB 3.0 receptacles for through-hole mount

•

Plug retention tabs

.236

.543

•

Kinked locating legs for secure PCB retention

•

Fully shielded

•

Fully backwards compatible with USB 2.0

.492

PIN 5

.118

.650

•

10X faster than USB 2.0 and provides

.275

PIN 9

PIN 1

.202

PIN 4

.110

.276

•

optimized power efficiency

Packaged in trays:

896-46-009-90-300000 - 100 pieces per tray

897-46-009-90-300000 - 80 pieces per tray

.039 (2x)

.138 (2x)

.517

.618

.079 (2x)

.157 (2x)

.079

.138

.402

ORDERING INFORMATION

USB 3.0 Type A Receptacle, Single, Through-Hole

.079 (5x)

.101

FIG. 1

Ø.028±.002

(8 PLC)

.079

Ø.036±.004

(2 PLC)

896-46-009-90-300000

USB 3.0 Type B Receptacle, Single, Through-Hole

.059

.121

.098 (2x)

.517

FIG. 2

897-46-009-90-300000

FIG. 1

.472

.333

.112

.472

.594

.474

.335

.098

.069

.070

.079 (2x)

.150

.049 (4x)

.079

Ø.028±.002

(5 PLC)

Ø.036±.004

(4 PLC)

Ø.091±.004

(2 PLC)

.079

.107

.188

.237

3 4

.098

.049

FIG. 2

Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com

PAGE 147 | IO SOCKETS

Materials:

RoHS - 2

2011/65/EU

Terminals: Copper Alloy, Tin-Plated

Contacts: Copper Alloy, Gold Flash over PdNi

Casing and Shield: Stainless Steel

Insulator material: High temperature thermoplastic rated UL94V-0

Ratings:

Voltage: 30VAC (rms)

Current: 1.5A PWR/GND pins

All housing materials rated for “lead-free” soldering up to 260º C

Electrical:

Contact resistance: 30mW max. for power and ground pins

50mW max. for all others

Insulation resistance: 100MW min.

Dielectric withstanding voltage: 100VAC at sea level

Capacitance: 2pF max.

Mechanical:

Random vibration: No discontinuity >1μs per EIA 364-28, cond. VII, letter D

Physical shock: No discontinuity >1μs per EIA 364-27, condition H

Durability: 5000 cycles min. per EIA 364-09

Mating force: 35 Newtons max. per EIA 364-13

Unmating force: Initial - 10 Newtons min. per EIA 364-13

After test - 8 Newtons min. per EIA 364-13

Environmental:

Thermal shock per EIA 364-32, condition I

Humidity per EIA 364-31

Temperature life per EIA 364-17, method A

Solderability per EIA 364-52, category 2

Technical Specifications

.425

.406

.726

.508
