SHEET 1 OF 1
10.00
[.394 in]
7.50
[.295 in]
5.00
[.197 in]
5.00
[.197 in]
10.00
[.394 in]
2.50
[.098 in]
3
2
1
6
5
4
PCB LAYOUT
n
.90
(6)
[.035 in]
7.50
[.295 in]
ACTUATOR COLOR:
OPAQUE GREEN
7.30
[.29 in]
13.50
[.531 in]
11.60
[.457 in]
1
2
3
PUSH
4
5
6
CIRCUIT DIAGRAM
3
6
.30
[.012 in]
5.00
[.197 in]
9.00
[.354 in]
7.50
[.295 in]
DPDT (MOMENTARY)
EPOXY
SEAL
6
4
3.50
[.138 in]
5.00
[.197 in]
2.50
[.098 in]
.60
[.024 in]
6
5
4
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT RATING: CURRENT: 100mA
VOLTAGE: 30 VDC
5. OPERATING LIFE: 50,000 MAKE-AND-BREAK CYCLES
6. INSULATION RESISTANCE: 500VDC, 100 Mega-OHM. MIN.
7. OPERATING FORCE: 250 ± 100 GRAMS
8. OPERATING TEMP.: -20°C to 70°C
9. TRAVEL: MOMENTARY
1.50 ± 0.3mm FULL TRAVEL
10. CONTACT RESISTANCE: 50 Milli-OHM. MAX.
11.
DENOTES CRITICAL PARAMETER.
12. 2002/95/EC (ROHS) COMPLIANT
13. LED: NONE
3
2
1
B
19603
DRAWING UPDATE
1/19/11
4/19/10
DATE
BGL
BLR
BY
A
18992
Release For Production
TITLE
SCALE
LP4OA1PBAGN
2=1
DATE
REV
PCR NO
DESCRIPTION
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
4/19/2010
DR
BLR
DWG
B240038
REV
B
