BZX85C100-TAP

Description
Tantalum Capacitors - Solid SMD 6.3volts 1000uF 10%
CategoryDiscrete semiconductor    diode
File Size103KB,6 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

BZX85C100-TAP Online Shopping

Suppliers Part Number Price MOQ In stock
BZX85C100-TAP - - View Buy Now

BZX85C100-TAP Overview

Tantalum Capacitors - Solid SMD 6.3volts 1000uF 10%

BZX85C100-TAP Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
MakerVishay
Parts packaging codeDO-41
package instructionO-XALF-W2
Contacts2
Reach Compliance Codeunknown
ECCN codeEAR99
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeZENER DIODE
Maximum dynamic impedance350 Ω
JEDEC-95 codeDO-41
JESD-30 codeO-XALF-W2
JESD-609 codee2
Humidity sensitivity level1
Number of components1
Number of terminals2
Maximum operating temperature175 °C
Package body materialUNSPECIFIED
Package shapeROUND
Package formLONG FORM
Peak Reflow Temperature (Celsius)NOT SPECIFIED
polarityUNIDIRECTIONAL
Maximum power dissipation1.3 W
Certification statusNot Qualified
Nominal reference voltage100 V
surface mountNO
technologyZENER
Terminal surfaceTin/Silver (Sn/Ag)
Terminal formWIRE
Terminal locationAXIAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Maximum voltage tolerance4.95%
Working test current2.7 mA
Base Number Matches1
BZX85-Series
www.vishay.com
Vishay Semiconductors
Zener Diodes
FEATURES
• Silicon planar power Zener diodes
• For use in stabilizing and clipping circuits with
high power rating
• The Zener voltages are graded according to the
international E 24 standard. Replace suffix “C”
with “B” for ± 2 % tolerance
• AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
PRIMARY CHARACTERISTICS
PARAMETER
V
Z
range nom.
Test current I
ZT
V
Z
specification
Int. construction
VALUE
2.7 to 100
2.7 to 80
Pulse current
Single
UNIT
V
mA
APPLICATIONS
• Voltage stabilization
ORDERING INFORMATION
DEVICE NAME
BZX85-series
BZX85-series
ORDERING CODE
BZX85-series-TR
BZX85-series-TAP
TAPED UNITS PER REEL
5000 (52 mm tape on 13" reel)
5000 per ammopack
(52 mm tape)
MINIMUM ORDER
QUANTITY
25 000/box
25 000/box
PACKAGE
PACKAGE NAME
DO-41
WEIGHT
310 mg
MOLDING COMPOUND
FLAMMABILITY RATING
UL 94 V-0
MOISTURE SENSITIVITY
LEVEL
MSL level 1
(according J-STD-020)
SOLDERING CONDITIONS
260 °C/10 s at terminals
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Power dissipation
Zener current
Junction to ambient air
Junction temperature
Storage temperature range
TEST CONDITION
Valid provided that leads at a distance of 4 mm
from case are kept at ambient temperature
See Table “Electrical characteristics”
Valid provided that leads at a distance of 4 mm
from case are kept at ambient temperature
R
thJA
T
j
T
stg
110
175
-55 to +175
K/W
°C
°C
SYMBOL
P
tot
VALUE
1300
UNIT
mW
Rev. 2.2, 02-Jun-14
Document Number: 85607
1
