Product data sheet
Characteristics
XCKJ110513H29
limit switch XCKJ - steel roller lever - 1C/O -
snap action - M20
Main
Range of product
Series name
Product or component
type
Device short name
Sensor design
Body type
Head type
Material
Body material
Head material
Fixing mode
Movement of operating
head
Type of operator
Type of approach
Cable entry
Number of poles
Contacts type and
composition
Contacts operation
OsiSense XC
Standard format
Limit switch
XCKJ
-
Plug-in body
Rotary head
Zamak
Zamak
By the body
Rotary
Spring return roller lever metal
Lateral approach 1 or 2 programmable direction
1 entry tapped for M20 x 1.5 cable gland, cable
outer diameter: 0.28...0.51 in (7...13 mm)
1
1 C/O
Snap action
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Metal
Complementary
Switch actuation
Electrical connection
Contacts insulation form
Number of steps
Positive opening
Minimum torque for tripping
Maximum actuation speed
[Ie] rated operational current
[Ithe] conventional enclosed thermal current
[Ui] rated insulation voltage
By 30° cam
Screw-clamp terminals, clamping capacity: 1 x 0.75...2 x 1.5 mm²
Za
1
Without
2.21 lbf.in (0.25 N.m)
4.92 ft/s (1.5 m/s)
0.27 A at 250 V, DC-13, Q300 conforming to EN/IEC 60947-5-1 appendix A
3 A at 240 V, AC-15, A300 conforming to EN/IEC 60947-5-1 appendix A
10 A
300 V conforming to CSA C22.2 No 14
500 V degree of pollution 3 conforming to IEC 60947-1
300 V conforming to UL 508
<= 25 MOhm conforming to IEC 60255-7 category 3
6 kV conforming to IEC 60947-1
6 kV conforming to IEC 60664
10 A by gG cartridge fuse
5000000 cycles, DC-13, inductive load type, 48 V, 7 W, operating rate: <= 60 cyc/
mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13, inductive load type, 24 V, 10 W, operating rate: <= 60
cyc/mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13, inductive load type, 120 V, 4 W, operating rate: <= 60
cyc/mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
30000000 cycles
1.69 in (43 mm)
Resistance across terminals
[Uimp] rated impulse withstand voltage
Short circuit protection
Electrical durability
Mechanical durability
Width
Mar 1, 2016
1
Height
Depth
Product weight
Terminals description ISO n°1
3.31 in (84 mm)
1.42 in (36 mm)
1.08 lb(US) (0.49 kg)
(11-12)NC
(13-14)NO
Environment
Shock resistance
Vibration resistance
IP degree of protection
IK degree of protection
Class of protection against electric shock
Ambient air temperature for operation
Ambient air temperature for storage
Protective treatment
Product certifications
50 gn (duration = 11 ms) conforming to IEC 60068-2-27
25 gn (f = 10...500 Hz) conforming to IEC 60068-2-6
IP66 conforming to IEC 60529
IK07 conforming to EN 50102
Conforming to NF C 20-030
Conforming to IEC 61140
-13...158 °F (-25...70 °C)
-40...158 °F (-40...70 °C)
TC
CCC
CSA
UL
CENELEC EN 50041
EN 60204-1
EN 60947-5-1
IEC 60204-1
IEC 60947-5-1
UL 508
CSA C22.2 No 14
Standards
Ordering and shipping details
Category
Discount Schedule
GTIN
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
Country of origin
22411 - LIMIT SWITCHES,IEC,XCKJ
T
003389110742978
1
0.70
N
FR
Offer Sustainability
Sustainable offer status
RoHS
REACh
Product environmental profile
Product end of life instructions
Green Premium product
Compliant - since 1103 -
Available
Schneider Electric declaration of conformity
Reference not containing SVHC above the threshold
Download Product Environmental
Need no specific recycling operations
Contractual warranty
Period
18 months
