SPECIFICATIONS
PARAMETERS
RATED VOLTAGE
OPERATING VOLTAGE RANGE
RATED CURRENT (MAX)
CAPACITANCE
MIN SPL @ 1Vrms, 1cm, 1.0kHz
RESONANT FREQUENCY
OPERATING TEMPERATURE
STORAGE TEMPERATURE
HOUSING MATERIAL
TERMINAL MATERIAL
WEIGHT
VALUES
3
1 ~ 10
3
80,000 30%
103
1,000 500
-20 ~ +60
-30 ~ +70
ABS
LEAD WIRE
1.3
UNITS
Vp-p
Vp-p
mA
pF
dBA
Hz
C
C
-
-
grams
THIS DOCUMENT CONTAINS DATA PROPRIETARY TO
PROJECTS UNLIMITED, INC. ANY USE OR
REPRODUCTION, IN ANY FORM, WITHOUT PRIOR
WRITTEN PERMISSION OF PROJECTS UNLIMITED,
INC. IS PROHIBITED.
REVISION HISTORY
LTR
-
DESCRIPTION
RELEASED FROM ENGINEERING
DATE
11/30/2015
APPROVED
2003, Projects Unlimited Inc.
2
17.7
50
BLACK (-)
RED (+)
5
3
1
UL1571 AWG #36
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS.
2. SPECIFICATIONS SUBJECT TO CHANGE OR WITHDRAWL
WITHOUT NOTICE.
3. THIS PART IS RoHS 2011/65/EU COMPLIANT.
UNLESS OTHERWISE
SPECIFIED:
DIMENSIONS ARE IN
MILLIMETERS,
TOLERANCES
ARE 0.5 AND
ANGLES ARE 3 .
Designed by
Date
Checked by
Date
Approved by
Date
Drawn Date
SIZE
J.D.
11/30/2015
R.W.
11/30/2015
B.R.
11/30/2015 11/30/2015
A3
AT-1810-T-LW50-R
PIEZO RECEIVER
Edition
Sheet
AT-1810-T-LW50-R.idw
-
1/1
