8.4 W High Power Factor, Isolated Flyback LED Driver using LYTSwitch-6 (LYT6063C)
Summary and Features
-Accurate constant voltage and constant current regulation (CV/CC)
-High power factor, >0.9 at 115 V and 230 V
-Fast transient load response
-Highly energy efficient, >84 % at 115 V and 230 V
-Integrated protection and reliability features
-Output short-circuit
-Line and output OVP
-Line surge or line overvoltage
-Thermal foldback and over-temperature shutdown with hysteretic automatic power
recovery
-No damage during line brown-out or brown-in conditions
- Meets IEC 2.5 kV ring wave, 2 kV differential surge
-Meets EN55015 conducted EMI
Blockdiagram
