DER-957 - 130 W USB PD 3.1 extended power range charger using PowiGaN based InnoSwitch4-CZ, ClampZero and HiperPFS-5

DER-957 - 130 W USB PD 3.1 Extended Power Range Charger using PowiGaN-based InnoSwitch4-CZ, ClampZero and HiperPFS-5

Overview

130 W ultra-compact USB PD 3.1 charger for mobile devices and laptops featuring three innovative PowiGaN-based ICs: InnoSwitch4-CZ Active Clamp Flyback Switch IC (INN4077C-H182) ClampZero Active Clamp IC (CPZ1076M) HiperPFS-5 Power Factor Correction IC (PFS5177F) - Input: 90 VAC - 265 VAC - Variable Output: 5V/3A; 9V/3A; 15V/3A; 20V/5A; 28V/4.65A - Efficiency: >94% full load at 230 VAC - no load input: <75 mW130 W ultra-compact USB PD 3.1 charger for mobile devices and laptop computers using three innovative PowiGaN-based ICs:InnoSwitch4-CZ active clamp flyback switcher IC (INN4077C-H182) ClampZero active clamp IC (CPZ1076M)HiperPFS-5 Power Factor Correction IC (PFS5177F)- Input: 90 VAC - 265 VAC- Variable Output: 5 V / 3A; 9 V / 3 A; 15 V / 3 A; 20 V / 5 A; 28 V / 4.65 A- Efficiency: >94% full load at 230 VAC- No-load input: <75 mW

Blockdiagram

Design Files
