555DC dimming

Overview

Notice!

The project is not yet completed and will be updated continuously.
This project is for DIY and learning purposes only. Any sale, dissemination, or copying of this open source project for commercial purposes is prohibited (including modifying its frame and silk-screening it for sale).
Investigate all piracy and counterfeiting

There’s not much to say about this thing. It hasn’t been verified yet. It’s just a NE555 open-loop low-side Buck.

12~30V@15A Max

project progress

■Schematic drawing
■PCB drawing
□Project verification
□Stress test

□ Shell drawing

Design Files
