#The7thLiChuangElectricityContest#USBBasicVoltageAmperemeter

Overview

* 1. Introduction of project function:
USB voltage and current meter is made based on N32G430 MCU chip of National Technology
* 2. Project attributes:
This project is open and based on the principle diagram of #7th Lichuang Electric Competition#USB Basic Voltage and Current Meter#.
* 3. Open source agreement
GPL3.0
* 4. The hardware part
is based on the official redrawing of the PCB front and back of #7th Lichuang Electric Competition#USB Basic Voltage and
Current Meter:
the line width of the sampling resistor area should be increased, and the power supply part should be as thick as possible to increase the overvoltage and current capabilities.
The GND part has a large area of ground and a large number of vias to ensure strong overcurrent capability of the loop

* 5. The software part
quotes the official code of #7th Lichuang Electric Competition#USB Basic Voltage and Current Meter
* 6. BOM list

* 7. Competition LOGO verification

Design Files
