G4m0rvx

Analog 2.0

Overview

The design requirements are as follows: (all implemented)
(1) Input impedance >= 10MΩ;
(2) Voltage amplification factor 250 times;
(3) General heart rate signal frequency band width is 0.05-100Hz;
(4) Design the required DC power supply by yourself ;
(5) The input waveform can be clearly displayed on the oscilloscope;
(6) The circuit adopts a modular design, and the input and output of each module need to have separate test points to facilitate testing and connection.
