TTL to USB / SBUS to USB / SBUS to TTL converter

Overview

Introduction:
I noticed that the ones sold online were rather ugly, and since I was using fewer and fewer modules, I drew a simpler and nicer
functional diagram .
Figure 1 shows an inverter, which can also be used as the "Black Sheep Mod" in a racing game.
Figure 2 shows a USB to S-Bus converter; the S-Bus can be detached and used separately, resulting in a TTL to S-Bus converter and a TTL to USB converter.
Figure 3 shows a USB to TTL circuit.
The DIY
BOM cost is only a dollar or two.
