FSV20120V

Among 1 related components, FSV20120V have related pdf.

Part Number	Manufacturer	Description	Datasheet
FSV20120V	ON Semiconductor	Schottky Diodes & Rectifiers 20 Amp 120V Schottky Rectifier	Download

FSV20120V parameters：

Description

Schottky Diodes & Rectifiers 20 Amp 120V Schottky Rectifier

Parametric

Parameter Name	Attribute value
Brand Name	ON Semiconductor
Is it lead-free?	Lead free
Maker	ON Semiconductor(安森美)
Manufacturer packaging code	340BQ
Reach Compliance Code	not_compliant
ECCN code	EAR99
Factory Lead Time	15 weeks
Samacsys Description	Diode Schottky 120V 20A 3-Pin(2+Tab) TO-277 T/R
application	GENERAL PURPOSE
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.79 V
JEDEC-95 code	TO-277
JESD-30 code	R-PDSO-F3
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	270 A
Number of components	1
Phase	1
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	20 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Guideline	AEC-Q101
Maximum repetitive peak reverse voltage	120 V
Maximum reverse current	35 µA
surface mount	YES
technology	SCHOTTKY
Terminal surface	Tin (Sn)
Terminal form	FLAT
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
