SS26F

Among 17 related components, SS26F have related pdf.
Part Number Manufacturer Description Datasheet
SS26F Galaxy Microelectronics Surface Mount Schottky Barrier Rectifiers, Diodes, Single, 60V, 2A, 0.75V, 2A, 50A Download
SS26F Microdiode Semiconductor (Shenzhen) Co., Ltd. DC reverse withstand voltage (Vr): 60V Average rectified current (Io): 2A Forward voltage drop (Vf): 700mV @ 2A Download
SS26F SHIKUES DC reverse withstand voltage (Vr): 60V Average rectified current (Io): 2A Forward voltage drop (Vf): 700mV @ 2A 60V, 2A, VF=0.7V@2A Download
SS26F Shandong Jingdao Microelectronics Co.,Ltd. DC reverse withstand voltage (Vr): 20V Average rectified current (Io): 2A Forward voltage drop (Vf): 700mV @ 2A 60V 2A VF=0.7V@2A Download
SS26F YFWDIODE Surface MountSchottky Barrier Rectifier Download
SS26F SY SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER Download
SS26F Gaomi Xinghe Electronics Surface Mount Schottky Barrier Rectifier Download
SS26F BILIN Schottky Barrier Rectifiers Download
SS26F Chenda SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER Download
SS26F Nanjing International Group Co.,Ltd 2.0 AMP SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS Download
SS26F Juxing Electronic Surface Mount Schottky Rectifiers Download
SS26F-2A-60V.SMAF Nanjing International Group Co.,Ltd 2.0 AMP SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS Download
SS26FA BILIN SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS Download
SS26FL ON Semiconductor DIODE SCHOTTKY 60V 2A SOD123F Download
SS26FL Fairchild CAN Interface IC Hi Spd CAN Transceiv Download
SS26FL SHIKUES DC reverse withstand voltage (Vr): 60V Average rectified current (Io): 2A Forward voltage drop (Vf): 700mV @ 2A 60V, 2A, VF=0.52V@2A Download
SS26FL FutureWafer Surface Mount Schottky Barrier Rectifier Download
SS26F parameters:

Description

Surface Mount Schottky Barrier Rectifiers, Diodes, Single, 60V, 2A, 0.75V, 2A, 50A

Parametric
Parameter NameAttribute value
Is it Rohs certified?conform to
MakerGalaxy Microelectronics
Parts packaging codeSMAF
package instructionSMAF, 2 PIN
Reach Compliance Codeunknown
applicationGENERAL PURPOSE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.75 V
JESD-30 codeR-PDSO-F2
Maximum non-repetitive peak forward current50 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Maximum output current2 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum repetitive peak reverse voltage60 V
Maximum reverse current500 µA
surface mountYES
technologySCHOTTKY
Terminal formFLAT
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
categoryDiscrete semiconductor
VRRM (V) max60
IF (A) max2
VF (V) max0.75
Condition1_IF (A)2
IFSM (A) max50
IR (uA) max500
Condition2_VR (V)60
trr (ns) max-
AEC Qualified-
Maximum operating temperature125
Minimum operating temperature-55
MSL level-
Is it lead-free?Yes
Comply with ReachYes
RoHS compliantYes
ECCN codeEAR99
Package OutlinesSMAF
