TPS2114PW

Showing 4 Results for TPS2114PW, including TPS2114PW,TPS2114PWG4, etc. You can look for possible substitutions between devices by comparing the similarities and differences between them.

Part Number	Manufacturer	Description	Datasheet
TPS2114PW	Texas Instruments	Dual In/Single Out Autoswitching Power MUX, Manual/Auto Switching, Adj. Cur Limit, Switch Status 8-TSSOP -40 to 85	Download
TPS2114PWG4	Texas Instruments	Dual In/Single Out Autoswitching Power MUX, Manual/Auto Switching, Adj. Cur Limit, Switch Status 8-TSSOP -40 to 85	Download
TPS2114PWR	Texas Instruments	Power Switch ICs - Power Distribution Dual In/Single Out Autoswitch Power MUX	Download
TPS2114PWRG4	Texas Instruments	Power Switch ICs - Power Distribution Dual In/Single Out Autoswitch Power MUX	Download

TPS2114PW Related Product Datasheets：

Part Number	Datasheet
TPS2114PWR 、 TPS2114PWRG4	Download Datasheet
TPS2114PW 、 TPS2114PWG4	Download Datasheet

TPS2114PW Related Products：

Part Number	TPS2114PW	TPS2114PWG4
Description	Dual In/Single Out Autoswitching Power MUX, Manual/Auto Switching, Adj. Cur Limit, Switch Status 8-TSSOP -40 to 85	Dual In/Single Out Autoswitching Power MUX, Manual/Auto Switching, Adj. Cur Limit, Switch Status 8-TSSOP -40 to 85
Brand Name	Texas Instruments	Texas Instruments
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
Parts packaging code	SOIC	SOIC
package instruction	TSSOP, TSSOP8,.25	TSSOP, TSSOP8,.25
Contacts	8	8
Reach Compliance Code	compli	compli
ECCN code	EAR99	EAR99
Other features	CAN SWITCH A VOLTAGE AS LOW AS 1.5V AS LONG AS THERE IS A MIN OF 2.8V AT ONE OF THE I/P POWER PINS	CAN SWITCH A VOLTAGE AS LOW AS 1.5V AS LONG AS THERE IS A MIN OF 2.8V AT ONE OF THE I/P POWER PINS
Adjustable threshold	YES	YES
Analog Integrated Circuits - Other Types	POWER SUPPLY SUPPORT CIRCUIT	POWER SUPPLY SUPPORT CIRCUIT
JESD-30 code	R-PDSO-G8	R-PDSO-G8
JESD-609 code	e4	e4
length	4.4 mm	4.4 mm
Humidity sensitivity level	1	1
Number of channels	2	2
Number of functions	1	1
Number of terminals	8	8
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSSOP	TSSOP
Encapsulate equivalent code	TSSOP8,.25	TSSOP8,.25
Package shape	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260	260
power supply	1.8/5 V	1.8/5 V
Certification status	Not Qualified	Not Qualified
Maximum seat height	1.2 mm	1.2 mm
Maximum supply current (Isup)	0.09 mA	0.09 mA
Maximum supply voltage (Vsup)	5.5 V	5.5 V
Minimum supply voltage (Vsup)	1.5 V	1.5 V
Nominal supply voltage (Vsup)	2.8 V	2.8 V
surface mount	YES	YES
Temperature level	INDUSTRIAL	INDUSTRIAL
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal form	GULL WING	GULL WING
Terminal pitch	0.65 mm	0.65 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
width	3 mm	3 mm
Base Number Matches	1	1
