* Applicators listed are used in the AMP-O-LECTRIC Model G, AMP 3K/40 and AMP 5K/40 Terminators. Call the Tooling Assistance Center at 800-722-1111 for applicator numbers for Automatic Cut, Strip and Terminate Leadmakers.
** Power tooling options are also available. Call Tooling Sales at 888-777-5917 (717-810-2080) for more information
te.com/products/minict
TE Connectivity
1.5 mm AMP Mini CT Connector Series
Photo Key
Dual Row Assemblies
A
353293
B
353907
C
353908
1
D
292206
E
292207
F
292227
Solder Pad
G
292228
H
292230
I
292231
2
Locating Boss
J
292215
K
353294
L
292208
3
Dual Row Assemblies
Two single row receptacle housings, either MT
or crimp, that use a holder to mate with a dual
row header.
M
292229
N
292262
O
2106091
Solder Pad
Designed to secure the SMT headers onto the PCB
Locating Boss
A mechanical feature that helps orientate the
headers onto the PCB.
te.com/products/minict
TE Connectivity
1.5 mm AMP Mini CT Connector Series
SINGLE ROW POST HEADER ASSEMBLIES : BOARD-MOUNT
Description
T/H Type Horizontal-Mount Type, w/o Boss
T/H Type Vertical-Mount Type, w/ Boss
SMT Type Horizontal-Mount Type, w Boss
SMT Type Horizontal-Mount Type, w/o Boss
SMT Type Vertical-Mount Type, w Boss
SMT Type Vertical-Mount Type, w/o Boss
PN
292206
292207
292227
292228
292230
292231
2
D
E
F
G
H
I
-2
-2
-2
-2
3
-3
-3
-3
-3
-3
-3
4
-4
-4
-4
-4
-4
-4
5
-5
-5
-5
-5
-5
-5
6
-6
-6
-6
-6
-6
-6
Position to Dash
7
-7
-7
-7
-7
-7
-7
8
-8
-8
-8
-8
-8
-8
9
-9
-9
-9
-9
-9
-9
10
-10
-10
-10
-10
-10
-10
11
-11
-11
-11
-11
-11
-11
12
-12
-12
-12
-12
-12
-12
13
-13
-13
-13
-13
-13
-13
14
-14
-14
-14
-14
-14
-14
15
-15
-15
-15
-15
-15
-15
16
-16
-16
-16
-16
-16
-16
17
-17
-17
-17
-17
-17
-17
18
-18
-18
-18
-18
-18
-18
19
-19
-19
-19
-19
-19
-19
20
-20
-20
-20
-20
-20
-20
Mating Part Numbers:
(MT) 353293 or (Crimp) 353908 w/ 353907-1 or 353918-1
Specifications:
A, X
SINGLE ROW POST HEADER ASSEMBLIES : PANEL-MOUNT
Description
Single Row Panel-Mount
PN
292215
2
J
-2
3
-3
4
-4
5
-5
6
-6
Position to Dash
7
-7
8
-8
9
-9
10
-10
11
-11
12
-12
13
-13
14
-14
15
-15
16
-16
17
-17
18
-18
19
-19
20
-20
Mating Part Numbers:
(MT) 353293 or (Crimp) 353908 w/ 353907-1 or 353918-1
Specifications:
A, X
DUAL ROW HEADERS
Description
Receptacle Housing Connector Mounting Holder
PN
353294
22
K
-22
24
-24
26
-26
Position to Dash
28
-28
30
-30
32
-32
34
-34
36
-36
38
-38
40
-40
Specifications:
C, X
Note:
Two receptacle housings are applied per holder and one holder per dual row header
Mating Part Numbers:
2 x (MT) 353293 or 2 x (Crimp) 353908 w/ 353907-1 or 353918-1
DUAL ROW POST HEADER ASSEMBLIES : BOARD-MOUNT
Description
Dual Row T/H Type/ Vertical-Mount
Dual Row SMT Type/ Vertical Mount Type w/Boss
Dual Row T/H Type/ Horizontal Mount w/ Board Lock
PN
292208
292229
292262
22
L
M
N
-22
-22
24
-24
-24
-24
26
-26
-26
-26
Position to Dash
28
-28
-28
-28
30
-30
-30
-30
32
-32
-32
-32
34
-34
-34
-34
36
-36
-36
-36
38
-38
-38
-38
40
-40
-40
-40
Specifications:
A, C, X
Mating Part Numbers:
353294 w/ 2 x MT or 2 x Crimp Single Row Housings
DUAL ROW POST HEADER ASSEMBLIES : PANEL-MOUNT
Description
Dual Row Panel-Mount
PN
22
292216
-22
24
-24
26
-26
Position to Dash
28
-28
30
-30
32
-32
34
-34
36
-36
38
-38
40
-40
Specifications:
C, X
Mating Part Numbers:
353294 w/ 2 x MT or 2 x Crimp Single Row Housings
4
Panel-Mount
Transmits signal through a notch in a panel or a PCB
and requires two housings to complete a circuit.
5
SMT Inverted Thru Board
Positioned thru a cutout or notch in a PCB and requires
only one housing to complete a circuit. The innovative
design eliminates wire dress management issues.
INVERTED THRU BOARD
Description
SMT Type Thru Board
PN
2106091
2
O
-1
Position to Dash
3
-2
4
-3
5
-4
6
-5
4
5
Mating Part Numbers:
MT 353293 or crimp 353908 w/ 333907-1 or 333918-1
Specifications:
D, Z
MINI CT CABLE ASSEMBLY
Description
Cable Assembly
PN
2
2058943
-1
Position to Dash
3
-2
4
-3
5
-4
6
-5
te.com/products/minict
TE Connectivity
1.5 mm AMP Mini CT Connector Series
Product/Application Specification
RATINGS
Product Specs
A
B
C
D
108-60018
108-60025
108-5525
108-2376
Voltage
50 V (AC/DC)
50 V (AC/DC)
50 V AC
50 V (AC/DC)
Operating Current (Amps)
24 AWG
—
3
—
3
26 AWG
2
2.5
2
2.5
28 AWG
1
1.5
2
1.5
30 AWG
—
—
—
—
Temperature
-30 to 105°C
-30 to 105°C
-65 to 105°C
-30 to 105°C
X
Y
Z
Application Specs
114-5223
114-5245
114-13245
AMP Mini CT Mount Styles
353908
Crimp Receptacle Housing
292227
SMT R/A Header
292230
292262
SMT Vertical Header
Dual Row T/H R/A Header
2106091
292208
SMT Inverted Thru-Board
Dual Row T/H Vertical Header
IDC Receptacle Housing
292206
353293
T/H R/A Header
T/H Vertical Header
292207
292215
Panel Mount Header
AMP Mini CT Design Kits*
Design Kits
PN
2110828-1
2110828-2
2110828-3
2110828-4
2110828-5
2110828-6
2110828-7
2110828-8
2110829-8
Description
AMP Mini CT T/H Deluze Vertical and Right Angle Kit
AMP MIni CT T/H Vertical Header Kit
AMP Mini CT T/H Right Angle Header Kit
AMP Mini CT SMT Deluxe Vertical and Right Angle Kit
AMP Mini CT SMTVertical Header
AMP Mini CT SMT Right Angle Kit
AMP Mini CT Deluxe T/H and SMT Vertical and Right Angle Kit
AMP Mini CT Deluxe T/H Vertical and Right Angle Kit
AMP Mini CT Deluxe SMT Vertical and Right Angle Kit
*Design kits are designed and assembled by Waldom and are available for purchase through your local distribution channel.
