FL
CONNECTOR
0.5mm
(.020") pitch
Emboss Tape
Connectors for FFC and FPC
Features –––––––––––––––––––––––
• Heat resistant design suitable for surface mounting
This surface mountable connector's housing is made of heat
resistant plastic to allow reflow soldering.
• In-line surface mount tails
Has an in-line surface mount tails for easy inspection.
• Embossed taping for automatic mounting
This connector is supplied in embossed tape packaging, for
mounting by automatic placement machines.
• Double-sided contact
This connector has highly resilient phosphor bronze contacts,
each of which has two independent mating spring members
that ensure continuity even when subjected to severe
vibration. Because each of the contacts simultaneously mates
with both sides of the FFC or FPC, the engineer has greater
The FL connector is 0.5mm (.020") pitch
non-ZIF type connector for FFC and FPC.
freedom in designing his circuitry.
• Simple snap-in action
The FFC or FPC is securely connected by simply inserting its
leads into the connector.
• Interchangeability
The PC board layout for the FL connector (non-ZIF type) is
identical to that of the FLZ connector (ZIF type). This allows
the use of both types of connector without changing the PCB
layout.
Specifications ––––––––––––––––––
26
F
JS
T
• Current rating: 0.5A AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/40mΩ max.
After environmental testing/60m
Ω
max.
• Insulation resistance:
800MΩ min.
• Withstanding voltage: 200V AC/minute
• Applicable FFC and FPC: Conductor/copper foil,tin-plated
Note:
Lead pitch/0.5mm(.020")
Lead width/0.35mm(.140")
Mating part thickness/
0.30±0.05mm(.012"
±
.002)
Note: FPC to be actually used should be checked for applicability.
* Contact JST for details.
276
FL
CONNECTOR
Connector –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Cir-
cuits
6
7
8
9
2.4(.094)
0.7(.028)
Model No.
06FL-SM1-TB
07FL-SM1-TB
08FL-SM1-TB
09FL-SM1-TB
10FL-SM1-TB
11FL-SM1-TB
12FL-SM1-TB
13FL-SM1-TB
14FL-SM1-TB
15FL-SM1-TB
16FL-SM1-TB
17FL-SM1-TB
18FL-SM1-TB
19FL-SM1-TB
20FL-SM1-TB
21FL-SM1-TB
22FL-SM1-TB
24FL-SM1-TB
25FL-SM1-TB
26FL-SM1-TB
27FL-SM1-TB
30FL-SM1-TB
Dimensions mm(in.)
A
2.5(.098)
3.0(.118)
3.5(.138)
4.0(.157)
4.5(.177)
5.0(.197)
5.5(.217)
6.0(.236)
6.5(.256)
7.0(.275)
7.5(.296)
8.0(.315)
8.5(.335)
9.0(.354)
9.5(.374)
10.0(.394)
10.5(.413)
11.5(.453)
12.0(.472)
12.5(.492)
13.0(.512)
14.5(.571)
B
8.9(.350)
9.4(.370)
9.9(.390)
10.4(.409)
10.9(.429)
11.4(.449)
11.9(.469)
12.4(.488)
12.9(.508)
13.4(.527)
13.9(.547)
14.4(.567)
14.9(.587)
15.4(.606)
15.9(.626)
16.4(.646)
16.9(.665)
17.9(.705)
18.4(.724)
18.9(.744)
19.4(.764)
20.9(.823)
Q´ty /
reel
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
10
11
12
13
14
15
16
3.2(.126)
1.2
(.047)
17
18
19
20
2.0(.080)
B
A
4.6(.181)
0.7(.028)
21
22
24
25
26
27
30
0.5(.020)
Material and Finish
Note:
1. The products listed in the chart are supplised on embossed tape.
Contact: Phosphor bronze, tin/lead-plated
Slider housing: Nylon 46, UL94V-0 (black)
Receptacle housing: Nylon 46, UL94V-0
( )FLZ-SM1-TB gray
( )FLZ-RSM1-TB natural (ivory)
Solder tab: Phosphor bronze, tin/lead-plated
Taping specifications ––––––––––––––––––––––––––––––––––––––––––––––––––––––
Feeding direction
330
±
2(12.992
±
.079)dia.
Carrier tape
Feeding direction
Cover tape leader area
400
(15.748)
min.
Tail tape
40.0
(1.575)
min
Connector
loaded area
Lead tape
20pcs
min
[13.0(.512)dia.]
W1
+ 2.5
- 1.0
(W1
+ .098
)
- .039
2.0
±
0.5
(.079
±
.020)
Feeding direction
6 to 24 circuits
Feeding direction
1.75±0.1
F±0.1
(.069±.004)
S (.004)
W±0.3(.012)
1.55±0.05
(.061±.002)dia.
4.0±0.1
(.161±.004)
25 to 30 circuits
2.0±0.1
(.079±.004)
1.75±0.1
(.069±.004)
1.55±0.05
(.061±.002)dia.
4.0±0.1
(.161±.004)
0.3±0.05
(.012±.002)
Cover tape
0.3±0.05
(.012±.002)
Cover tape
F±0.1
(.004)
S±0.1(.004)
W±0.3(.012)
2.0±0.1
(.079±.004)
Carrier tape
Carrier tape
12.0±0.1
(.472±.004)
12.0±0.1
(.472±.004)
Taping dimensions mm(in.)
Circuits
6 to 8
9 to 24
25 to 30
Reel dimen-
sions mm(in.)
W1
17.5( .689)
25.5(1.004)
33.5(1.319)
F
7.5(.295)
11.5(.435)
14.2(.559)
S
6.75( .266)
10.75(.423)
28.4(1.118)
W
16.0( .630)
24.0( .945)
32.0(1.260)
Q´ty /
reel
2,000
2,000
2,000
Note:
Specifications conform to JIS C 0806. The tape width, connector recess
dimensions, etc. are determined by the number of circuits and external shape
of the connector to be loaded.
277
FL
CONNECTOR
Lead section dimensions of FPC ––––––––––––––––––––––––––––––––––––––––––––
[0.5(.020)x(Number of circuits +1)]±0.05(.002)
0.5±0.1
(.020±.004)
0.5±0.03
(.020±.001)
[0.5(.020)x(Number of
circuits -1)]
±
0.03(.001)
0.35±0.04
(.014±.002)
0.5±0.1
(.020±.004)
0.3±0.05
(.012±.002)
3.0(.118)
min
[5.5(.217)]
Reinforcing layer
Check the applicability with
the FPC to be actualy used.
PC board layout
(viewed from component side)
and Assembly layout ––––––––––––––––––
2.1
±
0.1
(.083
±
.004)
2.1
±
0.1
(.083
±
.004)
0.35(.014)
0.2(.008)
3.3
±0.1(.130 ±
.004)
FPC
Note:
1. Tolerances are non-cumulative:±.003mm(±.001" ) for all centers.
2. The dimensions above should serve as a guideline.
Contact JST for details.
278
2.0(.080)
0.35
±
0.05(.014
±
.002)
0.5
±
0.03(.020
±
.001)
4.6(.181)
0.7(.028)
