P11S, P11A
www.vishay.com
Vishay Sfernice
12.5 mm Modular Panel Potentiometer Cermet (P11S)
or Conductive Plastic Elements (P11A)
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
12.5 mm square single turn panel control
Five shaft diameters and 29 terminal styles
Multiple assemblies - up to seven modules
Tests according to CECC 41000 or IEC 60393-1
GAM T1
P11S version for industrial, military, and aeronautics
applications
P11A version for professional audio applications
Low current compatibility
Shaft and panel sealed version
Up to twenty-one indent positions
Rotary and push/push switch options
Concentric shafts
Custom designs on request
Trimmer version T11 (see document no. 51021)
Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
COMPACT
ROBUST
QUICK REFERENCE DATA
Multiple module
Switch module
Detent module
Special electrical
laws
Sealing level
Lifespan
VERSATILE
Up to 7 modules
Yes
Yes
A: linear, L: logarithmic, F: reverse
logarithmic and others see specification
IP 64
50K cycles
MODULAR
CONFIGURATION EXAMPLE
- Dimensions in millimeters (inches) ± 0.5 mm (± 0.02")
Single module, single shaft, solder lugs, metric bushing and shaft
12.5
(0.492)
5
(0.197)
13.1
(0.516)
M6 x 0.75
2.4
(0.094)
12.5
(0.492)
6.85
(0.270)
3
Ø (0.118)
8
(0.315)
22
(0.866)
1.8
(0.071)
5.07
(0.200)
0,9
(0.035)
4.65
(0.183)
A
4.65
(0.183)
4.9
(0.193)
DETAIL A
Single module, single shaft, vertical mounting, PC pins with support plate, metric bushing and shaft
M10 x 0.75
12.7
(0.500)
6
Ø (0.236)
9.5
(0.374)
16
(0.626)
8
(0.315)
2.54
(0.100)
2.54
(0.100)
Dual modules, single shaft, PC pins with front support plates, imperial bushing and shaft
9.5
(0.374)
12.5
(0.492)
3/8" x 3/8"
13.1
(0.516)
6.35
Ø (0.250)
3.6
(0.143)
19.05
(0.750)
8
(0.325)
7.62
(0.300)
2.54
(0.100)
2.54
(0.100)
Revision: 20-Jul-17
Document Number: 51031
1
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
P11S, P11A
www.vishay.com
Vishay Sfernice
GENERAL SPECIFICATIONS
ELECTRICAL
(initial)
P11A
Resistive element
Electrical travel
Resistance range
(1)
Tolerance
Linear taper
Non-linear taper
Standard
On request
Conductive plastic
270° ± 10°
1 k to 1 M
470
to 500 k
± 20 %
± 10 %
90 %
F
R
Vs
% 50 %
Ve
S
P11S
Cermet
270° ± 10°
20
to 10 M
100
to 2.2 M
± 20 %
± 5 % or ± 10 %
A
W
Taper
20 %
10 %
50 %
15°
31°
L
Electrical travel 270°
Electrical travel
with switch 238°
Mechanical travel 300°
a
c
(3)
b
(2)
cw
15°
31°
Circuit diagram
(1)
Linear taper
Non-linear taper
Multiple assemblies
0.5 W at +70 °C
0.25 W at +70 °C
0.25 W at +70 °C per module
1 W at +70 °C
0.5 W at +70 °C
0.5 W at +70 °C per module
Rated Power (W)
P11S Linear Taper
1
Power rating at 70 °C
P11S Non-Linear Taper
0.5
P11A Linear Taper
0.25
P11A Non-Linear Taper
0
0
10
20
30
40
50
60
70
80
90 100 110 120 130
Ambient Temperature (°C)
Temperature coefficient (typical)
Limiting element voltage
End resistance (typical)
Contact resistance variation (typical)
Independent linearity (typical)
Insulation resistance
Dielectric strength
Attenuation
Mechanical endurance
Note
(1)
Consult Vishay Sfernice for other ohmic values
Revision: 20-Jul-17
Document Number: 51031
2
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Linear taper
Linear taper
± 500 ppm
350 V
2
1%
±5%
10
6
M min.
1500 V
RMS
min.
90 dB max./0.05 dB min.
50 000 cycles
± 150 ppm
350 V
2
2 % or 3
±5%
10
6
M min.
1500 V
RMS
min.
-
50 000 cycles
P11S, P11A
www.vishay.com
Vishay Sfernice
300° ± 5°
Single and dual assemblies
0.4 Ncm to 1.8 Ncm max. (0.57 oz.-inch to 2.55 oz.-inch max.)
0.2 Ncm to 0.3 Ncm max. (0.28 oz.-inch to 0.42 oz.-inch max.)
MECHANICAL
(initial)
Mechanical travel
Operating torque (typical)
Three to seven modules (per module)
End stop torque
(all bushing except G and concentric shaft configuration)
3 mm, 4 mm, and 1/8" dia. shafts
6 mm and 1/4" dia. shafts
End stop torque for bushing G
All shafts dia.
End stop torque for concentric shaft configuration
3 mm and 1/8" dia. shafts
6 mm and 1/4" dia. shafts
Tightening torque
6 mm, 7 mm, and 1/4" dia. bushings
10 mm and 3/8" dia. bushings
Weight
150 Ncm max. (13 lb-inch max.)
250 Ncm max. (21 lb-inch max.)
7 g to 9 g per module (0.25 oz. to 0.32 oz.)
25 Ncm max. (2.1 lb-inch max.)
80 Ncm max. (6.8 lb-inch max.)
40 Ncm max. (3.4 lb-inch max.)
35 Ncm max. (2.9 lb-inch max.)
80 Ncm max. (6.8 lb-inch max.)
ENVIRONMENTAL
P11A
Operating temperature range
Climatic category
Sealing
-55 °C to +125 °C
55 / 125 / 21
IP64
P11S
-55 °C to +125 °C
55 / 125 / 56
IP64
MARKING
• Potentiometer module
Vishay logo, SAP code of ohmic value, tolerance in %,
variation law, manufacturing date (four digits), “3” for the
lead 3, product series (P11S, P11A)
•
Switch module
Version, manufacturing date (four digits), “c” for common
lead
• Indent module
Version, manufacturing date (four digits)
PACKAGING
• Box
PERFORMANCES
TESTS
Electrical endurance
Change of temperature
Damp heat, steady state
Mechanical endurance
Climatic sequence
Shock
Vibration
CONDITIONS
1000 h at rated power
90’/30’ - ambient temp. 70 °C
-55 °C to +125 °C, 5 cycles
+40 °C, 93 % relative humidity
P11S: 56 days, P11A: 21 days
50 000 cycles
Dry heat at +125 °C/damp heat
cold -55 °C/damp heat, 5 cycles
50
g’s,
11 ms
3 shocks - 3 directions
10 Hz to 55 Hz
0.75 mm or 10
g’s,
6 h
R
T
/R
T
Contact resistance variation
R
T
/R
T
R
T
/R
T
Insulation resistance
R
T
/R
T
Contact resistance variation
R
T
/R
T
R
T
/R
T
R
1-2
/R
1-2
R
T
/R
T
V
1-2
/V
1-3
TYPICAL VALUE AND DRIFTS
P11S
±2%
±4%
± 0.2 %
±2%
> 1000 M
±5%
±5%
±1%
± 0.2 %
± 0.5 %
± 0.2 %
± 0.5 %
P11A
± 10 %
±5%
± 0.5 %
±5%
> 10 M
±6%
±4%
-
± 0.2 %
± 0.5 %
± 0.2 %
± 0.5 %
Note
• Nothing stated herein shall be construed as a guarantee of quality or durability
Revision: 20-Jul-17
Document Number: 51031
3
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
P11S, P11A
www.vishay.com
Vishay Sfernice
ORDERING INFORMATION
(part number)
P
1
1
S
2
Q
0
E
A
S
Y
0
0
1
0
3
M
A
MODEL
P11
STYLE
S = cermet element
A = conductive plastic
(audio)
NUMBER
OF
MODULES
1
2
3
4
5
6
7
BUSHING
LOCATING
PEG
SHAFT
SHAFT
STYLE
LEADS
RESISTANCE CODE/
TOLERANCE/
TAPER OR SPECIAL
STANDARD RESISTANCE ELEMENT DATA
P11S CERMET
P11A CONDUCTIVE PLASTIC
LINEAR TAPER
NON-LINEAR TAPER
LINEAR TAPER
NON-LINEAR TAPER
STANDARD
RESISTANCE MAX.
MAX. MAX. CUR. MAX.
MAX. MAX. CUR. MAX.
MAX. MAX. CUR. MAX.
MAX. MAX. CUR.
VALUES
POWER WORKING THROUGH POWER WORKING THROUGH POWER WORKING THROUGH POWER WORKING THROUGH
AT 70 °C VOLTAGE WIPER AT 70 °C VOLTAGE WIPER AT 70 °C VOLTAGE WIPER AT 70 °C VOLTAGE WIPER
22
47
50
100
220
470
500
1K
2.2K
4.7K
5K
10K
22K
47K
50K
100K
220K
470K
500K
1M
2.2M
4.7M
5M
10M
W
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.56
0.26
0.25
0.12
0.06
0.03
0.02
0.01
V
4.69
6.86
7.07
10.0
14.8
21.7
22.4
31.6
46.9
69
70.7
100
148
217
224
316
350
350
350
350
350
350
350
350
mA
213
146
141
100
67.4
46.1
44.7
31.6
21.3
14.5
14.1
10.0
6.74
4.61
4.47
3.16
1.59
0.75
0.70
0.35
0.16
0.074
0.070
0.035
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.26
0.25
0.12
0.056
7.07
10.5
15.3
15.8
22.4
33.2
48.5
50.0
70.7
105
153
158
224
332
349
350
350
350
70.7
47.7
32.6
31.6
22.4
15.1
10.3
10.0
7.07
4.77
3.26
3.16
2.24
1.51
0.74
0.71
0.34
0.16
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.26
0.25
0.12
22.4
33.2
48.5
50.0
70.7
105
153
158
224
332
350
350
350
22.4
15.1
10.3
10.0
7.07
4.77
3.26
3.16
2.24
1.51
0.74
0.71
0.34
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
11.2
15.8
23.5
34.3
35.4
50.0
74.2
108
112
158
235
343
350
22.4
15.8
10.7
7.29
7.07
5.00
3.37
2.31
2.24
1.58
1.07
0.73
0.71
W
V
mA
W
V
mA
W
V
mA
Revision: 20-Jul-17
Document Number: 51031
4
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
P11S, P11A
www.vishay.com
Vishay Sfernice
ORDERING INFORMATION
(part number)
P
1
1
S
2
Q
0
E
A
S
Y
0
0
1
0
3
M
A
MODEL
P11
STYLE
NUMBER
OF
MODULES
Ø
1/4"
1/4"
1/4"
1/4"
1/4"
3/8"
8
7
6
10
BUSHING
L
Old Codes
1/4"
7, 77, 77-3
3/8"
71
1/2"
72
3/8"
71H
1/2"
72H
3/8"
2, 03, 0-
8 TP, QP, VP, 2P, 7P
8
Q
8
T
9.5
V, CC, CC-3
LOCATING
PEG
SHAFT
SHAFT
STYLE
LEADS
RESISTANCE CODE/
TOLERANCE/
TAPER OR SPECIAL
A
B
C
D
E
F
G
Q
T
V
BUSHING DIMENSIONS
A
B
PANEL AND SHAFT SEALED: BUSHING G
Ø 8 (0.315)
8
(0.315)
C
J
6.7 (0.264)
K
All models have the same bushing Dia. 8 mm - L 8 mm
PANEL CUT OUT
Bushing G
Bushings
F and V
Bushings A, B,
C, D, E, T and Q
BUSHING D AND E WITH LOCKING NUT
Wrench 10 or 3/8"
A
B
ØH
G
G
ØH
7.2
(0.284)
Ø 8.5
(0.335)
C
J
BUSHINGS
A
B
C
J
G
H
Shafts
Bushing
Lead versions X.. Y..
K
Panel
Cutout
Thread
Wrench nut
Style
Ø
Ø
L
G
All Dia.
8
8
6.7
10.4
7.2
8.5
12
T
3
6
8
5
9.1
5.2
6.5
0.75
8
Q
4
7
8
5
9.1
6.2
7.5
10
V
6
10
9.5
7
11.1
8.2
10.5
12
A
1/8"
1/4"
1/4"
0.200
0.357
0.197
0.268
0.313
B
1/8"
1/4"
3/8"
0.200
0.357
0.197
0.268
0.313
C
D
E
1/8"
1/4"
1/2"
0.200
0.357
0.197
0.268
0.313
Slotted
F
1/4"
3/8"
3/8"
0.278
0.436
0.323
0.394
0.500
DIMENSIONS mm (± 0.5)
DIMENSIONS INCHES (± 0.02)
1/8"
1/8"
1/4"
1/4"
1/2"
3/8"
0.200
0.200
0.357
0.357
0.197
0.197
0.268
0.268
32 threads/inch
0.313
0.313
Slotted
Ø
Notes
• Hardware supplied in separate bags
• Slotted bushing for locking nut option
Revision: 20-Jul-17
Document Number: 51031
5
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
LED Zone
京公网安备 11010802033920号
EEWORLD
