Not for New Designs
PT-100, PT-200
www.vishay.com
Vishay Dale
Through Hole Transformers, Pulse, Trigger Type
FEATURES
• Integrated services digital network transformers
that provide isolation for the line card and terminal
in conjunction with both “S/T” and “U” interfaces
• Designed to meet the CCITT 1.430 pulse wave
form template requirements
• Isolation voltage levels available for U.S. and international
applications
• Printed circuit board mountable in both through-hole and
surface mount packages
• Standard and custom configurations available
• PT-100 series used for “S/T” interfaces
• PT-200 series used for “U” interfaces
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
PT-100-01
PT-100-02
PT-100-04
PT-100-05
PT-100-06
PT-100-08
PT-100-09
PT-100-12
PT-200-01
PT-200-02
PT-200-03
PT-200-08
TURNS
RATIO
1 CT : 2 CT
1 CT : 2 CT
1 CT : 2 CT
1 CT : 2.5 CT
1 CT : 1 CT
1 CT : 1.8 CT
1 CT : 2 CT
1 CT : 2 CT
2.5 : 1
2 : 1 CT
2:1
1.6 : 1
PRIMARY PRIMARY SECONDARY LEAKAGE PRIMARY/SECONDARY
IND. MIN. DCR MAX.
DCR MAX. IND. MAX.
HIPOT
STYLE
SCHEMATIC
(mH)
()
()
(μH)
(V
RMS
)
NUMBER
NUMBER
20
1.2
11.0
30
1500
1
1
20
1.2
11.0
30
1500
2
2
20
3.0
4.5
15
1500
4
4
22
2.8
6.5
20
1500
1
1
22
2.8
2.8
10
1500
5
6
22
2.8
5.5
20
1500
1
1
22
8.0
15.0
30
1500
7
5
22
2.8
5.5
10
2000
9
4
72
8.5
2.0
160
1100
3
3
25
11.0
3.5
20
1100
6
7
30
2.3
2.0
200
1100
8
8
13
3.0
3.0
55
2000
6
9
TRANSFORMER CROSS REFERENCE FOR TRANSCEIVER CHIPS
MODEL
PT-100-01
PT-100-02
PT-100-04
PT-100-05
PT-100-06
PT-100-08
PT-100-09
TURNS RATIO
1 CT : 2 CT
1 CT : 2 CT
1 CT : 2 CT
1 CT : 2.5 CT
1 CT : 1 CT
1 CT : 1.8 CT
1 CT : 2 CT
IC MANUFACTURER
SIEMENS
SIEMENS
AMD
MITEL
NATIONAL
INTEL
AT&T
MOTOROLA
INTEL
SIEMENS
AMD
MITEL
NATIONAL
SIEMENS
AMD
MITEL
NATIONAL
AT&T
MOTOROLA
MITEL
SIEMENS
IC PART NUMBER
PEB2080/2085/2081
PEB2080/2085/2081
79C30A
MT8930
TP3420
29C53
T7250/T7252
MC145474
MC145475
29C53
PEB2080/2085
79C30A
MT8930
TP3420
PEB2080/2085/2081
79C30A
MT8930
TP3420
T7262/T7263
MC145472
MT8972
PEB2091
PT-100-12
(1)
PT-200-01
PT-200-02
PT-200-03
PT-200-08
(1)
1 CT : 2 CT
2.5 : 1
2 : 1 CT
2:1
1.6 : 1
(2)
Notes
(1)
Hipot voltage will meet international safety standards
(2)
Low profile
