75W Single Output Medical Type

RPS-75

£g

series

SPECIFICATION

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

PEAK LOAD (23.5CFM)

OUTPUT

VOLTAGE ADJ. RANGE

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE

FREQUENCY RANGE

INPUT

EFFICIENCY(Typ.)

AC CURRENT (Typ.)

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

OVERLOAD

PROTECTION

OVER VOLTAGE

WORKING TEMP.

WORKING HUMIDITY

ENVIRONMENT

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

SAFETY STANDARDS

SAFETY &

EMC

EMC EMISSION

EMC IMMUNITY

MTBF

OTHERS

DIMENSION

PACKING

NOTE

RPS-75-3.3

3.3V

15A

0 ~ 20A

49.5W

66W

Note.2

80mVp-p

RPS-75-5

14A

0 ~ 18.7A

70W

93.5W

80mVp-p

4.75 ~ 5.5V

RPS-75-12

12V

6.3A

0 ~ 8.3A

75.6W

99.6W

120mVp-p

11.4 ~ 13.2V

RPS-75-15

15V

0 ~ 6.7A

75W

100.5W

150mVp-p

13.5 ~ 16.5V

RPS-75-24

24V

3.2A

0 ~ 4.2A

76.8W

100.8W

240mVp-p

22.8 ~ 27.6V

RPS-75-36

36V

2.1A

0 ~ 2.8A

75.6W

100.8W

300mVp-p

34.2 ~ 39.6V

RPS-75-48

48V

1.6A

0 ~ 2.1A

76.8W

100.8W

300mVp-p

45.6 ~ 52.8V

2.9 ~ 3.6V

Note.3

¡Ó

2.0%

¡Ó

2.0%

¡Ó

0.5%

¡Ó

1.5%

¡Ó

1.0%

¡Ó

0.5%

¡Ó

1.0%

¡Ó

1.0%

¡Ó

0.5%

¡Ó

1.0%

¡Ó

1.0%

¡Ó

0.5%

¡Ó

1.0%

¡Ó

1.0%

¡Ó

0.5%

¡Ó

1.0%

¡Ó

1.0%

¡Ó

0.5%

¡Ó

1.0%

¡Ó

0.5%

¡Ó

1.5%

80ms/230VAC

90 ~ 264VAC

47 ~ 63Hz

73%

1.5A/115VAC

500ms, 30ms/230VAC

500ms, 30ms/115VAC at full load

20ms/115VAC at full load

127 ~370VDC

78%

1A/230VAC

82%

83%

85%

86%

COLD START 25A/115VAC

50A/230VAC

Note.7

Earth leakage current < 100 A/264VAC , Touch leakage current < 100 A/264VAC

£g

140 ~ 180% rated output power

Protection type : Hiccup mode, recovers automatically after fault condition is removed.

3.8 ~ 4.46V

5.75 ~ 6.75V

13.8 ~ 16.2V

17.25 ~ 20.25V

27.6 ~ 32.4V

41.4 ~ 48.6V

55.2 ~ 64.8V

Protection type : Shut down o/p voltage, re-power to recover

-20 ~ +70

¢J

(Refer to "Derating Curve")

20 ~ 90% RH non-condensing

-40 ~ +85

¢J

, 10 ~ 95% RH

¡Ó

0.03%/

¢J

(0 ~ 45

¢J)

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved

I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25

¢J

/ 70% RH

Compliance to EN55011 (CISPR11), EN55022 (CISPR22) Class B, EN61000-3-2,-3

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN60601-1-2, EN61000-6-2, EN61204-3, heavy industry level, EN61204-3 medical level, criteria A

446.8K hrs min. MIL-HDBK-217F (25

¢J

)

127*76.2*31mm (L*W*H)

0.26Kg; 63pcs/16.3Kg/1.35CUFT

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25

¢J

of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

5. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time.

6. Heat Sink HS1,HS2,HS3 can not be shorted.

7. Touch current was measured from primary input to DC output.

File Name:RPS-75-SPEC 2012-05-22
