0.70
A
Pin1
Shield: Steel,
Nickel Plated
Insulator: UL94V-0 rated
High Temp. Nylon,
Color- White or Black
Reflow Process Compatible
Contact Material:
Phosphor Bronze
Plating Options:
Standard: Gold Flash
on Contact Area, 120u"
Tin-Lead on Soldertails,
all over 50u" Nickel
30 Option: 30u" Gold
on Contact Area, 120u"
11.70 4.50
12.0
7.00 2.00
0.33
7.00
2.00
1.20
PIN 4
PIN 1
0.60
Pin4
Tin-Lead on Soldertails,
all over 50u" Nickel
18.65±0.25
3.90
Rated Voltage:
30V AC (rms)
2.00
4.00
2.50
1.60
2.70 1.20
1.00
1.60
4.50
11.40
2.20
2.00
B (x2)
P.C.B EDGE
Part Number
KUSB-SMT2-AP1S-W
KUSB-SMT2-AP1S-W30
KUSB-SMT2-AP1S-B
KUSB-SMT2-AP1S-B30
KUSB-SMT2-AP5S-W
KUSB-SMT2-AP5S-W30
KUSB-SMT2-AP5S-B
KUSB-SMT2-AP5S-B30
REV.
A0
A1
A2
A3
A4
A5
4.5
Contact Current Rating:
1A max.
Contact Resistance:
30 milliohms Max.
1.50
Insulation Resistance:
1000 Megohms Min.
Dielectric Withstanding:
500V AC
Insertion Force:
3.57kg max.
Contact Area Plating Finish
Gold Flash (standard)
30u" Gold (30 option)
Gold Flash (standard)
30u" Gold (30 option)
Gold Flash (standard)
30u" Gold (30 option)
Gold Flash (standard)
30u" Gold (30 option)
Insulator Color
White
Dim "A"/Dim "B"
Extraction Force:
1.02kg min.
Operating Temperature:
-55°C to 85°C
Recommended PCB Layout
(Top View)
0.90mm/1.10mm
±0.10mm
Black
White
1.35mm/1.55mm
±0.10mm
Black
C
US
LR78160
Tolerances
X.X ± 0.25
X.XX ± 0.15
Unless Stated
Otherwise
DATE
03/29/02
04/10/02
04/15/02
06/27/02
12/13/04
07/27/05
DESCRIPTION
New Drawing
Modify Post Dim.
Modify Post Dim.
Release Drawing
ECO #04-068
ECO #05-030
REV. BY
M. Yiu
K. Wallace
K. Wallace
K. Wallace
R. Aguirre
R. Aguirre
CHK. BY
K. Wallace
K. Wallace
K. Wallace
K. Wallace
H. MA
H. MA
DRAWN BY
M. Yiu
DATE
03/29/02
UNITS
mm
