FEATURES
APPLICATIONS
Standardized Case Sizes
-
High Ripple Current
–
Multiple
Case Sizes
Bypass
–
Coupling
–
Filtering
–
De-coupling
Operating Temperature
Range
Capacitance Tolerance
WVDC
Surge Voltage
SVDC
WVDC
Dissipation
Tan δ
Factor
Leakage Current
Low
Temperature
Stability
Impedance
Ratio
(120 Hz)
-55°C to +105°C
+20% at 120 Hz, 20°C
6.3
7.9
6.3
.22
10
13
10
.19
16
20
16
.16
25
32
25
.14
35
44
35
.12
50
63
50
.1
63
79
63
.1
100
125
100
.1
Add .02 for every 1000uF above 1000uF
2 Minutes
.01CV or 3uA, Whichever is greater
WVDC
-25°C to +20°C
-40°C to +20°C
6.3
4
8
10
3
6
16
2
4
25
2
3
35
2
3
50
2
3
63
2
3
100
2
3
Load Life
Shelf Life
5000 hours at 105°C with rated WVDC and ripple current applied
(4000 hrs for D=10, 3000 Hrs for D=8, 2000 Hrs for D<6.3)
Capacitance Change
<20% of initial measured value
Dissipation Factor
<200% of maximum specified value
Leakage Current
<100% of maximum specified value
1000 hours at 105°C with no voltage applied
Capacitance Change
<25% initial measured value
Dissipation Factor
<200% of maximum specified value
Leakage Current
<100% of maximum specified value
Frequency (Hz)
Ripple Current Multipliers
Capacitance
C<180
220<C<560
680<C<1800
2200<C<3900
C>4700
50
.4
.5
.6
.75
.85
120
.4
.5
.6
.75
.85
1k
.75
.85
.87
.9
.95
10k
.9
.94
.95
.95
.98
100k
1.0
1.0
1.0
1.0
1.0
D
5
6.3
8
10
S
2.0
2.5
3.5
5.0
d
0.5
0.5
0.6
0.6
L
1
=L+1.5 mm Max. (L<20mm)
L
1
=L+2.0 mm Max. (L>20mm)
D
1
=D+0.5 mm Max.
S
1
=S+0.5 mm
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
mm
Feb-17
