CRYSTEK
Voltage Controlled Oscillator-VCO
M I C
of Crystek Corporation
ROWAVE
A Division
PERFORMANCE SPECIFICATION
Lower Frequency:
Upper Frequency:
2000
CVCO55CW-1000-2000
MAX
1000
UNITS
MHz
MHz
MIN
TYP
Tuning Voltage:
Supply Voltage:
1.0
9.75
10.0
20.0
10.25
VDC
VDC
Output Power:
Supply Current:
+6.0
+9.0
15
+12.0
25
dBm
mA
Harmonic Suppression (2
nd
Harmonic):
Pushing:
-10
2.5
-5
5.0
dBc
MHz/V
Pulling, all Phases:
Tuning Sensitivity:
Phase Noise @ 10kHz offset:
Phase Noise @ 100kHz offset:
Load Impedance:
Input Capacitance:
Operating Temperature Range:
-40
7.5
60
-95
-115
50
15.0
MHz pk-pk
MHz/V
dBc/Hz
dBc/Hz
33
+85
pF
°C
Storage Temperature Range:
-45
+90
°C
Phase Noise (1 Hz BW, Typical)
Tuning Curve (Typical)
Product Control:
Crystek Part Number:
CVCO55CW-1000-2000
Release Date:
01-Dec-2016
Revision Level:
K
Responsible:
C. Vales
Page 1 of 2
C
CRYSTEK
C OR P OR A T IO N
12730 Commonwealth Drive Fort Myers, Florida 33913
Phone: 239-561-3311 800-237-3061
Fax: 239-561-1025 www.crystek.com
CRYSTEK
Voltage Controlled Oscillator-VCO
M I C
of Crystek Corporation
ROWAVE
A Division
Gold Finish
0.030
(0.76)
0.052
(1.32)
0.025
(0.64)
CVCO55CW-1000-2000
BOTTOM VIEW
[RF]
SIDE VIEW
0.465 SQ
(11.81 SQ)
[Vcc]
[Vt]
0.280
0.080
0.180
BOTTOM ORIENTATION MARK
TOP VIEW
0.500
(12.70)
0.500
0.415
13
0.380
0.040
(1.02)
0.150
(3.81)
0.100
(2.54)
Pad
12
11
10
9
Connection
Vt
RF-OUTPUT
Vcc
GROUND
8
7
0.405
0.305
0.205
0.105
CRYSTEK
CVCO55CW
1000-2000
YYWW
0.315
14
15
16
2
10
14
Others
0.500
(12.70)
0.215
0.115
PAD LOCATION
6
5
0.000
1
2
3
4
0.000
0.115
TOP ORIENTATION MARK
TAPE AND REEL
0.059 Ø TYP
(1.50 Ø) TYP
0.157±0.004
(4.00±0.10)
0.945±0.012
(24.00±0.30)
DIRECTION OF FEED
0.630±0.004
(16.00±0.10)
0.500
0.215
0.315
0.415
Unless otherwise specified,
Dimensions are in:
IN
(mm)
Pad Location
Dimensions are in: Inches
Drawing not to scale
Product Control:
Crystek Part Number:
CVCO55CW-1000-2000
Release Date:
01-Dec-2016
Specification is subject to change without notice
Revision Level:
K
Responsible:
C. Vales
Page 2 of 2
C
CRYSTEK
C OR P OR A T IO N
12730 Commonwealth Drive Fort Myers, Florida 33913
Phone: 239-561-3311 800-237-3061
Fax: 239-561-1025 www.crystek.com
