ALUMINUM ELECTROLYTIC CAPACITORS
FX2 Series
•Life rating to 5000 hours at 85°C
•Temperature range –40°C to +85°C
Rated
Voltage
(WVDC)
Part
Number
FX22V272YC12R
FX22V332YC13R
FX22V392YD10R
FX22V472YD12R
FX22V562YD13R
FX22V682YE12R
FX22V822YE13R
FX22V103YE16R
FX22V123YE17R
FX22V123YF13R
FX22V153YF16R
FX22V183YF20R
FX22V223YF24R
FX22V273YG24R
FX22G222YC12R
FX22G272YC13R
FX22G332YD10R
FX22G392YD12R
FX22G472YD13R
FX22G562YE12R
FX22G682YE13R
FX22G822YE16R
FX22G103YE20R
FX22G103YF13R
FX22G123YF16R
FX22G153YF20R
FX22G183YF24R
FX22G223YG24R
Capacitance
2,700
3,300
3,900
4,700
5,600
6,800
8,200
10,000
12,000
15,000
18,000
22,000
27,000
2,200
2,700
3,300
3,900
4,700
5,600
6,800
8,200
10,000
12,000
15,000
18,000
22,000
Case Size
ØD x L (mm)
51 X 115
51 X 130
64 X 96
64 X 115
64 X 130
77 X 115
77 X 130
77 X 155
77 X 171
90 X 131
90 X 157
90 X 196
90 X 236
101 X 237
51 X 115
51 X 130
64 X 96
64 X 115
64 X 130
77 X 115
77 X 130
77 X 155
77 X 195
90 X 131
90 X 157
90 X 196
90 X 236
101 X 237
Maximum Ripple
Current (A rms)
@85° C,120Hz
9.7
11.3
12.0
14.0
16.1
17.9
20.6
24.4
27.9
26.7
31.9
38.1
45.5
52.0
8.8
10.2
11.0
12.8
14.8
16.2
18.7
22.0
26.7
24.2
28.5
34.8
41.2
47.0
Maximum
ESR (mΩ)
25
22
19
16
14
12
12
11
8
8
6
5
5
5
28
24
21
18
16
14
12
12
10
10
8
6
5
5
Typical
ESL (nH)
25
25
30
30
40
50
50
50
50
50
60
70
70
70
25
25
30
30
30
40
50
50
50
50
50
60
70
70
350 Volts
(Code: 2V)
400 Volts
(Code: 2G)
39
