DF15-M
1.5 Amp. Miniature Glass Passivated Single-Phase Bridge Rectifier
Voltage
600 V to 1000 V
FEATURES
Ideal for automated insertion
High forward surge current capability
Ideal for printed circuit boards
Solder dip 260ºC, 10s
Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
Meets MSL level 1, per J-STD-020, LF maximum
peak of 250º C
MECHANICAL DATA
Case
:
DFM
Epoxy meets UL 94V-0 flammability rating.
Polarity
:
As marked on body.
Terminals
:
Matte tin plated leads, solderable per
MIL-STD-750 Method 2026, J-STD-002 and JESD22-B102.
Consumer grade, meets JESD 201 class 1A whisker test.
TYPICAL APPLICATIONS
Used in ac-to-dc bridge full wave rectification for SMPS,
lighting ballaster, adapter, battery charger, home appliances, office
equipment, and telecommunication applications..
DFM
Current
1.5 Amp. at 40ºC
Maximun Ratings and Electrical Characteristics at 25°C
DF1506M
Marking code
DF1506M
600
420
1.5 A
10 A
50 A
12 A
2
sec
55 to + 150 °C
55 to + 150 °C
DF1510M
DF1510M
1000
700
V
RRM
V
RMS
I
F (AV)
I
F RM
I
FSM
I
2
t
T
j
T
stg
Peak recurrent reverse voltage (V)
Maximum RMS voltage (V)
Forward current at Tamb = 40 °C
Recurrent peak forward current
8.3 ms. peak forward surge current
(Jedec Method)
I
2
t value for fusing (t = 8.3 ms)
Operating temperature range
Storage temperature range
Electrical Characteristics at Tamb = 25 °C
V
F
I
R
Max. forward voltage drop at I
F
= 1.5 A
Max. reverse current
at
V
RRM
d.c.
and T = 25 °C
and T = 125 °C
1.1 V
10 µA
500 µA
40 °C/W
R
th(j-a)
Maximum thermal resistance junction to ambient (*)
(*) NOTE: Thermal Resistance from junction to ambient mounted on P.C. Board with 12 mm. sq. Copper
www.fagorelectronica.com
Document Name: df15-m
Version: Dec-11
Page Number: 1/4
DF15-M
1.5 Amp. Miniature Glass Passivated Single-Phase Bridge Rectifier
Ratings and Characteristics
(Ta 25 ºC unless otherwise noted)
TYPICAL FORWARD CHARACTERISTIC
FORWARD CURRENT DERATING CURVE
1.50
I
F(AV)
, average forward rectified current (A)
10
I
F
, instantaneous forward current (A)
1
1.25
R or L Load
10
0
1.00
0.75
0.50
0.25
0
10
-1
10
-2
0
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
0
25
50
75
100 125 150 175
V
F
, instantaneous forward voltage (V)
Tamb, ambient temperature (ºC)
MAXIMUM NON-REPETITIVE
PEAK FORWARD SURGE CURRENT
100
I
FSM
, peak forward surge current (A)
50
20
10
1
2
4 6
10
20
40
100
Number of cycles at 60 Hz.
www.fagorelectronica.com
Document Name: df15-m
Version: Dec-11
Page Number: 3/4
