1. Inductance tolerance is +/-30% for inductance values between 1uH and 8.2uH and +/-20% for values between
10uH and 680uH.
2. Inductance is measured at 100kHz, 250mV for values between 1uH and 8.2uH and at 1kHz, 250mV for values
between 10uH and 680uH.
3. The rated current as listed is the rms or heating current that the part can withstand with acceptable temperature
rise in typical applications. At the listed current the inductance typically drops to 85-90% of the no load value
when measured at 25C.
4. The temperature of the component (ambient plus temperature rise) must be within the stated operating
temperature.
2
pulseelectronics.com
P746.A (12/14)
Pulse Jack
Shielded Drum Core Inductor
PA4300.XXXNLT & PA4301.XXXNLT Series
Electronics
Mechanical
PA43XX.XXXNLT
A
B
F
G
A
E D
H
G
Schematic
C
1
2
FINAL OUTLINE
SUGGESTED PAD LAYOUT
Part Number
PA4300.XXXNLT
PA4301.XXXNLT
A (max)
6.1
7.2
B (max)
3.0
3.0
C (max)
8.2
9.7
D
(5.5)
(6.5)
E
(2.0)
(2.0)
F
(6.3)
(7.3)
G
(2.15)
(2.65)
H
(2.0)
(2.0)
TAPE & REEL INFO
T
E
P
2
P
0
ØD
0
B
F
W
A
N
K
0
P
1
G
SURFACE MOUNTING TYPE, REEL/TAPE LIST
TYPE
PA4300.XXXNLT
PA4301.XXXNLT
REEL SIZE (mm)
A
Ø330
Ø330
B
21
21
G
16.5
16.5
N
100
100
E
1.75
1.75
F
5.5
7.5
D
0
1.5
1.5
P
8
12
TAPE SIZE (mm)
P
0
4
4
P
2
2
2
W
16
16
T
0.30
0.30
K
0
3.3
3.2
QTY
PCS/REEL
2000
1000
For More Information
Pulse Worldwide
Headquarters
12220 World Trade Drive
San Diego, CA 92128
U.S.A.
Pulse China Headquarters
Pulse North China
Pulse South Asia
Pulse North Asia
B402, Shenzhen Academy of
Room 2704/2705
135 Joo Seng Road
3F, No. 198
Aerospace Technology Bldg.
Super Ocean Finance Ctr.
#03-02
Zhongyuan Road
10th Kejinan Road
2067 Yan An Road West
PM Industrial Bldg.
Zhongli City
High-Tech Zone
Shanghai 200336
Singapore 368363
Taoyuan County 320
Nanshan District
China
Taiwan R. O. C.
Shenzhen, PR China 518057
Tel: 886 3 4356768
Tel: 858 674 8100
Tel: 49 7032 7806 0
Tel: 86 755 33966678
Tel: 86 21 62787060
Tel: 65 6287 8998
Fax: 886 3 4356823 (Pulse)
Fax: 858 674 8262
Fax: 49 7032 7806 12
Fax: 86 755 33966700
Fax: 86 2162786973
Fax: 65 6287 8998
Fax: 886 3 4356820 (FRE)
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may be
