REVISION AA
DO NOT
SCALE FROM
THIS PRINT
.080 2.03 REF
(No OF POS x .100[2.54])
+ .060[1.52] REF
(No OF POS -1)
x .100[2.54] REF
01
02
IPL1-1XX-XX-XXX-D-XX-X
No OF POSITIONS
-02 THRU -25
(PER ROW)
LEAD STYLE
-01: THROUGH HOLE
(USE T-1S64-XX-XX)
-02: SURFACE MOUNT
(SEE FIG. 2, SHT 2)
(USE T-1S64-XX-XX)
OPTION
-P: POLARIZATION (SEE FIG. 1)
(USE IPL1-XX-D-P)
(NOT AVAILABLE W/ -K, OPTIONS)
-K: KEYED POLARIZATION
(USE IPL1-XX-D-K)
(SEE FIG. 5, SHEET 3)
(NOT AVAILABLE W/ -P, OPTIONS)
(LEAVE BLANK FOR NO POLARIZATION
(SEE FIG. 4, SHEET 3), SAMTEC WILL ONLY SUPPORT
EXISTING BUSINESS AS OF REV. U)
.250 6.35
REF
07
C
L
.100 2.54 REF
.040 1.02 REF
C
L
.100 2.54 REF
IPL1-106-01-XXX-D-P SHOWN
FIG 1
PLATING SPECIFICATION
-F: FLASH SELECTIVE (USE T-1S64-XX-F)
-L: LIGHT SELECTIVE (USE T-1S64-XX-L)
-S: SELECTIVE (USE T-1S64-XX-S)
-H: HEAVY GOLD (T-1S64-XX-H)
-FM: FLASH SELECTIVE/MATTE TIN TAILS (USE T-1S64-XX-F)
-LM: LIGHT SELECTIVE/MATTE TIN TAILS (USE T-1S64-XX-L)
-SM: SELECTIVE/MATTE TIN TAILS (USE T-1S64-XX-S)
-STL: SELECTIVE/ TIN/LEAD TAILS (USE T-1S64-XX-STL)
OPTION
-RA: RIGHT ANGLE (SEE FIG. 3, SHT 2)
(AVAILABLE WITH -01 LEAD STYLE ONLY)
ROW SPECIFICATION
-D: DOUBLE (USE IPL1-XX-D)
**
NOT RELEASED FOR PRODUCTION
IPL1-XX-D-P
SEE NOTE 9
"A"
(SEE NOTE 11)
SEE NOTE 5
C6
.300 7.62
REF
.320 8.13
REF
.215 5.46
REF
.120 3.05 REF
.025 0.64 SQ REF
C3
2 MAX SWAY
(TYP)
C4
"A"
C7
T-1S64-07-XXX
2 MAX SWAY
(TYP)
.100 2.54
C8
.100 2.54
C5
SECTION "A"-"A"
((No OF POS -1)
x .100[2.54]) .008[.20]
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. NOTE DELETED.
3. MINIMUM TERMINAL RETENTION: 1 LB.
4. PARTS TO BE MOLDED TO POSITION.
5. POST MUST BE WITHIN .005[.13] OF EACH OTHER.
6. ALL PIN TO PIN DIMENSIONS TO BE MEASURED
FROM TIP TO TIP.
7. NOTE DELETED.
8. DIMENSION TO BE MEASURED AT BEND.
9. TIP TO BE FLUSH TO .015 BELOW TOP OF SHROUD.
10. BOTH ROWS TO BE SYMMETRIC WITHIN .010[0.25].
11.THIS NUMBER REPRESENTS THE NUMBER OF POSITIONS
PER ROW ONLY AND IS NOT INTENDED TO BE USED IN
POSITION NUMBERING.
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
.XX: .01[.3]
.XXX: .005[.13]
.XXXX: .0020[.051]
MATERIAL:
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
PROPRIETARY NOTE
DECIMALS
ANGLES
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
INSULATOR: LCP, COLOR: BLACK
-K INSULATOR: LCP, COLOR: NATURAL
TERMINAL: PHOS BRONZE
.100[2.54] DOUBLE ROW TERMINAL ASSEMBLY
DWG. NO.
F:\DWG\MISC\MKTG\IPL1-1XX-XX-XXX-D-XX-X-MKT.SLDDRW
BY:
IPL1-1XX-XX-XXX-D-XX-X
KEVIN B
03/11/02
SHEET
1
OF
3
REVISION AA
IPL1-106-02-XXX-D-P SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1]
C9
FIG 2
-02: SURFACE MOUNT INPROCESS 1
-02: SURFACE MOUNT INPROCESS 2
SEE NOTE 9
AA
.345 8.76
(SEE NOTE 8)
.215 5.46
REF
90°
- 4°
90°
- 4°
.115 2.92 REF
SEE TABLE 2
T-1S64-08-XXX
SEE NOTE 10
.235 5.97
.125 3.17
+0°
+0°
C10
.377 9.58
REF
.377±.010 9.58±0.25
T-1S64-08-XXX
01
02
(ASSEMBLIES TO HAVE POSITION #1 LOADED IN THE SAME
DIRECTION AS ARROW ON TUBE, EXCEPT WITH -RA OPTION)
PT-1-24-04-40
PT-1-24-15-29
PT-1-24-02-08
07
PACKAGING VIEWS
IPL1-106-01-XXX-D-RA-P SHOWN
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1)
.290 7.37 REF
T-1S64-09-XXX
T-1S64-10-XXX
"B"
C14
FIG 3
SEE NOTE 9
.215 5.46
REF
C15
AA
.100 2.54
.060 1.52
(SEE NOTE 8)
"B"
.085 2.16 REF
SECTION "B"-"B"
F:\DWG\MISC\MKTG\IPL1-1XX-XX-XXX-D-XX-X-MKT.SLDDRW
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.100[2.54] DOUBLE ROW TERMINAL ASSEMBLY
BY:
IPL1-1XX-XX-XXX-D-XX-X
KEVIN B
03/11/02
SHEET
2
OF
3
REVISION AA
-RA: INPROCESS 1
-RA: INPROCESS 2
-RA: INPROCESS 3
C12
C13
-RA: INPROCESS 4
SEE NOTE 9
90°
.115 2.92 REF
.640 16.26
C11
SEE NOTE 9
.215 5.46 REF
.215 5.46 REF
.530 13.46 REF
.160 4.06
.730 18.54 REF
.740 18.80
.085 2.16 REF
T-1S64-09-XXX
.060 1.52
T-1S64-10-XXX
(IPL1-106-01-XXX-D SHOWN)
(DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIG. 1)
SAMTEC WILL ONLY SUPPORT
EXISTING BUSINESS AS OF REV. U)
FIG 4
(IPL1-106-01-XXX-D-K SHOWN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 4)
-02 POS
(DIFFERENT AS SHOWN)
.040 1.02
REF
.040 1.02
REF (TYP)
01 02
FIG 5
01
02
01
C
L
02
07
07
IPL1-XX-D
IPL1-06-D-K
.030 0.76
REF
03
IPL1-02-D-K
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.100[2.54] DOUBLE ROW TERMINAL ASSEMBLY
IPL1-1XX-XX-XXX-D-XX-X
KEVIN B
03/11/02
F:\DWG\MISC\MKTG\IPL1-1XX-XX-XXX-D-XX-X-MKT.SLDDRW
BY:
SHEET
3
OF
3
