LH1550AAB1-TR datasheet, PDF - EEWORLD Datasheet

LH1550AAB1-TR: DescriptionTransistor Output SSR, 1-Channel, 3750V Isolation; CategoryLED optoelectronic/LED photoelectric; File Size140KB，3 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

LH1550AAB1-TR Overview

Transistor Output SSR, 1-Channel, 3750V Isolation

Parameter Name	Attribute value
Maker	Infineon
Reach Compliance Code	unknown
Other features	UL RECOGNIZED
Configuration	SINGLE
Maximum forward current	0.05 A
Maximum insulation voltage	3750 V
Number of components	1
Maximum on-state current	0.1 A
Maximum on-state resistance	50 Ω
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	TRANSISTOR OUTPUT SSR
Base Number Matches	1

	LH1550AAB1-TR	LH1550AAB1TR	LH1550AAB1	LH1550AT1
Description	Transistor Output SSR, 1-Channel, 3750V Isolation	TRANSISTOR OUTPUT SOLID STATE RELAY, 3750V ISOLATION-MAX, SMD-6	Transistor Output SSR, 1-Channel, 3750V Isolation, SMD-6	Transistor Output SSR, 1-Channel, 3750V Isolation, DIP-6
Maker	Infineon	Infineon	Infineon	Infineon
Reach Compliance Code	unknown	unknown	compliant	unknown
Other features	UL RECOGNIZED	UL RECOGNIZED, HIGH RELIABILITY	UL RECOGNIZED, HIGH RELIABILITY	UL RECOGNIZED, HIGH RELIABILITY
Configuration	SINGLE	SINGLE	SINGLE	SINGLE
Maximum forward current	0.05 A	0.05 A	0.05 A	0.05 A
Maximum insulation voltage	3750 V	3750 V	3750 V	3750 V
Number of components	1	1	1	1
Maximum on-state current	0.1 A	0.1 A	0.1 A	0.1 A
Maximum on-state resistance	50 Ω	35 Ω	35 Ω	35 Ω
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C
Optoelectronic device types	TRANSISTOR OUTPUT SSR	TRANSISTOR OUTPUT SSR	TRANSISTOR OUTPUT SSR	TRANSISTOR OUTPUT SSR
package instruction	-	SMD-6	SMD-6	DIP-6
